American Standard Ultima Manual Toilet Flush Valve, Piston-Type, 1.28 gpf/4.8 Lpf, 27-Inch Rough-In - AMS-6047122

American Standard Ultima Manual Toilet Flush Valve, Piston-Type, 1.28 gpf/4.8 Lpf, 27-Inch Rough-In - AMS-6047122

(No reviews yet) Write a Review

Model: 6047122.002

In Stock (leaves warehouse same day if ordered before 3pm ET)

$281.96
$267.16
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Ultima Manual Toilet Flush Valve, Piston-Type, 1.28 gpf/4.8 Lpf, 27-Inch Rough-In
  • For flushometer bowls with 1-1/2" (38 mm) exposed top spud
  • Exclusive DynaClean self-cleaning wiper spring technology
  • Integral wiper spring cleans refill orifice with every flush to help prevent valve run-on
  • ADA-compliant non-hold open handle provides automatic shut-off after every flush
  • Piston operation delivers superior flush accuracy and repeatability
  • High back pressure vacuum breaker helps prevent dripping
  • Can be install left- or right-handed
  • No external volume adjustment
  • 27" (686 mm) rough-in. Pipe can be cut during installation

Manufacturer Resources

Product Specs

Product Type:
Flush Valve
Product Group:
Washroom/Bath
Product Subgroup:
Toilet
Department:
Plumbing

American Standard 6047122.002 – Frequently Asked Questions

1) Will the American Standard Ultima 6047122 flush valve fit my toilet's spud?
The Ultima 6047122 is built for flushometer bowls with a 1-1/2 inch (38 mm) exposed top spud. If your bowl has a back spud, a concealed spud, or a smaller spud size, this valve won't connect without changing the bowl or the spud connection.
2) What does the 27-inch rough-in mean on this Ultima flush valve, and can I use it on a shorter rough-in?
The supply pipe on the Ultima manual valve comes at a 27 inch (686 mm) rough-in, and the pipe can be cut during installation. So it covers 27 inches and anything shorter you cut it down to, but it won't stretch past 27 inches.
3) Does this American Standard Ultima valve flush 1.28 gpf, and is that right for a high-efficiency bowl?
It flushes at 1.28 gpf / 4.8 Lpf, which is the standard high-efficiency water closet volume. Match it to a bowl rated for 1.28 gpf. There is no external volume adjustment on this valve, so you cannot dial the flush up or down in the field, the bowl has to be specified for that volume.
4) Is the handle on this flush valve ADA compliant?
The Ultima manual valve uses an ADA-compliant non-hold-open handle that shuts off automatically after each flush. For a facility restroom that has to meet accessible-stall requirements, that handle is the piece that matters, along with mounting the handle on the open side of the stall.
5) My flushometers keep running on after the flush. Will this one fix that?
Run-on is usually a fouled refill orifice. The Ultima uses DynaClean, an integral wiper spring that scrubs the refill orifice on every flush to help prevent valve run-on. It also has a high back pressure vacuum breaker to help stop dripping. For hard-water or high-sediment buildings, that self-cleaning action is the reason to pick this one.
6) Can the Ultima 6047122 be mounted for a left-hand supply?
Yes, it installs left- or right-handed, so one part number covers both stall layouts. That is useful when you're standardizing a restroom where the supply comes in from either side.
7) Piston or diaphragm flushometer, which should I use?
This Ultima is a piston-type valve. Piston operation gives more consistent flush volume flush after flush, which is what you want in high-traffic restrooms where accuracy and repeatability matter. Diaphragm valves are the other common style and are what many buildings already have, so if you're rebuilding rather than replacing whole valves, confirm which type is on the wall before ordering parts.
8) Is this a manual or sensor flush valve?
Manual. The 6047122 is handle-operated, not battery or sensor driven, so there's no power supply, no batteries to change, and no sensor to fail. If the spec calls for touchless operation, this is the wrong valve for that opening.
9) Does the Ultima 6047122 come in anything besides chrome?
Chrome is the finish for 6047122.002. It's the standard commercial restroom finish and matches most existing flushometers in a multi-stall layout.
