Arrow CH-44-201 Tailpiece Pack for H Series, RK Series and SFIC 6 & 7 Pin Cylinders

(No reviews yet) Write a Review

Model: CH-44-201

In Stock (leaves warehouse same day if ordered before 3pm ET)

$18.92
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Arrow CH-44-201 Tailpiece Pack for H Series, RK Series and SFIC 6 & 7 Pin Cylinders

The Arrow CH-44-201 Tailpiece Pack is a genuine replacement component designed for use with Arrow H Series locks (except 15 & 19 Functions), RK Series locks, and SFIC 6-pin and 7-pin cylinder configurations. This commercial-grade tailpiece pack ensures proper cylinder-to-lock body engagement, restoring correct operation in compatible Arrow locking hardware. Engineered for professional installation, this part supports a wide range of Arrow cylinder applications in demanding commercial environments.

Key Features

  • Broad Series Compatibility: Designed for Arrow H Series locks (except 15 & 19 Functions), RK Series, and SFIC 6-pin and 7-pin cylinder configurations for versatile serviceability.
  • SFIC 6 & 7 Pin Support: Compatible with both 6-pin and 7-pin Small Format Interchangeable Core (SFIC) cylinders, accommodating a wide range of keying systems.
  • Genuine Arrow Replacement Part: An authentic Arrow component ensuring correct fit, function, and compatibility with the original lock hardware.
  • Commercial-Grade Quality: Rated for commercial applications, providing reliable performance in high-use institutional and commercial environments.
  • Professional-Grade Component: Engineered to restore proper cylinder-to-lock body engagement, maintaining the integrity of Arrow locking systems.

Technical Specifications

  • Department: Door Hardware
  • Product Category: Mechanical Locks
  • Product Group: Parts and Accessories
  • Subcategory: Parts and Accessories
  • Product Subgroup: Parts and Accessories
  • Product Type: Cylinders
  • Parts and Accessories Type: Replacement Parts
  • Commercial/Residential: Commercial
  • Product Model: CH-44-201
  • Features: Arrow Parts

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties

Why Arrow CH-44-201?

Arrow lock components are engineered to exacting commercial standards, ensuring compatibility and reliable operation across the H Series, RK Series, and SFIC cylinder platforms. The CH-44-201 Tailpiece Pack delivers genuine OEM-level fit and function, making it the dependable choice for locksmiths and facility maintenance professionals servicing Arrow hardware in high-demand commercial settings.

Manufacturer Resources

Arrow Express Catalog

Product Specs

Department:
Door Hardware
Product Category:
Mechanical Locks
Product Group:
Parts and Accessories
Subcategory:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Cylinders
Parts and Accessories Type:
Replacement Parts
Commercial/Residential:
Commercial
Product Model:
CH-44-201
Features:
Arrow Parts

