Toto Connelly Toilet Tank

TOTO Connelly Dual-Max Dual Flush 1.28 and 0.9 GPF Toilet Tank with Right and Left Trip Lever

(No reviews yet) Write a Review

Model: ST494MR#01
From the Connelly Collection
Selected Finish is
Selected Lever is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$248.14
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

* Default Option Specs and Description based on : ST494MR#01- (Model specific information below)

The TOTO Connelly Dual-Max, Dual Flush 1.28 and 0.9 GPF Toilet Tank with Right-Hand Trip Lever is designed for use with the Connelly dual flush bowl. The Connelly tank includes a tank to bowl gasket, tank to bowl hardware, and toilet bolt caps. The Connelly tank features TOTO's Dual-Max dual flush option, allowing you to proactively conserve water usage. The right-hand chrome trip lever allows you to choose between a 0.9 GPF rinse or 1.28 GPF for tougher jobs. The Connelly tank meets the standards for EPA WaterSense, and California's CEC and CALGreen requirements. Additional items needed for installation and use must be purchased separately: toilet bowl, wax ring, toilet mounting bolts, water supply lines, and toilet seat. The Connelly ST494M tank can be used on the CT494CEFG and CT494CEF bowls.

Features

  • Connelly toilet tank for use with Connelly toilet bowl
  • Dual-Max flushing system allows you to proactively conserve water - Select 1.28 GPF or 0.9 GPF
  • Right-hand chrome trip lever
  • WaterSense, CALGreen, and CEC compliant
  • Included parts: tank to bowl gasket, tank to bowl hardware, and toilet bolt caps
  •

Manufacturer Resources

Specification Sheet

Product Specs

Battery Included:
No
CALGreen:
Yes
CEC:
Yes
Collection:
Connelly
Flush Valve Size:
2
Product Group:
Washroom/Bath
Product Subgroup:
Toilet Tank
Product Type:
Tanks
WaterSense:
Yes
Battery Type:
Does Not Contain a Battery
Product Length:
7.375
Gallons Per Flush (GPF):
0.9|1.28
Product Height:
14.125
Product Material:
Vitreous China
Product Category:
Tanks
Product Weight:
31
Product Width:
16.625
Department:
Plumbing

TOTO ST494MR#01 – Frequently Asked Questions

1) Which TOTO bowls does the Connelly ST494M tank fit?
The Connelly ST494M tank is built for the Connelly dual flush bowls, specifically the CT494CEFG and CT494CEF. It is a tank-only item, so the bowl has to be one of those two; it will not mate to other TOTO bowls.
2) Does the Connelly tank come with the bowl, seat, and wax ring, or do I order those separately?
Tank only. What ships with it is the tank to bowl gasket, the tank to bowl hardware, and the toilet bolt caps. You still need to buy the bowl, wax ring, floor mounting bolts, water supply line, and the seat to finish the install.
3) Can I get the Connelly tank with the flush lever on the left side?
Both hands are offered: the Connelly tank comes with either a right-hand or a left-hand trip lever, in Cotton White. Pick the side that clears your wall or vanity, since the lever position is fixed by the tank you order.
4) Will this toilet tank meet California water efficiency rules for a multi-family or commercial job?
It does. The Connelly tank is WaterSense labeled and meets California CEC and CALGreen requirements, which is what specs on California projects normally call for at 1.28 GPF maximum.
5) How much water does the Connelly dual flush tank use per flush?
Two settings: 0.9 GPF for liquid waste and 1.28 GPF for solids, through TOTO's Dual-Max system. The chrome trip lever selects between them.
6) I cracked the tank on a Connelly toilet. Can I just replace the tank?
Yes, that is exactly what this is sold for. The Connelly ST494M tank replaces the tank on a Connelly toilet using a CT494CEFG or CT494CEF bowl, and it comes with a fresh tank to bowl gasket, hardware, and bolt caps so the reset is complete. Match the lever hand to what you had.
7) What size flush valve is in the Connelly tank, and does it need batteries or power?
A 2 inch flush valve, fully mechanical. There is no battery and no electrical connection, so nothing to wire and no sensor to maintain.
8) How big and heavy is the Connelly tank for handling and clearance?
Vitreous china, 31 pounds, measuring 16.625 x 14.125 x 7.375 inches. Plan on a two-hand lift over the bowl and check your clearance behind the fixture before setting it.
