Metallics DIA12V – Frequently Asked Questions
1) What bolt size does the Metallics DIA12V drop-in anchor take?
The DIA12V is a 1/2-13 drop-in anchor, so it accepts a 1/2 inch bolt or threaded rod with 13 threads per inch (standard 1/2 inch UNC coarse thread). The anchor is internally threaded, so the bolt is a separate item and is not supplied with the anchor.
2) Can I use the Metallics DIA12V in a hollow block wall or in drywall?
No. A drop-in anchor works by expanding against the sides of a drilled hole and needs solid base material, typically poured concrete. For hollow block, brick with voids, or drywall, use a toggle or sleeve type anchor instead. The DIA12V is a solid-base anchor only.
3) Why would an electrical contractor choose a drop-in anchor over a wedge anchor for overhead work?
A drop-in anchor is flush-set and internally threaded, so once it is placed in the concrete deck you can thread 1/2 inch rod or bolts in and out without disturbing the anchor. That suits overhead hanging of strut, trapeze supports, and cable tray, where rod lengths change and fixtures get removed. A wedge anchor leaves a fixed stud projecting and cannot be removed and re-used the same way.
4) Is the Metallics DIA12V anchor plated for corrosion resistance, and can it go outdoors?
It is steel with a zinc plating, which is a mild indoor corrosion coating. That is fine for dry interior concrete decks and walls. For exterior, wet, or chemically aggressive locations, specify a stainless anchor rather than zinc-plated steel.
5) How many anchors come in a box of Metallics DIA12V?
They ship 500 pieces per package. That is a bulk production quantity, which is what you want for a job laying out repetitive hanger points across a deck rather than a handful of one-off mounts.
6) What is the exact part number to order this Metallics 1/2 inch drop-in anchor?
Order Metallics part number DIA12V. That designation covers the 1/2-13 zinc-plated steel drop-in anchor in the 500 piece pack.
