Aiphone Aiphone WB-HA - Wall Box with Hooded Light and Assistance Lettering WB-HA

Aiphone WB-HA - Wall Box with Hooded Light and Assistance Lettering

(No reviews yet) Write a Review

Model: WB-HA

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,870.00
$1,448.46
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

The Stainless Steel Wall mount box provides an easy-to-see heavy duty enclosure for an IS Series call station, used for Emergency and Assistance applications.

Installed in parking garages, airports, campuses, malls, and a wide variety of locales, these stations provide proper signage and specifications to meet ADA requirements. The Beacon is always lit for easy visibility; strobe flashes during emergency call-in.

ADA (28 CFR Part 36 section 4.4.1) states that an object must not protrude more than 4" if mounted higher than 27". Since these units have the potential to include a camera, mounting height restrictions are avoided with this streamline design, while call button mounting height guidelines can still be met.

Any Aiphone IX or IS RA series station can fit into the wall mount box.

FEATURES

  • Made of 12 gauge stainless steel
  • Fully enclosed beacon/strobe light on top
  • Assistance Lettering
  • ADA Compliant: 4″ depth to meet ADA requirements to allow mounting higher than 27″, and proper signage and call button mounting height

SPECIFICATIONS

  • Light/Strobe Power Source: DC 24V, use PS-2420UL
  • Blue Assistance lettering: ADA Compliant

Product Specs

Product Type:
Wall Box
Product Group:
Electronic Access Controls
Product Subgroup:
Parts and Accessories
Subcategory:
Accessories
Commercial/Residential:
Commercial
Electronic:
Yes
Product Category:
Electronic Access Controls
Department:
Door Hardware

Aiphone WB-HA – Frequently Asked Questions

1) Which Aiphone call stations fit inside the WB-HA wall box?
The WB-HA wall box accepts any Aiphone IX or IS RA series station. It is built as an enclosure for an IS Series call station used in emergency and assistance applications, so the station itself is a separate order.
2) Does the Aiphone WB-HA meet ADA protrusion rules for mounting above 27 inches?
Yes. The box is 4 inches deep, and ADA (28 CFR Part 36 section 4.4.1) allows no more than a 4 inch protrusion for objects mounted higher than 27 inches. That lets you mount the unit high enough for a camera view while still placing the call button at the ADA-guideline height. The blue Assistance lettering is also ADA compliant.
3) What power does the beacon and strobe on the WB-HA need?
The light and strobe run on DC 24V, and Aiphone specifies the PS-2420UL power supply for it. That supply is separate from whatever powers the call station you mount inside. The beacon stays lit continuously for visibility, and the strobe flashes when an emergency call is placed.
4) Is the Aiphone WB-HA tough enough for an outdoor parking garage or campus emergency phone?
It is made of 12 gauge stainless steel and is intended for exactly that duty. Aiphone lists parking garages, airports, campuses, and malls as typical locations. The beacon and strobe are fully enclosed in the hood on top, not exposed.
5) Does the WB-HA say Assistance or Emergency on the face?
The WB-HA carries blue Assistance lettering. If your specification calls for an Emergency-marked tower, this is not the right variant of the wall box, since the lettering is part of the enclosure rather than a field-applied label.
6) What do I still need to order besides the WB-HA to finish an assistance station?
Three things sit outside the box itself: the Aiphone IX or IS RA series call station that mounts into it, a 24V DC supply for the beacon and strobe (Aiphone calls out the PS-2420UL), and whatever system head end or power the station itself requires. The WB-HA is the enclosure with the hooded light and lettering.
7) Is the Aiphone WB-HA a residential product or a commercial one?
It is a commercial product. The wall box is a heavy duty stainless enclosure for assistance and emergency call stations in public facilities, not a residential intercom housing.
