Adams Rite ADR31-0117-IP Exit Device Driver Board for Electric Latch Retraction Systems

Adams Rite ADR31-0117-IP Exit Device Driver Board for Electric Latch Retraction Systems

(No reviews yet) Write a Review

Model: 31-0117-IP

In Stock (leaves warehouse same day if ordered before 3pm ET)

$155.94
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Adams Rite ADR31-0117-IP Exit Device Driver Board for Electric Latch Retraction Systems

Electronic Control Board for 8000 Series Exit Device Electrification

The Adams Rite ADR31-0117-IP is an electronic control board designed for integration with electrified 8000 Series Exit Devices, enabling Electric Latch Retraction (EL/LR) and Motorized Latch Retraction (MLR) functionality. This control board manages electrical operations of the latch mechanism for remote unlocking and locking via access control components including card readers, keypads, fire alarms, power door operators, and maglocks. Compatible with door sizes 30"–48" and supports both solenoid-driven and motor-driven retraction systems for commercial storefront and aluminum glass door applications requiring panic hardware with remote control capabilities.

Professional Features & Benefits

  • ANSI/BHMA Grade 1 certified
  • Narrow stile aluminum door construction
  • Rim (8300/8400) and top-of-door mounted (8800/8700/EX88) configurations
  • Stainless steel touchbar / crossbar
  • UL 10C fire door listed
  • Panic-proof single-motion egress
  • Available with electric latch retraction
  • Compatible with 7800 electric strike
  • Multiple trim options and levers
  • Field-reversible handing

Technical Specifications

  • Door Application: Narrow stile aluminum doors
  • Configuration: Rim, mortise, top-of-door mounted
  • Egress: Single-motion panic proof
  • Compatible Strike: 7800 Series electric strike
  • Fire Rating: UL 10C listed
  • ANSI/BHMA: Grade 1
  • Handing: Field reversible

Installation & Operation

  1. Verify electrical requirements match available power supply. Confirm voltage (12VDC/24VDC for EL/LR or 24VDC for MLR) and current capacity including 16A inrush for LR and 2A regulated supply for MLR before proceeding.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the control board in the specified location within the 8000 Series Exit Device ensuring adequate clearance for wiring access, ventilation, and future service requirements.
  4. Route and connect wiring according to manufacturer wiring diagrams. Use appropriate wire gauge and connectors for the EL/LR or MLR application.
  5. Configure operational settings including fail-secure operation and any field tuning requirements for MLR systems per application requirements.
  6. Restore power and test all functions including normal latch retraction, fail-secure operation, and integration with connected access control systems.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Storefront Security Systems
  • Aluminum Glass Door Access Control
  • Life-Safety and Fire-Rated Exit Systems
  • Retail Loss Prevention with Remote Control
  • Educational Institution Safety Systems
  • Healthcare Facility Access Control
  • Emergency Exit Compliance Applications

Why Choose Adams Rite Quality?

Adams Rite exit device control boards deliver professional-grade reliability with factory calibrated performance and fail-secure operation for demanding commercial applications. The ADR31-0117-IP supports both solenoid and motor-driven systems with precise power management and comprehensive access control integration. Engineered for life-safety applications where dependable electronic control and remote functionality are essential.

Manufacturer Resources

Adams Rite Product Catalog

Product Specs

Subcategory:
Electronic Parts
Product Group:
Parts and Accessories
Product Category:
Exit Device Components
Department:
Door Hardware
Commercial/Residential:
Commercial
Product Subgroup:
Parts and Accessories
Product Type:
lectrical Board (for Electrified Latch Retraction)

Adams Rite 31-0117-IP – Frequently Asked Questions

1) Which Adams Rite exit devices does the ADR31-0117-IP driver board work with?
The ADR31-0117-IP is the electronic control board for electrified Adams Rite 8000 Series exit devices. That covers the rim configurations (8300 and 8400) and the top-of-door mounted devices (8800, 8700 and EX88). It drives both solenoid based Electric Latch Retraction (EL/LR) and Motorized Latch Retraction (MLR), so it is not tied to one retraction style. If the device on the door is not an 8000 Series Adams Rite, this board is not the part.
2) What power supply do I need for an Adams Rite 31-0117-IP latch retraction board?
It depends on which retraction system you are feeding. Latch retraction (EL/LR) runs on 12VDC or 24VDC, and the supply has to carry a 16A inrush. Motorized latch retraction (MLR) runs on 24VDC from a 2A regulated supply. Size the supply for the inrush figure, not the holding current, or the device will chatter or fail to pull the latch on an LR job.
3) Will the exit device unlock or stay locked if power drops with the 31-0117-IP board?
Fail secure. When power is lost the latch stays projected and the door stays locked from the outside. Free egress is not affected, since the 8000 Series touchbar releases mechanically in a single motion regardless of the electronics. If your life safety plan calls for the outside trim to release on power failure, this board's operation is not what you want.
4) Can I tie an Adams Rite electric latch retraction board into a card reader or fire alarm?
That is what it is for. The 31-0117-IP manages the latch electrically for remote lock and unlock, and it is intended to be driven by access control components: card readers, keypads, fire alarm interfaces, power door operators and maglocks. The board itself is the interface between that head end and the exit device motor or solenoid, so the access control side needs a dry contact or switched output plus a supply that meets the device's current draw.
5) Do I need a different Adams Rite board for motorized latch retraction than for solenoid latch retraction?
No. The 31-0117-IP supports both solenoid driven and motor driven retraction, so one board part number covers EL/LR and MLR devices. What changes is the supply and the setup: MLR wants 24VDC from a 2A regulated source and has field tuning to set during commissioning, while LR needs a supply that can deliver the 16A inrush.
6) Is the ADR31-0117-IP the exit device itself or just a component?
It is the electronic control board only, mounted inside an 8000 Series exit device. It does not include the touchbar, latch, rods or trim. Buy it when you are electrifying an existing 8000 Series device for remote latch retraction, or replacing a failed board in one that already has EL/LR or MLR.
7) How do I order the Adams Rite exit device driver board, and are there options to specify?
One part number, no options to configure: model 31-0117-IP. Handing is not a factor because the 8000 Series device it serves is field reversible, and the same board covers rim and top-of-door mounted configurations. What you specify separately is the power supply that matches your retraction type.
8) What electric strike pairs with an Adams Rite 8000 Series electrified exit device?
The 7800 Series electric strike is the stated match for the 8000 Series devices this board controls. On a rim application that gives you a coordinated latch and strike package rather than mixing brands at the frame.
