Metallics JDIA12L Anchors 1/2-13 Drop-In Ancr Lip St-zn (Jar 50)

The JDIA12L takes a 1/2-13 bolt or threaded rod, meaning 1/2 inch diameter with 13 threads per inch, which is the standard UNC coarse thread for that diameter. You set the anchor in concrete, then thread your 1/2-13 rod or bolt into it. The anchor supplies the internal threads only, so bolts, rod, nuts, and washers are separate.

It is a zinc plated steel anchor, which is a mild corrosion coating meant for dry interior concrete, not wet or exterior exposure. For outdoor decks, parking structures, wash-down areas, or anywhere chlorides are present, go to a stainless drop-in or a hot-dip galvanized anchor instead of zinc plated.

Fifty anchors per jar. The jar pack is how this 1/2-13 lipped drop-in anchor is sold, so a quantity of one is 50 pieces, not a single anchor. Worth knowing when you are pricing out a strut or hanger rod layout and counting drops.

The lip is a flange at the top of the anchor body that bears on the concrete surface and stops the anchor dropping below the face of the hole when you set it. It also gives you a visible reference that the anchor is seated flush. Non-lipped drop-ins sit fully in the hole and are set flush by drilling to depth instead. Pick the lipped version when you want the anchor top registered at the surface.

It is the common overhead attachment for 1/2 inch threaded rod: trapeze hangers for conduit racks, cable tray supports, strut, and bus or equipment hung off a concrete deck. You drill the slab, set the anchor flush, then thread rod up into it. Metallics carries it as part of its electrical fastener line.

No. Once the internal plug is driven, the expansion is permanent and the anchor body stays in the concrete. You can back the bolt out and reuse the threads, but the anchor itself cannot be pulled or relocated. Mark and verify your layout before setting, and order the 50-count jar with some spare for misses.
