Arrow G70 Deadlatch Replacement Part for GL Series Locksets with 2-1/4" x Front

(No reviews yet) Write a Review

Model: AR-G70
$31.40
$28.98

In Stock (leaves warehouse same day if ordered before 3pm ET)

$31.40
$28.98
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Arrow G70 Deadlatch Replacement Part for GL Series Locksets with 2-1/4" x Front

The Arrow G70 Deadlatch is a precision-engineered replacement latch component designed for use with Arrow's GL Series locksets. Featuring a 2-1/4" x front plate dimension and the correct backset configuration, this deadlatch is the factory-specified part for maintaining the full functionality and security performance of compatible GL Series door hardware in commercial applications.

Key Features

  • Precise Fit: Engineered specifically for Arrow GL Series locksets, ensuring a direct, factory-compatible replacement with no modification required.
  • Front Plate Dimensions: 2-1/4" x front configuration for accurate reinstallation and proper door edge alignment.
  • Correct Backset Compatibility: Designed to match the standard backset of GL Series locks for seamless integration into existing door preparation.
  • Deadlatch Function: Provides positive latch retention with deadlatch security feature to prevent latch manipulation from the outside.
  • Commercial Grade Construction: Built to Arrow's commercial hardware standards for reliable performance in demanding door hardware applications.
  • Genuine Arrow Part: An authentic Arrow replacement component, preserving the original performance characteristics and security of the GL Series lockset.

Technical Specifications

  • Department: Door Hardware
  • Product Category: Mechanical Locks
  • Product Group: Parts and Accessories
  • Subcategory: Parts and Accessories
  • Product Subgroup: Parts and Accessories
  • Product Type: Latches
  • Parts and Accessories Type: Replacement Parts
  • Commercial/Residential: Commercial
  • Product Model: G70
  • Features: Arrow Parts

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Arrow G70?

Arrow hardware components are manufactured to commercial-grade standards, delivering dependable performance in high-use environments. The G70 Deadlatch is designed to restore the full security and functionality of Arrow GL Series locksets, making it the trusted choice for facility managers and door hardware professionals who require genuine, compatible replacement parts.

Manufacturer Resources

Product Specs

Department:
Door Hardware
Product Category:
Mechanical Locks
Product Group:
Parts and Accessories
Subcategory:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Latches
Parts and Accessories Type:
Replacement Parts
Commercial/Residential:
Commercial
Product Model:
G70
Features:
Arrow Parts

Arrow AR-G70 – Frequently Asked Questions

1) What backsets does the Arrow G70 deadlatch come in?
Four backsets are offered on the Arrow G70: 2-3/8 inch, 2-3/4 inch, 3-3/4 inch and 5 inch. The 2-3/8 and 2-3/4 inch sizes are the two standard backsets you will find on most commercial and residential door preps; the 3-3/4 and 5 inch versions exist for wide stile aluminum and glass front doors where the lock body sits further back from the door edge. Measure from the door edge to the center of the bore before you order, because the backset is not adjustable on this latch.
2) Will the Arrow G70 latch fit my GL Series lockset?
The G70 is the factory latch for Arrow GL Series locksets, so it drops into the existing door prep with no modification as long as you match the backset and the front plate. It is a genuine Arrow part, which is what keeps the original security performance of the lockset intact. If your lock is not an Arrow GL Series, this is the wrong latch.
3) My aluminum storefront door has a wide stile. Which Arrow G70 do I order?
Wide stile and storefront doors put the cylinder well back from the edge, which is why the G70 is offered in 3-3/4 inch and 5 inch backsets on top of the usual 2-3/8 and 2-3/4. Measure edge of door to center of the lock bore and order that number. Both long backsets come with the 1-1/8 inch option and the 630 satin stainless faceplate.
4) I need a latch for a residential entry door with an adjustable backset, not a commercial GL Series lock. What should I look at instead of the Arrow G70?
The Arrow G70 is a commercial replacement part matched to Arrow GL Series locksets and is ordered in a fixed backset of 2-3/8, 2-3/4, 3-3/4, or 5 inches. For a residential entry door where you want one latch that covers either common backset, the Deltana DLE23875 is a drive-in entry latch with an adjustable backset and fits doors 1-3/8 to 2 inches thick. If the opening is a passage or privacy door rather than an entry, the Deltana DLP23875 is the same style of adjustable drive-in latch in a passage/privacy function.
5) Can a Kwikset 84290 plainlatch be used in place of an Arrow G70 deadlatch on a GL Series lockset?
No. The Arrow G70 is a deadlatch built specifically for Arrow GL Series locksets, engineered as a direct factory-compatible replacement with no modification required. The Kwikset 84290 is a square corner plainlatch with a 2-3/8 inch backset intended for Kwikset cylindrical locks. A plainlatch also lacks the deadlatch plunger that keeps the latch from being manipulated from the outside, which the G70 provides. For a GL Series lock, order the G70 in the backset that matches the existing door prep.
6) What is the difference between the 1 inch and 1-1/8 inch option number on the Arrow G70?
That number goes with the backset. The 2-3/8 inch backset G70 is supplied with the 1 inch option, while the 2-3/4, 3-3/4 and 5 inch backsets all carry the 1-1/8 inch option. You do not pick it independently, it follows the backset you select.
7) What does the deadlatch function on the Arrow G70 actually do?
The G70 carries a deadlatching plunger alongside the main latchbolt. When the door closes, the plunger rides up on the strike and blocks the latchbolt from being pushed back, which stops the latch from being shimmed or loided from the outside with a card. A plain latch has no plunger and gives you none of that. For an exterior or tenant entry door, the deadlatch version is the one you want.
8) Can I use the Arrow G70 on a fire rated door?
Stick with a latch that is specifically listed for the opening. Among the latches we carry, Kwikset's RCAL adjustable square drive 83518 and the RCAL plain latch 83521 are both stated as UL 3 hour, as is the 84290 square corner plain latch at 2-3/8 inch backset. Match the latch listing to the door label and the lock it is going into.
9) We want a motorized or electrified latch for an access-control opening. Does the Arrow G70 do that?
No. The Arrow G70 is a mechanical deadlatch replacement part for Arrow GL Series locksets with no electrified function. For a powered opening, the Emtek LC9-DBLTCH is an EMPowered motorized deadbolt latch; note that it is a deadbolt latch function rather than a cylindrical lockset deadlatch, so it addresses a different prep and a different lock body.
10) Is the Arrow G70 suitable for high traffic commercial doors?
Yes. The G70 is built to Arrow's commercial hardware standards and is catalogued as a commercial part, not residential. It is used in office buildings, schools, healthcare facilities, retail, warehouses, multi-tenant residential and government buildings.
11) Is the Arrow G70 the right part if I only need a new faceplate, not the whole latch?
No. The Arrow G70 is the complete deadlatch assembly for GL Series locksets, including the 2-1/4 inch front. If you only need cosmetic trim for a latch, a faceplate-only part such as the Emtek 83228 faceplate and screws for a tubular pocket door privacy latch is that kind of item, though it is made for an Emtek privacy latch rather than an Arrow GL Series lock.
