Aiphone Aiphone WB-CE - Wall Box with Caged Light and Emergency Lettering WB-CE

Aiphone WB-CE - Wall Box with Caged Light and Emergency Lettering

(No reviews yet) Write a Review

Model: WB-CE

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,452.00
$1,070.95
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

The Stainless Steel Wall mount box provides an easy-to-see heavy duty enclosure for an IS Series call station, used for Emergency and Assistance applications.

Installed in parking garages, airports, campuses, malls, and a wide variety of locales, these stations provide proper signage and specifications to meet ADA requirements. The Beacon is always lit for easy visibility; strobe flashes during emergency call-in.

ADA (28 CFR Part 36 section 4.4.1) states that an object must not protrude more than 4" if mounted higher than 27". Since these units have the potential to include a camera, mounting height restrictions are avoided with this streamline design, while call button mounting height guidelines can still be met.

Any Aiphone IX or IS RA series station can fit into the wall mount box.

FEATURES

  • Made of 12 gauge stainless steel
  • Caged beacon/strobe light on top
  • Emergency Lettering
  • ADA Compliant: 4″ depth to meet ADA requirements to allow mounting higher than 27″, and proper signage and call button mounting height

SPECIFICATIONS

  • Light/Strobe Power Source: DC 24V, use PS-2420UL
  • Blue Assistance lettering: ADA Compliant

Product Specs

Product Type:
Wall Box
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Subcategory:
Accessories
Commercial/Residential:
Commercial
Electronic:
Yes
Product Category:
Electronic Access Controls
Department:
Door Hardware

Aiphone WB-CE – Frequently Asked Questions

1) Which Aiphone call stations fit inside the WB-CE wall box?
The WB-CE stainless wall box accepts any Aiphone IX or IS RA series station. It is an enclosure only, so the call station itself is ordered separately.
2) Does the Aiphone WB-CE emergency call box meet ADA mounting requirements?
Yes. ADA (28 CFR Part 36 section 4.4.1) limits protruding objects to 4 inches when mounted above 27 inches, and the WB-CE is built to a 4 inch depth for exactly that reason. That lets you mount it high enough to clear the protrusion rule, including when a camera station is inside, while still hitting call button height guidelines. The blue Assistance lettering is also ADA compliant.
3) What power do I need to run the beacon and strobe on the Aiphone WB-CE?
The light and strobe run on DC 24V, and Aiphone specifies the PS-2420UL power supply for it. Budget that as a separate line item along with the station's own power. The beacon stays lit continuously for visibility and the strobe flashes when a call is placed.
4) Is the WB-CE tough enough for a parking garage or open campus tower?
It is a 12 gauge stainless steel enclosure built for exposed public locations such as parking garages, airports, campuses and malls. The beacon and strobe sit in a cage on top so the light is protected from impact and vandalism.
5) What is the difference between the Aiphone WB-CE and a plain assistance wall box?
The CE version carries Emergency lettering and a caged beacon/strobe on top. Choose it where the station is a true emergency phone that needs to be seen from a distance and needs a visual call indication. If your application is general assistance or information rather than emergency, you want the Assistance-lettered box instead, since the signage on the enclosure is fixed and cannot be changed in the field.
6) Can I use the WB-CE with a video intercom station that has a camera?
Yes. The design accounts for camera-equipped stations, and because the box keeps to a 4 inch depth you avoid the mounting height restriction that a deeper enclosure would create when mounting above 27 inches. Any IX or IS RA series station drops in.
7) Is the Aiphone WB-CE a surface mount or flush mount box?
It is a wall mount enclosure, mounted on the wall surface rather than recessed, which is why its 4 inch depth matters for the ADA protrusion limit. Typical placement is on a garage wall, column face, or building exterior where the emergency station needs to be visible.
