Yale Commercial Yale nexTouch Series - Grade 1 Mortise Lock with Keypad Trim, Stand Alone Pushbutton Keypad YAL-NTM622-NR

Accentra nexTouch Series Grade 1 Mortise Keypad Lock with Pushbutton Trim

(1 review) Write a Review

Model: AUR-NTM613-NR-626
$1,148.00
$758.64
Selected Finish is
Selected Rose Option is
Selected Lever Style is
Selected Cylinder Override is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,148.00
$758.64
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Accentra nexTouch Series Grade 1 Mortise Keypad Lock with Pushbutton Trim

ANSI/BHMA Grade 1 Certified Electronic Mortise Security

The Accentra nexTouch Series delivers professional-grade electronic access control with ANSI/BHMA Grade 1 certification for demanding commercial applications. This sectional mortise keypad lock features a 2-3/4" backset, 3/4" stainless steel latchbolt throw, and accommodates door thickness from 1-3/4" standard up to 3-1/4" thick doors. UL/cUL fire rated up to 3 hours with windstorm certification for comprehensive building code compliance.

Professional Features & Benefits

  • ANSI/BHMA: Certified ANSI/BHMA A156.13, Series 1000, Grade 1
  • UL/cUL: UL/cUL fire rated up to 3 hours
  • Windstorm: Certified (refer to local codes)
  • Mechanism: Stainless steel
  • Backset: 2-3/4"
  • Latchbolt: 3/4" stainless steel throw
  • Door Thickness: 1-3/4" standard, to 3-1/4" thick doors to order
  • Fronts: Bevel front, free-floating to adjust from flat to standard bevel of 1/8" in 2"
  • Cylinders: 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order
  • Reversibility: Field reversible handing
  • Strikes: 1-1/4" curved lip for 1-3/4" door standard; other lip lengths to special order; all reversible
  • Levers: Offered in 9 standard lever designs as well as decorative lever styles. See catalog for more information.
  • Finishes: Available in four finishes, see catalog for more details.
  • Warranty: 3 year limited warranty on mechnical and electronic components, one year on finish.
  • A Certified Integrator is required to configure this product with Yale Accentra.

Installation & Operation

  1. Verify door preparation meets mortise lock requirements including proper door thickness (1-3/4" to 3-1/4"), backset clearance for 2-3/4" dimension, and mortise pocket specifications.
  2. Install mortise lock body in prepared door pocket ensuring proper alignment and secure mounting of all mechanical components.
  3. Configure electronic keypad settings and programming per manufacturer instructions. A Certified Integrator is required to configure this product with Yale Accentra systems.
  4. Install cylinder assembly with provided 6-pin keyed-random cylinder and verify smooth key operation and proper throw engagement.
  5. Mount exterior keypad trim and interior lever trim ensuring proper alignment and secure attachment to mortise mechanism.
  6. Test all functions including keypad operation, mechanical key override, latchbolt throw, and integration with any connected access control systems.
  7. Complete final inspection and document programming settings. Refer to manufacturer documentation for complete installation specifications and programming procedures.

Professional Applications

  • Commercial Office Building Access Control
  • Educational Facility Security Systems
  • Healthcare Institution Entry Management
  • Retail Establishment Loss Prevention
  • Industrial Facility Controlled Access
  • Government and Municipal Building Security
  • Multi-Tenant Property Management

Why Choose Accentra Quality?

Accentra nexTouch Series mortise locks deliver professional-grade reliability with stainless steel mechanism construction and ANSI/BHMA Grade 1 certification for demanding commercial applications. The comprehensive 3 year limited warranty on mechanical and electronic components with UL/cUL fire rating up to 3 hours ensures dependable performance in critical security applications. Engineered for commercial environments where robust electronic access control and code compliance are essential.

Product Specs

Series:
nexTouch Series
Subcategory:
Mortise Keypad Lock
Product Group:
Mechanical Locks
Product Subgroup:
Mortise Locks and Trim
Product Type:
Mortise Locks
Commercial/Residential:
Commercial
Lock Type:
Mortise
Electronic:
Yes
Product Attribute:
Electronic Locks
Tags:
yale nextouch aur ntm 62, yale nextouch sectionalmortise lock, yale commercial door lock
Product Model:
YAL-NTM622
Reader Type:
Keypad
Product Category:
Electronic Locks
Department:
Door Hardware

