Anchors 1/2 x 4" Hx Hd Lg Dia CS SS (Jar 25)
Manufacturer Resources
Product Specs
- Division:
- Electrical H1
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Anchors
Metallics LCS1240SS – Frequently Asked Questions
1) Do I need a hole drilled, and what drill bit size for a 1/2 inch Metallics LCS1240SS anchor?
It's a drilled-in concrete anchor, not a self-drilling screw, so you drill first and set it through the fixture. For a 1/2 inch large diameter hex head anchor of this style the hole is drilled with a 1/2 inch carbide bit, matched to the anchor diameter, and the hole needs to run deeper than the embedment you want so cuttings have somewhere to go. At 4 inches of overall length, subtract the thickness of what you are fastening to know how much embedment you actually get.
2) Can the Metallics LCS1240SS be used outdoors or in a damp location?
The LCS1240SS is a stainless steel version of the large diameter hex head anchor, which is what you want for exterior pads, rooftop equipment curbs, parking structures, or wash-down areas where a plain carbon steel anchor would rust at the head. For dry interior slab work the plain steel version of the same size is the usual choice.
3) What tool drives these hex head anchors?
Hex head, so it drives with a socket on an impact wrench or a ratchet, not a bit driver. No nut, washer, or expansion sleeve to handle, which is why electricians favor this style for hanging strut, trapeze supports, and panel backing to concrete.
4) How many Metallics LCS1240SS anchors do I need to order for a job with 60 anchor points?
Packed 25 per jar, so 60 points takes three jars (75 anchors) with 15 spares. Buying by the jar is worth planning around on larger installs, since anchors get lost in the hole or spin out in soft concrete and you want the overage on the truck rather than a second trip.
