Arrow AM20-305 Faceplate Replacement Part for AM and BM Series Locks

Arrow AM20-305 Faceplate Replacement Part for AM and BM Series Locks

(No reviews yet) Write a Review

Model: AM20-305 26D

In Stock (leaves warehouse same day if ordered before 3pm ET)

$49.66
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Arrow AM20-305 Faceplate Replacement Part for AM and BM Series Locks

The Arrow AM20-305 is a commercial-grade replacement faceplate designed for use with Arrow AM and BM Series mechanical locks. As an authorized Arrow replacement part, this mounting plate ensures proper fit and finish for compatible lock bodies, maintaining the integrity and function of the original hardware. Ideal for facility maintenance professionals and locksmiths servicing Arrow lock installations in commercial environments.

Key Features

  • Genuine Arrow Replacement Part: Purpose-built as an Arrow OEM component, ensuring precise compatibility and consistent performance with AM and BM Series lock assemblies.
  • AM and BM Series Compatibility: Specifically designed for Arrow AM and BM Series mechanical locks, providing a direct-fit replacement solution for serviceable hardware.
  • Commercial-Grade Construction: Engineered to meet the demands of commercial door hardware applications, supporting long-term reliability in high-use environments.
  • Mounting Plate Design: Functions as the faceplate component of the lock assembly, providing a clean, finished appearance and proper structural interface between the lock body and door surface.
  • Simplified Maintenance: Allows technicians to restore lock function and appearance without full lock replacement, reducing downtime and service costs.

Technical Specifications

  • Department: Door Hardware
  • Product Category: Mechanical Locks
  • Product Group: Parts and Accessories
  • Subcategory: Parts and Accessories
  • Product Subgroup: Parts and Accessories
  • Product Type: Mounting Plates
  • Parts and Accessories Type: Replacement Parts
  • Commercial/Residential: Commercial
  • Product Model: AM20-305
  • Features: Arrow Parts

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Arrow AM20-305?

Arrow has long been recognized for producing reliable commercial door hardware, and the AM20-305 Faceplate upholds that standard as a genuine replacement component engineered for direct compatibility with AM and BM Series lock bodies. Sourcing an authentic Arrow part ensures proper fit, consistent finish, and maintained lock performance, critical considerations for commercial facility managers and service professionals who depend on dependable, long-lasting hardware solutions.

Manufacturer Resources

Arrow Express Catalog

Product Specs

Department:
Door Hardware
Product Category:
Mechanical Locks
Product Group:
Parts and Accessories
Subcategory:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Mounting Plates
Parts and Accessories Type:
Replacement Parts
Commercial/Residential:
Commercial
Product Model:
AM20-305
Features:
Arrow Parts

Arrow AM20-305 26D – Frequently Asked Questions

1) Which series do I pick for the Arrow faceplate, BM20, BM22 or BM23?
Pick the series that matches the lock body already in the door. The AM20-305 faceplate is offered configured for BM20, BM22 and BM23 lock bodies, and the plate is the structural interface between the lock case and the door face, so the series selection has to track the case you are servicing. Read the series stamp on the existing lock before ordering.
2) What finishes can I get the Arrow AM20-305 faceplate in to match my other doors?
Seven finishes across the range: 605 bright brass, 606 satin brass, 612 satin bronze, 613 satin bronze oil-rubbed, 625 bright chrome, 626 satin chrome, and 630 satin stainless steel. Not every finish is offered on every series, though: 630 satin stainless is offered on BM22, while BM20 and BM23 cover the other six. Match the BHMA finish number on your existing trim and the plate will blend with the rest of the opening.
3) Can I just replace the faceplate instead of the whole Arrow lock?
That is the point of the part. Swapping the AM20-305 restores the appearance and the mounting interface without pulling and replacing the lock body, which keeps a scarred or wrong-finish opening in service with a short turn on site. If the lock case itself is failing mechanically, the plate will not fix that.
4) Will an aftermarket faceplate work on an Arrow BM Series lock?
Stick with the Arrow part. The AM20-305 is built as an Arrow OEM component specifically for AM and BM Series lock assemblies, so the plate profile, fastener locations and finish match the original hardware. A generic plate is not a direct fit for these cases.
5) Is the AM20-305 the lock itself or just the cover plate?
Just the plate. It is the faceplate that finishes the lock installation and sits between the lock body and the door face. You still need a functioning AM or BM Series lock case behind it; this part does not include the lock, cylinder or levers.
6) Is the Arrow AM20-305 faceplate rated for commercial traffic?
It is a commercial-grade component, catalogued for commercial rather than residential use, and Arrow lists it for offices, schools, healthcare, retail, warehouse, multi-tenant residential and municipal buildings. Facility crews standardizing on Arrow AM/BM locks typically stock a couple of finishes for exactly this reason.