Accentra AUR-NTM613-NR-626 – Frequently Asked Questions

1) Do I have to order the nexTouch keypad mortise lock handed, or can it be reversed on site?
Handing is field reversible on the nexTouch mortise lock, so one part number covers both left and right hand openings and you can flip it at install. The strike follows the same logic: the standard 1-1/4 inch curved lip strike for a 1-3/4 inch door is reversible too. Other lip lengths are a special order if the frame sits proud of the jamb face and needs a longer lip.
2) Can I put an electronic keypad mortise lock on a 3 hour fire rated stair door?
Yes. The nexTouch Grade 1 mortise keypad lock is UL/cUL fire rated up to 3 hours and is certified to ANSI/BHMA A156.13, Series 1000, Grade 1, which is the heavy duty mortise standard institutional specs call for. It also carries windstorm certification, though that one is written against local code, so the AHJ decides whether it satisfies the opening.
3) Does the nexTouch keypad lock have a key override, and how is it keyed when it arrives?
Key override is an ordering choice, not standard equipment: the NTM622 is built either with cylinder override or without it, so you pick that up front. Ordered with override, it comes with a 6-pin keyed-random cylinder and two keys, and a 7-pin cylinder is available to order if the building runs a 7-pin master system. Without override, entry is keypad only, which is what most people want on an interior door where a lost key is the bigger risk.
4) Will the 3/4 inch latchbolt on the nexTouch mortise lock catch my existing ANSI strike?
The latchbolt throws 3/4 inch and is stainless steel, which is the normal throw for a commercial mortise latch, so an existing ANSI mortise strike with an adequately deep pocket will take it. The front is a free floating bevel that adjusts from flat to the standard 1/8 inch in 2 inch bevel, so it self-corrects on a beveled door edge instead of forcing you to reshape the mortise. Standard strike lip is 1-1/4 inch curved.
5) Can I program the nexTouch NTM622 keypad lock myself or do I need an installer?
The mechanical install is standard mortise work, but configuring the NTM622 with the Yale Accentra system requires a Certified Integrator. If the plan is to run it on Accentra, budget for that integrator on the job. If you only need a standalone pushbutton lock with no system behind it, a Dormakaba E-Plex 2000 Series pushbutton mortise lock or the Schlage CO-100 standalone keypad mortise lock are the standalone route.
6) Is there a Grade 1 keypad mortise lock that works on a door thicker than 2 inches?
That is where the nexTouch NTM622 separates from most of the field. It is built for 1-3/4 inch doors standard and can be ordered for doors up to 3-1/4 inches thick. The Alarm Lock Trilogy electronic mortise locks, DL2700CR, DL3500CR and the DL4500 deadbolt, all top out at 1-7/8 inches. The TownSteel FME-2000 and FME-4000 and the Schlage CO-100 keypad mortise lock are all listed at 1-3/4 inches. On a heavy timber or thick institutional door, the nexTouch is the one that can be built to the opening.
7) The door is only 1-5/8 inch thick. What electronic mortise lock works there instead of the nexTouch NTM622?
The nexTouch NTM622 is built for 1-3/4 inch doors as standard, with thicker doors to 3-1/4 inch available to order, so a thin door falls below its range. The Alarm Lock Trilogy family covers 1-5/8 inch to 1-7/8 inch door thickness: the DL2700CR in classroom function, the DL3500CR in classroom function with 300 user codes, and the DL4500DB as a Grade 1 electronic mortise deadbolt with a privacy keypad. All three are keypad-operated electronic mortise locks, and the DL2700CR and DL3500CR are Grade 1.
8) What is the closest equivalent to the Accentra nexTouch NTM622 keypad mortise lock from another manufacturer?
The nexTouch NTM622 is a Grade 1 mortise lock with a keypad reader, so the nearest cross-brand equivalents are standalone electronic mortise locks that also carry a Grade 1 rating and a pushbutton entry. The Schlage CO-100-MS-40-KP is a standalone electronic mortise lock with a keypad reader, Grade 1, heavy duty, for 1-3/4 inch doors, in privacy function. The Dormakaba E-Plex E5086 is a Grade 1 electronic pushbutton and card mortise lock in a back-to-back entry/egress arrangement. The Alarm Lock DL3500CR Trilogy is a Grade 1 electronic mortise lock with 300 user codes in classroom function. Which one lands depends on the function the opening needs, since the nexTouch is offered with or without cylinder override.
9) Which electronic mortise lock should be used if credentials need to be cards or phones rather than a keypad code?
