ABH A548S / A548B Non Mortised Edge Guard

ABH A548S/A548B Non-Mortised Edge Guard with Integral Astragal - 304 Stainless Steel

(No reviews yet) Write a Review

Model: A548S-32D-42
$172.00
$142.21
Selected Finish is
Selected Edge Type is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$172.00
$142.21
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

ABH Non-Mortised Edge Guard with Integral Astragal - 304 Stainless Steel

Professional Door Protection with Enhanced Security Features

The ABH Non-Mortised Edge Guard provides superior door protection with an integral astragal design that protects the latch from intruders and vandalism. Constructed from .050" thick 304 stainless steel, this edge guard is available in custom lengths up to 120" and comes standard with UL fire rating for both wood and hollow metal fire doors. Available in both square edge (A548S) and bevel edge (A548B) configurations for versatile installation requirements.

Professional Features & Benefits

  • Custom Length Capability: Available in any length up to 120" for precise door fitting and comprehensive protection coverage.
  • Heavy-Duty Construction: .050" material thickness in 304 stainless steel provides exceptional durability and corrosion resistance for long-term performance.
  • Integral Astragal Design: Built-in astragal provides additional security by protecting the latch from intruders and vandalism attempts.
  • Dual Edge Options: Available in square edge (A548S) and bevel edge (A548B) configurations to match specific door requirements.
  • Non-Mortised Installation: Surface-mounted design eliminates the need for door preparation and mortising, simplifying installation.
  • UL Fire Rating: Standard fire rating for wood or plastic-covered wood composite fire doors up to 1-1/2 hours and hollow metal fire doors up to 3 hours.
  • Complete Hardware Package: Includes #6 x 5/8" Phillips flat head, undercut sheet metal screws for secure mounting.
  • BAA Qualified: Meets Buy American Act requirements for government and institutional projects.

Technical Specifications

  • BAA Qualified: Yes
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Fasteners: #6 x 5/8" Phillips flat head, undercut sheet metal screws
  • Keyed: N/A
  • Keyed Function: N/A
  • PDF:A548 3 Sided with Astragal Edge Guard: https://zensupply.com/content/pdf/abh/0000276_a548.pdf
  • PDF:Door Clearance Chart: https://zensupply.com/content/pdf/abh/0002576_door_clearance_chart_abh02222_2022.pdf
  • PDF:Stainless Steel Edge Guard Clearance Chart: https://zensupply.com/content/pdf/abh/0000576_ss_eg_clearance_chart_01.pdf
  • PDF:Stainless Steel Edge Guards: https://zensupply.com/content/pdf/abh/0000575_stainless_steel_edge_guard_templates.pdf
  • PDF:Stainless Steel Edge Guards Cross Reference: https://zensupply.com/content/pdf/abh/0000408_cross_reference.pdf
  • Product Category: Door Trim and Accessories
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Door Armor and Protection Plates
  • Product Type: Edge Guards and Protectors
  • Subcategory: Door Guards

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose ABH Quality?

ABH edge guard products deliver professional-grade reliability with .050" thick 304 stainless steel construction and UL fire rating for demanding commercial applications. The integral astragal design provides enhanced security protection while the non-mortised installation simplifies field installation. Engineered for demanding commercial applications where dependable door protection and fire safety compliance are essential.

Product Specs

Product Group:
Door Trim and Accessories
Fasteners:
#6 x 5/8" Phillips flat head, undercut sheet metal screws
Product Subgroup:
Door Armor and Protection Plates
Product Type:
Edge Guards and Protectors
Subcategory:
Door Guards
Commercial/Residential:
Commercial
Keyed:
N/A
Keyed Function:
N/A
BAA Qualified:
Yes
Product Category:
Door Trim and Accessories
Department:
Door Hardware

ABH A548S-32D-42 – Frequently Asked Questions

1) Will the ABH A548 edge guard fit my door without mortising the edge?
No door prep needed. The A548S and A548B are non-mortised, three-sided edge guards that wrap the door edge and fasten on the surface with the supplied #6 x 5/8 inch Phillips flat head undercut sheet metal screws. That is what makes it a practical retrofit on doors already hung: no routing, no rehanging, no removing the door for shop work. Worth checking your hinge-side and strike-side clearances first, since adding material to the edge changes how the door meets the frame.
2) Should I order the square edge or bevel edge version of the ABH A548?
Match the guard to the door edge you already have. The A548S is the square edge version, for a door with a flat, square-machined edge. The A548B is the bevel edge version, for a door beveled on the lock edge (the usual bevel on commercial doors so the leading edge clears the stop as it swings). Putting a square guard on a beveled door leaves the guard proud of the edge and fights the frame. Both are the same .050 inch 304 stainless construction and both come in satin stainless.
3) What does the integral astragal on the ABH A548 actually do?
It shields the latch. The astragal is formed into the guard itself and stands off the door edge to cover the gap between door and frame, so someone cannot get a shim or a pry bar onto the latchbolt. On a leaf that keeps getting loided or jimmied, that is the reason to specify the A548 over a plain three-sided edge guard, which protects the edge from wear but leaves the latch gap open. It is a mechanical shield only, so it does not change your lock function or keying.
4) Will an edge guard with an astragal make my door bind or stop it from closing?
It can, which is why clearance is the thing to check before you order. The astragal adds material at the door edge and reduces the gap to the frame, so on a door already hung tight the leaf can rub or the latch may not throw fully. ABH publishes a door clearance chart and a separate stainless steel edge guard clearance chart for working this out on your opening; templates for the A548 are published as well. On a pair of doors, only one leaf gets the astragal guard.
5) Does the ABH A548 edge guard meet Buy American requirements for a federal job?
It is BAA qualified, so it can be specified on projects carrying Buy American Act requirements. Combined with the UL fire rating for hollow metal doors up to 3 hours, that covers the two questions that usually gate a government or municipal submittal on a protection plate. It is a commercial-duty product, not a residential one.
6) Is 304 stainless the right edge guard material for a kitchen, locker room, or coastal building?
Yes. The A548 is .050 inch thick 304 stainless steel, which is the standard corrosion-resistant grade for wet, humid, and cleaning-chemical environments, and it takes repeated washdown without pitting the way a painted or plated guard does. The .050 inch gauge is what carries cart and gurney impact on the door edge. Satin stainless is the finish, so it matches the 32D/US32D hardware already on most commercial and healthcare openings.
7) Do I need to buy screws or anything else to install the ABH A548 edge guard?
Fasteners come with it. Each guard ships with #6 x 5/8 inch Phillips flat head, undercut sheet metal screws, so the only thing you supply is the drill, the countersink pilot, and a piece cut to your door height if you are not ordering an exact length. Nothing about the guard changes your lock or hinge hardware.
8) Do I need an edge guard with an astragal or will a plain edge guard do?
Depends on what is failing. If the door edge is getting chewed up by carts, keys, and traffic, a plain three-sided stainless edge guard handles it. Choose the A548 with the integral astragal when the problem is security: the astragal covers the door-to-frame gap and blocks access to the latch, which a plain guard does not. Schools, multi-tenant residential, and back-of-house doors that get jimmied are where the astragal version earns its place.
9) I have edge guards from another manufacturer on my other doors. Is there an ABH equivalent?
ABH publishes a cross reference for its stainless steel edge guards, which maps competitor model numbers to the matching ABH part. If you are standardizing a building on one product, take the model number stamped on what is already installed and run it through that cross reference to find whether the A548S or A548B is the match for your edge type and length.