Arrow CH-44-201 – Frequently Asked Questions

1) Will the Arrow CH-44-201 tailpiece work with my Arrow H Series lock?
Yes, with one exception. The CH-44-201 tailpiece pack covers Arrow H Series locks except the 15 and 19 functions. If you are servicing an H Series 15 or 19, this is the wrong part. It also covers Arrow RK Series locks.
2) Does this Arrow tailpiece pack fit both 6-pin and 7-pin small format interchangeable cores?
It does. The CH-44-201 pack is made for SFIC 6-pin and 7-pin cylinder configurations, so the same part serves either core length in an Arrow H or RK Series application. That matters on facilities keyed with 7-pin masterkey systems, where the core stack is deeper than standard 6-pin.
3) My Arrow lock turns with the key but the latch doesn't retract. Is the tailpiece the part I need?
That symptom is exactly what the CH-44-201 addresses. The tailpiece is the flat driver that carries cylinder rotation into the lock body, so a worn, bent, or wrong-length tailpiece lets the key turn freely while the retractor never moves. Replacing it restores cylinder-to-lock engagement on Arrow H Series (except 15 and 19 functions) and RK Series hardware.
4) Is the Arrow CH-44-201 tailpiece pack a substitute for a complete replacement cylinder?
No. The Arrow CH-44-201 is a replacement tailpiece pack that restores cylinder-to-lock-body engagement in Arrow H Series locks (except 15 and 19 functions), RK Series locks, and SFIC 6-pin and 7-pin cylinders. If the cylinder itself is worn, damaged, or being rekeyed to a different keyway, you need a cylinder instead - for example the BEST 1C Series standard 5-pin cylinder core, or the Schlage 20-057 6-pin FSIC rim cylinder with convertible tailpiece cam. Those are keyed cylinders; the CH-44-201 supplies only the tailpiece hardware.
5) I need to service an Arrow H Series 15 function lock - will the CH-44-201 work?
No. The CH-44-201 tailpiece pack covers Arrow H Series locks except the 15 and 19 functions, along with RK Series and SFIC 6-pin and 7-pin cylinders. For those two excluded functions you will need the tailpiece specified for that function rather than this pack. If the goal is instead to retrofit an Arrow interconnected lock with a high-security cylinder, the Medeco 1065140 is a 5-pin retrofit cylinder for the Arrow JL interconnected lock.
6) Is the CH-44-201 a genuine Arrow part or an aftermarket copy?
Genuine Arrow. The CH-44-201 is an authentic Arrow replacement component, catalogued for commercial use, so the tailpiece geometry matches the original lock hardware rather than approximating it.
7) Is the CH-44-201 tailpiece pack suitable for a school or hospital keying system, or is it residential grade?
It is a commercial part, intended for institutional and high-use settings including educational facilities, healthcare, government buildings and multi-tenant residential properties. For a facility standardized on Arrow H or RK Series locks with SFIC cores, it is the service part to stock for cylinder swaps.
8) Can I use a Medeco retrofit cylinder in an Arrow lock instead of replacing the tailpiece?
For some Arrow platforms, yes. The Medeco 1065140 is a 5-pin retrofit cylinder listed for the Arrow JL interconnected lock. That is a different platform from the H and RK Series the CH-44-201 serves, so it is a re-cylinder path rather than a substitute for this tailpiece pack. If your opening is H or RK Series with an SFIC core, stay with the CH-44-201.
9) I'm converting Arrow locks from conventional cylinders to interchangeable cores. What else do I need besides the core?
Plan on the tailpiece as well. Moving an Arrow H Series (except 15 and 19 functions) or RK Series lock to an SFIC 6-pin or 7-pin core changes the drive at the back of the cylinder, and the CH-44-201 pack supplies the tailpiece that engages the lock body. If you are standardizing a whole building on interchangeable cores, buy the tailpiece packs alongside the cores rather than discovering the shortfall mid-install.
10) Can I use the Arrow CH-44-201 on a rim cylinder for an exit device?
The CH-44-201 pack is specified for Arrow H Series locks (except 15 and 19 functions), RK Series locks, and SFIC 6-pin and 7-pin cylinders, not for rim cylinder housings. Rim applications use a tailpiece matched to the housing - the Schlage 20-021 rim cylinder carries a vertical tailpiece cam and the 20-022 a horizontal tailpiece cam, and the Corbin Russwin 3070 6-pin rim housing is supplied with a 1-7/8 inch tailpiece. Confirm the device's required orientation and length before ordering rim parts.
11) What is the difference between a tailpiece pack like the Arrow CH-44-201 and a cam like the one on a Corbin Russwin mortise cylinder?
A tailpiece is a flat blade that projects behind a key-in-knob, key-in-lever, or interchangeable core cylinder and drives the lock mechanism directly; the CH-44-201 pack supplies those blades for Arrow H Series, RK Series, and SFIC 6- and 7-pin cylinders. A cam is the rotating plate on the back of a mortise cylinder - the Corbin Russwin 1000 Series 1-1/2 inch mortise cylinder uses an A02 straight cam, and the 1070 Series 1-1/4 inch 6-pin housing uses an A01 cloverleaf cam. They are not interchangeable parts; the cylinder type dictates which one applies.
12) If I am replacing an Arrow knob cylinder in a lock rather than just the tailpiece, what universal cylinders are options?
For a full cylinder swap in key-in-knob or key-in-lever hardware, the Kaba Ilco 1539 Series is a key-in-knob and lever universal cylinder and the 1599 Series is a key-in-knob replacement cylinder; the 1579 Series is the knob and lever cylinder for Sargent hardware. The Arrow CH-44-201 does not cover that - it supplies tailpieces to restore engagement between an existing Arrow H Series, RK Series, or SFIC 6- or 7-pin cylinder and the lock body.
13) We are standardizing a facility on interchangeable cores - does the Arrow CH-44-201 support 7-pin cores?
Yes. The CH-44-201 tailpiece pack supports both 6-pin and 7-pin small format interchangeable core configurations, so a single pack covers Arrow SFIC work across either pin count as well as H Series (except 15 and 19 functions) and RK Series locks. If the standardization also calls for the cores themselves, the BEST 1CDF is a drill-resistant patented interchangeable core 7-pin brass 150 Series core and the BEST 1CB is a Peaks 150 Series interchangeable core cylinder.
14) Will the Arrow CH-44-201 help me service an aluminum storefront deadlock?
No. The CH-44-201 is an Arrow part for H Series locks (except 15 and 19 functions), RK Series locks, and SFIC 6- and 7-pin cylinders. Storefront deadlocks use their own cylinder hardware - the Adams Rite 4024 cylinder pull with trim plate mounting and the 4025 five-pin cylinder pull with through-screws are both for the MS1847 deadlock/deadlatch, and the Adams Rite 4036 is a Grade 1 five-pin mortise cylinder with a 1/2 inch minimum door thickness.
15) Is a lazy-motion tailpiece cylinder the same thing as the Arrow CH-44-201 tailpiece pack?
They serve different purposes. Lazy-motion cylinders are complete keyed cylinders whose tailpiece has built-in play for residential handleset and deadbolt linkages - examples are the Medeco 1075127 5-pin rim type lazy motion single cylinder for handlesets and deadbolts, the Medeco 1012040 6-pin lazy motion rim cylinder for Kwikset single cylinder deadbolts, and the Medeco 1065244 5-pin lazy motion rim cylinder with an Emtek tailpiece. The Arrow CH-44-201 is a commercial replacement tailpiece pack for Arrow H Series, RK Series, and SFIC 6- and 7-pin cylinders, supplied without a cylinder.
16) For a key-in-lever cylinder replacement instead of a tailpiece, what else is comparable?
The Falcon A23161-05 G is a key-in-lever cylinder for RU/T Series hardware with a 6-pin G keyway, keyed different and supplied with two cut keys, and the Detex MC65 is a 1-1/8 inch 6-pin commercial mortise cylinder with a Schlage C keyway. Both are complete keyed cylinders. The Arrow CH-44-201 instead supplies the tailpiece hardware that couples an existing Arrow H Series, RK Series, or SFIC 6- or 7-pin cylinder to the lock body.