The nexTouch NTM622 reads a keypad code, with a mechanical cylinder override offered on part of the range. For credential-based openings, the Schlage LEMD-GRW is a Grade 1 ENGAGE Series wireless mortise lock with a 125kHz proximity reader and mobile-enabled deadbolt, rated 3 hours fire. The TownSteel FME-2000 is a Grade 1 heavy duty classroom mortise lockset with RFID for 1-3/4 inch doors, and the FME-4000 is the electronic intruder classroom version with RFID. Dormakaba's LX-I-M002 Saffire is an electronic RFID mortise lockset with BLE mobile access at BHMA Grade 2.
10) What should be specified when the opening has to be released from an access control panel rather than by a code at the door?
The nexTouch NTM622 is a standalone keypad lock at the door, and a Certified Integrator is required to configure it with Yale Accentra. For an opening driven from a panel, a wired electrified mortise lock is the different approach: the BEST 45HW is a heavy duty wired electromechanical mortise lock with 12V/24V operation, the Command Access ML190 is a heavy duty motorized mortise lock in storeroom function with field selectable EL/EU operation on 24VDC, and the Schlage L9092EU with 03A trim is a heavy duty electric lock/unlock outside lever mortise lock, keyed outside, with request to exit, on 12/24VDC for 1-3/4 inch doors.
11) Which keypad mortise locks look like a match for the nexTouch NTM622 but carry a different grade?
Grade matters when a facility standard calls for Grade 1. The nexTouch NTM622 is certified ANSI/BHMA A156.13, Series 1000, Grade 1. Two keypad-style electronic mortise locks that read as close alternatives sit at a different rating: the Schlage LEBMB-ADD is a mobile-enabled mortise lock with push button and LED covering privacy, office and apartment functions at Grade 2 with a 3 hour fire rating, and the Dormakaba Saffire LX-I-M002 electronic RFID mortise lockset is BHMA Grade 2. If the spec on the drawing reads Grade 1, those two answer a different line item.
12) Which keyless mortise lock is used on an aluminum storefront or narrow stile door where the nexTouch NTM622 will not fit?
The nexTouch NTM622 is a sectional mortise lock with a 2-3/4 inch backset for doors 1-3/4 inch and thicker, which is a hollow metal and wood door preparation. For storefront work, the Dormakaba E-Plex 2066 is an electronic pushbutton keyless mortise lock built for wide stile doors, and the Alarm Lock DL1300NW Trilogy Networx is a wireless electronic mortise lock with a keypad made for Adams Rite deadlatches. Kaba Ilco's BR Series is a glass door bottom rail lock for all-glass openings.
13) A cylindrical lock is on the door now. Does the nexTouch NTM622 drop in, or is there a cylindrical equivalent?
It does not drop in. The nexTouch NTM622 needs a mortise pocket prepared for a 2-3/4 inch backset mortise lock body, while a cylindrical lock uses a bored preparation, so the door has to be prepped or replaced. If the door prep is staying cylindrical, the Schlage PC10 is a Grade 1 passage cylindrical lock, non-keyed with rose, for 1-3/4 inch doors. The mortise counterpart in the same family is the Schlage PM010, a Grade 1 passage latch mortise lock, non-keyed, for 1-3/4 inch doors.
14) What do I have to specify when ordering the Accentra NTM622 keypad mortise lock?
Four things decide the part number. Cylinder override, with or without. Lever design, from Augusta, Carmel, Monroe or Pacific Beach. Rose, with Copenhagen as the standard and R3 through R9 as the alternatives. Finish, from 605 bright brass, 613E dark oxidized satin bronze equivalent, 626 satin chrome, or BSP black suede powder coat. Beyond that, a 7-pin cylinder, a non-standard strike lip, or a door over 1-3/4 inches thick each have to be called out as to-order items.
15) I need the electronic locks to match the satin chrome lever hardware already in the building. What finishes does the nexTouch mortise keypad lock come in?
626 satin chrome is one of the four, which is the most common commercial finish and what most existing lever hardware in an office or school building will be. The others are 605 bright brass, 613E dark oxidized satin bronze equivalent, and BSP black suede powder coat. Lever design is a separate choice from finish, so you can match both the color and the lever profile of the mechanical locks on the rest of the floor.
16) Should I use an electronic mortise lock or an electronic cylindrical lock for a commercial entry?
