Arrow 001 Standard Straight Screw-On Cam Replacement Part for Mechanical Lock Cylinders

Arrow 001 Standard Straight Screw-On Cam Replacement Part for Mechanical Lock Cylinders

(No reviews yet) Write a Review

Model: 001

In Stock (leaves warehouse same day if ordered before 3pm ET)

$18.27
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Arrow 001 Standard Straight Screw-On Cam Replacement Part for Mechanical Lock Cylinders

The Arrow 001 Standard Straight Screw-On Cam is a genuine Arrow replacement component designed for use with compatible Arrow mechanical lock cylinders in commercial door hardware applications. This screw-on cam features a standard straight profile, ensuring precise fit and reliable operation when replacing worn or damaged cam components. Engineered for commercial-grade performance, this part maintains the operational integrity of Arrow cylinder-based locking systems.

Key Features

  • Standard Straight Profile: Features a standard straight cam design for accurate alignment and dependable engagement with compatible Arrow cylinder assemblies.
  • Screw-On Attachment: Screw-on mounting style allows for secure, stable installation on compatible Arrow lock cylinders without specialized tooling.
  • Genuine Arrow Component: Authentic Arrow replacement part manufactured to original specifications, ensuring compatibility and consistent performance.
  • Commercial Application: Designed and rated for commercial door hardware environments where dependable cylinder operation is essential.
  • Direct Replacement Design: Drop-in replacement that restores cylinder function without requiring full assembly replacement, reducing maintenance costs and downtime.
  • Cylinder Parts Compatibility: Compatible with Arrow mechanical lock cylinder applications as part of the Arrow Parts product line for commercial installations.

Technical Specifications

  • Department: Door Hardware
  • Product Category: Mechanical Locks
  • Product Group: Parts and Accessories
  • Subcategory: Parts and Accessories
  • Product Subgroup: Parts and Accessories
  • Product Type: Cylinders
  • Parts and Accessories Type: Replacement Parts
  • Commercial/Residential: Commercial
  • Product Model: 001
  • Features: Arrow Parts

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Arrow 001?

Arrow mechanical lock components are engineered to meet the demands of commercial door hardware applications, delivering consistent fit and function as genuine replacement parts. The Arrow 001 Standard Straight Screw-On Cam upholds the operational reliability of Arrow cylinder-based locking systems, making it the trusted choice for facility managers and professional installers seeking dependable, manufacturer-approved parts for commercial environments.

Manufacturer Resources

Arrow Express Catalog

Product Specs

Department:
Door Hardware
Product Category:
Mechanical Locks
Product Group:
Parts and Accessories
Subcategory:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Cylinders
Parts and Accessories Type:
Replacement Parts
Commercial/Residential:
Commercial
Product Model:
001
Features:
Arrow Parts

