Metallics WAKJ8QD Anchor 1/4" Light Duty Green Collarless Vinyl Wall Anchor Jar w/ 10 x 1 Quadrive 5/16 Hex Head Screw

Drill 1/4 inch. The WAKJ8QD is a 1/4 inch vinyl wall anchor, and plastic anchors of this style are sized by the hole they seat in, so a 1/4 inch masonry or twist bit matches it. Set the anchor flush, then drive the included #10 x 1 inch screw to expand it against the hole wall.

Screws are in the jar. Each WAKJ8QD jar pairs the green 1/4 inch vinyl anchors with #10 x 1 inch Quadrive hex head screws with a 5/16 inch hex, so you are not sourcing fasteners separately. That matters for an MRO cart or a service van, where a mismatched screw diameter is what keeps a plastic anchor from gripping.

No. It is specified as a light duty anchor, which puts it in the range of device plates, low voltage brackets, cable clips, trim, and signage. Hanging a loaded box, panel, or anything with real pull-out or shear load calls for a toggle, a self-drilling metal anchor, or a mechanical masonry anchor instead.

Vinyl anchors like the WAKJ8QD expand by compression against the sides of the hole, so they hold best in a solid substrate: concrete, block, brick, plaster, or tile backer. In hollow drywall there is nothing for the body to bear against once it passes the paper, so a toggle or a self-drilling drywall anchor is the right call there.

A 5/16 inch hex driver or nut setter is the quickest route, since the screws are hex head. They are also Quadrive, so a square drive bit seats in the recess if you would rather drive them with an impact driver bit than a socket. Either one works, which is why electricians like this screw for overhead box and strap work.

A collarless anchor has no flange at the top, so the whole body can go below the surface of the wall. Use the WAKJ8QD where the item being mounted has to sit dead flat, or where the hole is slightly oversized and a collar would hold the fixture off the wall. A collared anchor is the better pick when the hole may be ragged and you want the lip to bridge it and stop the anchor from pushing through.

Color is the size code. Vinyl anchor lines run color by diameter so a crew can grab the right one out of a bin without measuring, and green on the Metallics WAKJ8QD is the 1/4 inch light duty size. If your other jars are a different color, they are a different diameter and the screws will not interchange.

Nothing to configure. WAKJ8QD is sold as a single item, the jar of 1/4 inch green collarless vinyl anchors with matching #10 x 1 inch screws, so ordering by that part number gets you one combination with no options to select.