A mortise lock like the nexTouch NTM622 needs a mortise pocket cut into the door edge, and in exchange you get the heavier Grade 1 A156.13 Series 1000 mechanism, a 3/4 inch stainless latchbolt, and a 3 hour fire rating. That is the right call on a high traffic entry, a stair door, or anywhere the door is already prepped for a mortise body. If the door has a standard 161 cylindrical prep instead, cutting a mortise pocket is real carpentry, and a cylindrical electronic lock is the cheaper install. What you cannot do is drop a mortise lock into a cylindrical prep.
17) What else could I use instead of the Accentra nexTouch NTM622 keypad mortise lock?
For a like-for-like Grade 1 electronic mortise lock, the Dormakaba E-Plex E5086 is a Grade 1 pushbutton and card mortise lock, and the Schlage LEMD-GRW is a Grade 1 ENGAGE wireless mortise lock with a 3 hour fire rating and a 125kHz proximity reader if you want credentials rather than a keypad. The BEST 45HZ EZ Series is an electronic keypad mortise lock with key override. TownSteel's FME-2000 Series is a Grade 1 RFID mortise lockset for 1-3/4 inch doors in a classroom function. Alarm Lock's Trilogy DL3500CR is Grade 1 classroom, but it is built for 1-5/8 to 1-7/8 inch doors, so it is not a fit on a thicker door.
18) I'm looking at the Schlage LE Series push button mortise lock. How does it compare to the Accentra nexTouch mortise keypad lock?
Grade is the difference that matters. The Schlage LEBMB-ADD is a Grade 2 mobile enabled mortise lock with push button and LED, rated 3 hours fire and built for 1-3/4 inch doors. The nexTouch NTM622 is certified Grade 1 to A156.13 Series 1000. If the spec on the drawing calls for Grade 1, the LEBMB-ADD will not satisfy it. Schlage's own Grade 1 answer in that family is the LEMD-GRW ENGAGE wireless mortise lock, which reads 125kHz proximity credentials rather than a keypad.
19) Is the nexTouch NTM622 keypad lock a full lockset or just the mortise body?
It is a complete assembly: mortise lock body, exterior keypad pushbutton trim, and interior lever trim, with the strike included. That is worth checking against what else you may be pricing, because a number of mortise items are bodies or trim only. The BEST 45H Series public entrance item is a lock body on its own, and the Sargent 130KB and 130W are mortise thumbturns, not locksets. If you already have a good mortise body in the door and only want to add electronic access, those are different purchases.
20) Is the nexTouch keypad mortise lock heavy enough for a hospital or school corridor door?
Grade 1 under ANSI/BHMA A156.13 Series 1000 is the top mortise durability tier, and the mechanism is stainless steel, so it is built for the cycle counts a healthcare or education corridor puts on a door. The 3 hour UL/cUL fire rating covers the rated openings in those buildings. One thing to plan for on a healthcare job: if the opening needs ligature resistant trim, a keypad and lever lock is the wrong form and something like TownSteel's MRX-A anti-ligature arch trim mortise lockset is what to look at instead.
21) Is there a simpler mortise lock for an opening that does not need electronic access control?
When the opening only needs mechanical keyed control, a standard Grade 1 mortise lockset covers it without programming. The Cal-Royal NM8080 is a heavy duty Grade 1 storeroom mortise lockset with an interchangeable core option for 1-3/4 inch doors, the NM8070 is the Grade 1 classroom version, and the NM8050 is the Grade 1 office/entrance version with an auxiliary deadlatch. The Corbin Russwin ML2003 is a Grade 1 mortise classroom lockset for 1-3/4 inch doors, and the Sargent 7925 is a Grade 1 heavy duty corridor/dormitory mortise lock with rose trim and a single cylinder deadbolt.
22) Do the BEST 45H mortise lock bodies substitute for the nexTouch NTM622?
They do not do the same job. The nexTouch NTM622 is a complete electronic mortise lock with keypad trim and lever trim. The BEST 45HCAC is a heavy duty mortise lock body in public entrance function and the BEST 45HCAINL is a heavy duty mortise lockbody with intruder function; both are lock bodies, so trim is a separate line. Where a keypad body from BEST is wanted, the 45HZ EZ Series is an electronic keypad mortise lock with key override function.
23) What replaces the nexTouch NTM622 on an opening that needs a push/pull paddle or anti-ligature trim?
The nexTouch NTM622 carries lever trim in Augusta, Carmel, Monroe and Pacific Beach designs over a keypad, which is not the trim style for behavioral health or hands-free openings. The Marks USA 5PDN is a Grade 1 hospital passage mortise push/pull paddleset, ligature resistant and ADA compliant, in satin stainless steel. TownSteel offers the MRX-A-01 as a Grade 1 heavy duty satin stainless steel ligature resistant arch trim mortise lockset in passage function and the MRX-L-01 as a Grade 1 heavy duty stainless steel anti-ligature lever mortise lockset, both for 1-3/4 inch doors.
