95810 Viega MegaPress reducer Smart Connect technology 304 stainless steel, 1-1/4'' x 1''
Manufacturer Resources
Product Specs
- Connection Type:
- FTG x P
- Material Type:
- 304 Stainless Steel
- Product Dimension:
- 1-1/4'' x 1''
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Reducers
- Product Type:
- Reducer
- Product Length:
- 4.008"
- Product Height:
- 1.78"
- Product Weight:
- 0.685 lbs
- Product Width:
- 1.78"
- Product Material:
- 304 stainless steel
Viega 95810 – Frequently Asked Questions
1) What does the FTG x P connection on the Viega 95810 MegaPress reducer mean for how it installs?
FTG x P means one end is a fitting end (male, sized to slip inside another MegaPress fitting socket) and the other is a press socket that accepts pipe. So the 95810 lets you step down from 1-1/4 inch to 1 inch without adding a separate coupling. Both joints are made with a press tool and the seal, not with threads or solder.
2) Is the Viega 95810 MegaPress reducer for copper tube or for steel pipe?
MegaPress fittings press onto black iron and carbon steel pipe, which is what separates the MegaPress line from Viega's copper ProPress line. The 95810 is a 1-1/4 inch by 1 inch reducer with a 304 stainless steel body. If you are pressing copper tube, you want a ProPress fitting instead.
3) Will the Viega 95810 reducer fit in a tight chase or between close hangers?
Overall length is 4.008 inches, with a 1.78 inch height and 1.78 inch width, so plan on roughly four inches of straight run for the fitting body. Remember you also need clearance around the fitting for the press tool jaw to close fully on each joint, which is usually the controlling dimension in a tight chase, not the fitting itself.
4) What is Smart Connect on this Viega MegaPress fitting and why does it matter on an inspection?
Smart Connect is a feature of the sealing element that leaks visibly at an unpressed joint during pressure testing, so a connection you missed shows itself rather than passing test and failing later. On a large repipe with dozens of joints it is the reason a crew can test and find the one fitting that never got pressed.
5) How much does the Viega 95810 MegaPress reducer weigh for takeoff and hanger spacing?
0.685 lbs each. Light enough that a run of these does not change hanger sizing, but worth adding into a count when you are pricing out a few hundred fittings.
