Metallics J1512SS Anchors Sprg Wing TogBt Rh Sl 1/4" Trd 20 Lgt 4" SS (Jar 50)

The J1512SS is a spring wing toggle bolt with a 1/4 inch diameter screw, 20 threads per inch, and a 4 inch length, with a round head slotted screw. The 1/4-20 thread is a standard coarse machine screw thread, so any 1/4-20 nut, washer, or accessory will mate with it. It ships as a jar of 50.

That is exactly what a spring wing toggle is for. The wings fold flat to pass through a drilled hole, then spring open behind the wall and spread the load across the back face of the panel, so it grips where there is no stud or solid backing. The J1512SS gives you 4 inches of 1/4-20 screw length, which covers the wall thickness plus whatever you are hanging. If the cavity behind the wall is too shallow for the wings to open, a toggle is the wrong choice and you want a solid-wall anchor instead.

Stainless steel, both the bolt and the wings. That makes the J1512SS a reasonable pick for damp, washdown, coastal, or unheated spaces where a plain zinc-plated toggle would rust and lose holding value, and for jobs where you want to avoid galvanic trouble against stainless strut or stainless conduit clamps.

The hole has to clear the folded wings, not the 1/4 inch screw, so it is considerably larger than the bolt diameter. Fold the wing assembly flat against the screw on one of the J1512SS toggles and size the bit to that, then drill the wall and test-fit before you commit to the fixture layout. Drilling to the screw diameter is the most common reason a toggle will not pass through the panel.

It is an electrical fastener, and the 1/4-20 thread is the size most conduit straps, strut fittings, box brackets, and fixture hangers are drilled for, so it lands in the same holes those accessories use. On a ceiling, remember the load is hanging from the wings against the back of the panel, so it depends entirely on the panel itself holding, not on the anchor.

The J1512SS is packed 50 to a jar, which is the format for shops doing repeat work rather than a single fix. Each toggle is one-time use in the wall: pull the screw and the wing nut drops into the cavity, so plan on a fresh anchor at every relocation and keep the jar count against the number of points on the job, not the number of fixtures.

The J1512SS uses a round head with a slotted drive. The rounded profile sits proud of the surface with a broad bearing face, and the slot drives with a flat blade screwdriver, which suits hand work in tight overhead positions where you cannot get a driver square on the fastener. If you are running these with an impact or need higher torque, a hex head is the easier drive; the holding value in the wall is the same either way because that comes from the wings.