24) Can a mortise thumbturn or dummy trim be ordered in place of the nexTouch NTM622 keypad lock?
No, those are different parts. The nexTouch NTM622 is a complete Grade 1 electronic mortise lock that throws a 3/4 inch stainless steel latchbolt. The Sargent 130KB and 130W are mortise thumbturns, standard duty, and turn a deadbolt from the inside rather than latching a door. The Schlage L0170 is half dummy trim, a Grade 1 mortise non-keyed lever with no latching mechanism, and the Emtek 3102 Memphis, 3104 Hamilton, 3106 Manhattan and 3019 Brisbane mortise entrance locksets are dummy function. Any of those on a controlled opening leaves it without a latch.
25) Is a mortise deadbolt an alternative to the nexTouch NTM622 keypad mortise lock?
A deadbolt secures the opening but does not latch it, so it answers a different need. The nexTouch NTM622 combines keypad entry with a latching mortise lock and an optional cylinder override. The Sargent 4874 is a double cylinder mortise deadbolt with a 2-3/4 inch backset, matching the nexTouch backset dimension, and the Kaba Ilco 185 Series mortise locks are deadbolt function with no handing. The Alarm Lock DL4500DB is the keypad version of that idea, a Grade 1 electronic mortise deadbolt with 2,000 user codes and a privacy keypad for 1-5/8 inch to 1-7/8 inch doors.
26) What Grade 1 mortise lock covers doors thicker than 1-3/4 inch besides the nexTouch NTM622?
The nexTouch NTM622 handles 1-3/4 inch as standard and up to 3-1/4 inch thick doors to order. Among mechanical peers, the Hager 3800 Series covers 1-3/4 inch to 2-1/2 inch: the 3810E passage mortise lock with escutcheon and 2-3/4 inch backset, the 3810S passage with rose, and the 3850E office lever with escutcheon, non-keyed, on a 2-3/4 inch backset. The Baldwin 6301 entry/apartment mortise lock body is listed for 1-3/4 inch and over on a 2-1/2 inch backset, and the 6310 entry/storeroom body for 1-3/8 inch and over.
27) Is there a lighter duty keypad mortise option than the Grade 1 nexTouch NTM622 for a low traffic interior door?
The nexTouch NTM622 is a Grade 1 mortise lock with a stainless steel mechanism, a 3/4 inch stainless steel throw, and UL/cUL fire rating up to 3 hours, built for heavy commercial traffic. The Codelocks CL2255 is an electronic tubular mortise latch rated medium duty in a brushed steel finish, a different service level for a door that sees light use. The Schlage LEBMB-ADD is a Grade 2 mobile-enabled mortise lock with push button and LED covering privacy, office and apartment functions with a 3 hour fire rating.
28) For a privacy or restroom door, what is chosen instead of the nexTouch NTM622 keypad lock?
A keypad on a restroom door is more control than the opening needs. The Cal-Royal NM8440 is a heavy duty Grade 1 privacy mortise lockset with a deadbolt for 1-3/4 inch doors, and the Hager 3840S is a Grade 1 privacy mortise lock with a 2-3/4 inch backset covering 1-3/4 inch to 2 inch doors, the same backset the nexTouch NTM622 uses. If an electronic privacy function is still wanted, the Schlage CO-100-MS-40-KP is a standalone electronic mortise lock in privacy function with a keypad reader, Grade 1, for 1-3/4 inch doors.
29) Which mortise locks match the 626 satin chrome finish of the nexTouch NTM622 for standardizing a facility?
The nexTouch NTM622 is offered in 605 bright brass, 613E dark oxidized satin bronze equivalent, 626 satin chrome, and BSP black suede powder coat. On the peer side, the Schlage L9092EU electric mortise lock with 03A trim is called out in 626, which lets an electrified opening and a keypad opening carry the same finish on a corridor run. For stainless openings, the Marks USA 5PDN paddleset and the TownSteel MRX-A-01 are satin stainless steel.
How fast can I get the Accentra AUR-NTM613-NR-626 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Accentra AUR-NTM613-NR-626 come with a warranty?
Absolutely. The Accentra AUR-NTM613-NR-626 is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Accentra AUR-NTM613-NR-626?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
Why buy the Accentra AUR-NTM613-NR-626 from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.

Product Reviews

  • 5
    Reliable Touchscreen Mortise Lock – Effortless Security

    Posted by Dylan on Nov 14th 2023

    This touchscreen mortise lock is a breeze to use; the touch feature is quick and responsive, enhancing security effortlessly. However, occasional software updates might be needed for optimal performance, which could be a slight inconvenience. Overall, it's a reliable and sleek solution for modern security needs.

!