Arrow 001 – Frequently Asked Questions

1) Will the Arrow 001 cam fit a Schlage, Corbin Russwin, or BEST cylinder?
No. The 001 is a genuine Arrow part made to Arrow's cylinder specification and is intended for compatible Arrow mechanical lock cylinders. Cam shape, screw hole spacing, and tail geometry differ by manufacturer, so don't plan on it landing on another brand's plug. If you are working on a Corbin Russwin mortise cylinder, order that cam configuration with the cylinder instead, for example the Corbin Russwin 1000 Series 1-1/2 inch mortise cylinder supplied with an A02 straight cam.
2) Is a straight cam the right one for my lock, or do I need a cloverleaf cam?
A straight cam is the flat, single-tab type used on most standard mortise lock bodies. Cloverleaf cams are multi-lobed and are called for by certain lock bodies, for instance Corbin Russwin lists an A01 cloverleaf cam on its 1070 housing and on the 1080 LFIC cylinder used with Schlage L9000 mortise locks. Pull the existing cam off your cylinder and match the profile before ordering; the Arrow 001 is the standard straight profile only.
3) Does the Arrow 001 include a cylinder, keys, or a keyway?
No. The 001 is the cam only, a replacement component for a cylinder you already have. It carries no keying, no keyway, and no plug. If you need a complete keyed cylinder rather than a part, look at a full cylinder such as the Kaba Ilco 1539 Series key-in-knob/lever universal cylinder or the Schlage 20-021 rim cylinder, which ships with 2 keys.
4) Will the Arrow 001 cam work on a rim cylinder?
No. The Arrow 001 is a screw-on cam for Arrow mechanical lock cylinders, and rim cylinders drive a tailpiece rather than a cam of this type. For rim applications, the Schlage 20-021 is a 6-pin rim cylinder with a vertical tailpiece cam and the Schlage 20-022 is the same rim cylinder with a horizontal tailpiece cam; the Corbin Russwin 3070-178 is a 6-pin rim cylinder housing with a 1-7/8 inch tailpiece.
5) Is there a straight cam mortise cylinder I can order complete instead of just replacing the cam?
The Arrow 001 is a standard straight screw-on cam sold as a replacement part on its own, so it restores an existing Arrow cylinder rather than supplying one. If you would rather put in a whole cylinder already fitted with a straight cam, the Corbin Russwin CR1000-112 is a 1000 Series Grade 1 mortise cylinder, 1-1/2 inch length, furnished with an A02 straight cam.
6) My mortise lock needs a cloverleaf cam, not a straight one. What should I order?
The Arrow 001 is a standard straight profile cam, so it is the wrong shape for a housing that calls for a cloverleaf. The Corbin Russwin CR1070-114-A01 is a 1-1/4 inch 6-pin mortise housing supplied with an A01 cloverleaf cam, and the CR1080-112-A01 is a 1-1/2 inch LFIC 6-pin mortise cylinder with an A01 cloverleaf cam for Schlage L9000 mortise locks.
7) The Arrow cylinder body itself is worn, not just the cam. What replaces it in an Arrow JL interconnected lock?
A cam like the Arrow 001 only restores the drive component, so a damaged cylinder body needs a cylinder. The Medeco 1065140 is a 5-pin retrofit cylinder listed for the Arrow JL interconnected lock as well as Emtek handleset and deadbolt outside cylinder use.
8) Do I need special tools to change the cam on an Arrow cylinder?
No specialized tooling. The 001 mounts with a screw, so a correctly sized screwdriver and a bench to lay the cylinder on is the whole job. Removing the cylinder from the lock body is the bigger part of the work than swapping the cam itself.
9) My Arrow mortise cylinder is worn out, not just the cam. What should I replace it with?
If the plug or pins are the problem, the cam won't fix it and you want a whole cylinder. Options we carry include the Adams Rite 4036 Grade 1 five-pin mortise cylinder, the Detex MC65 six-pin mortise cylinder in Schlage C keyway, or a Corbin Russwin 1000 Series 1-1/2 inch mortise cylinder. Keep the 001 on the shelf for the case where only the cam is chewed up.
10) If I want to move to interchangeable cores instead of repairing fixed cylinders, what are the options?
The Arrow 001 cam is a repair part that keeps an existing fixed cylinder in service. To go to interchangeable cores instead, the BEST 1C5 is a standard 5-pin cylinder core, the BEST 1CB is a Peaks 150 Series interchangeable core cylinder, and the BEST 1CDF is a drill resistant patented 7-pin brass interchangeable core in the 150 Series. On the Schlage side, the 20-057 is a 6-pin FSIC rim cylinder with a convertible tailpiece cam and the 20-057-C is a full size interchangeable core in the C keyway, 643E Aged Bronze.
11) I need a cam replacement for a key-in-knob or key-in-lever cylinder. Does the Arrow 001 cover that?
The Arrow 001 is a straight screw-on cam for Arrow mechanical lock cylinders in commercial door hardware, not a knob or lever cylinder assembly. For knob and lever cylinder replacement, the Kaba Ilco 1539 is a key-in-knob and lever universal cylinder, the 1579 is a knob and lever cylinder for Sargent, and the 1599 is a key-in-knob replacement cylinder. The Falcon A23161-05 G is a key-in-lever cylinder in the RU/T Series 6-pin G keyway, keyed different with two cut keys.
12) For an aluminum storefront with an Adams Rite deadlock, does a cam like the Arrow 001 apply?
No. The Arrow 001 cam serves Arrow mechanical lock cylinders. For Adams Rite storefront deadlocks, the 4024 cylinder pull mounts with a trim plate and the 4025 five pin tumbler cylinder pull uses through-screws, both for the MS1847 deadlock/deadlatch; the 4026 five pin tumbler cylinder pull is for the 5017 wood door deadlock/deadlatch. The Adams Rite 4036 is a five-pin mortise cylinder, Grade 1, with a 1/2 inch minimum door thickness.
13) What looks like an alternative to the Arrow 001 but will not function as a working cam?
The BEST 12E Series dummy rim cylinder has a 1-5/32 inch diameter and is a dummy, so it provides no operating function at all. The Emtek CY4 cylinder is sold each as a parts item but is a cylinder rather than a cam. The Arrow 001 itself is the straight screw-on cam that drives the lock from a compatible Arrow cylinder.
14) For a deadbolt cylinder replacement, is the Arrow 001 the right part?
The Arrow 001 is a cam, so it does not replace a deadbolt cylinder. The Kaba Ilco 1549 is a key-in-deadbolt cylinder with a deadbolt function. For deadbolt and handleset cylinders, the Medeco 1012040 is a 6-pin lazy motion rim cylinder for Kwikset single cylinder deadbolts, the Medeco 1075127 is a 5-pin rim type lazy motion single cylinder for handlesets and deadbolts, and the Medeco 1065244 is a 5-pin rim lazy motion cylinder with an Emtek tailpiece.
15) I am standardizing mortise cylinders on a Schlage C keyway. What takes the place of repairing Arrow cylinders?
Repairing with the Arrow 001 cam keeps the existing Arrow cylinders in place. If you are standardizing on a Schlage C keyway mortise cylinder instead, the Detex MC65 is a 1-1/8 inch 6-pin commercial grade mortise cylinder in the Schlage C keyway.
16) Is the Arrow 001 cam suitable for commercial buildings or is it a residential part?
It is a commercial part. Arrow lists the 001 for commercial door hardware use, and it turns up in offices, schools, hospitals, retail, warehouses, multi-tenant residential, and government buildings where Arrow cylinder locks are already standardized. For a facility running Arrow cylinders across many doors, stocking the cam is a low-cost way to keep openings in service.
17) Is there an interchangeable core option instead of replacing cams and cylinders on Arrow hardware?
If the goal is to stop servicing individual cylinders, an interchangeable core system is the other direction to go. We carry BEST 1C Series standard 5-pin cores, the BEST 1CB 150 Series interchangeable core cylinder, and Schlage 20-057 FSIC rim cylinders with convertible tailpiece cams. Those let you pull and rekey a core in seconds, whereas a screw-on cam repair like the Arrow 001 keeps existing conventional Arrow cylinders working as-is.
How fast can I get the Arrow 001 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
