Alarm Controls System Accessories - LD 1/4" LEDs
Product Features
• 1/4” lens with domed top and .280 black bezel
• LEDs mount in 1/4” hole
• Color options: green, yellow, bi-color, red flashing, blue, red
• LEDs have built-in resistor and operate on 12 or 24 VDC or VAC
• LEDs terminated with 6” x 20 gauge red and black leads
• Available individually or in packages of 10
Manufacturer Resources
Alarm Controls LEDs Catalog Page
Product Specs
- Subcategory:
- Parts and Accessories
- Commercial/Residential:
- Commercial
- Product Type:
- LEDs
- Product Group:
- Electronic Access Controls
- Product Subgroup:
- Sensors, Switches, Relays and Timers
- Product Category:
- Electronic Access Controls
- Department:
- Door Hardware
Alarm Controls LDB – Frequently Asked Questions
1) What size hole do the Alarm Controls LD LEDs mount in?
The LD series LEDs drop into a 1/4 inch hole. The lens is 1/4 inch with a domed top and a .280 black bezel, so drilling a clean quarter-inch hole in a faceplate, escutcheon, or control panel is all the prep needed.
2) Do these LEDs need a separate resistor on a 12V or 24V access control circuit?
No added resistor is needed. Each LD LED has a built-in resistor and runs on 12 or 24 volts, AC or DC, so it wires straight to the output of a door controller, power supply, or timer without any dropping resistor on the bench.
3) How do the Alarm Controls LD LEDs terminate, and can I splice them into existing wiring?
Each LED comes with 6 inch red and black 20 gauge leads already attached. Red is positive on DC installs. Six inches is short, so for anything beyond the immediate backbox plan on splicing to a run of 18 or 20 gauge to reach the controller.
4) Can I buy just one Alarm Controls LD LED, or do they only come in packs?
Both. The blue LDB is offered as an individual unit, while green (LDG), red (LDR), yellow (LDY), red flashing (LDR-F), and red/green bi-color (LDR-B) come in 10-packs. If you are standardizing indicators across a building, the 10-pack is how the colored units are sold.
5) Will these LEDs work on a 24VAC circuit, or only DC?
Either. The LD LEDs are rated for 12 or 24 volts on both AC and DC, so they can be tied to a 24VAC transformer feeding door equipment or to a 12VDC access control power supply without changing parts.
6) What are these 1/4 inch LEDs actually used for in a door hardware install?
They are panel indicators for electronic access control work: mounting into push plates, request-to-exit stations, key switch plates, and control panel faces to show lock or alarm status. Alarm Controls lists them as commercial-duty accessories in the same family as its switches, relays, and timers, so they pair with the door control gear rather than functioning on their own.
