Eaton B-Line series wireway systems and accessories
Manufacturer Resources
Product Specs
- Certifications:
- CSA C22.2.
- Closure Type:
- Hinged
- Finish Color:
- ANSI 61 gray
- Product Height:
- 4 IN
- Product Length Depth:
- 12 IN
- Product Weight:
- 1.695 LB
- Product Width:
- 4 IN
- Special Features:
- Cover securedto bodyw/gasketedretaining s.s. screw
- Department:
- Electrical
- Product Type:
- 3RAHS NK wireway
- Product Details:
- 3RAHS NK wireway
- Installation Category:
- Thru holes
B-LINE 4412-3RAHS NK – Frequently Asked Questions
1) Can this B-Line wireway be used outdoors or in a washdown area?
The 3RAHS construction is the gasketed, hinged screw-cover type, and the cover seals to the body with a gasketed stainless steel screw, which is what makes it suitable for wet and outdoor locations. The stainless hardware is the detail that matters in a washdown or coastal install, since plated steel screws are the first thing to seize.
2) Does this 4412 wireway come with knockouts already punched?
No. The NK suffix on the 4412-3RAHS NK means no knockouts, so the trough ships blank and you drill or punch entries where your conduit runs actually land. If you want factory openings on a set spacing, order the knockout version of the same 4 x 4 body instead.
3) Is the cover on this 4x4 wireway hinged or a screw-on lift-off cover?
Hinged. The cover on the 4412-3RAHS NK stays captive to the body and is secured with a gasketed stainless steel retaining screw, so you can open the trough for pulling or re-pulling conductors without removing and misplacing a separate cover.
4) How does this wireway mount to a wall or backpan?
Mounting is through holes in the trough body, so it fastens directly to a wall, strut, or backpan with your own hardware sized to the substrate. Nothing is welded on for standoff mounting, and no fasteners are supplied, so pick up anchors or strut nuts with it.
5) Is this Eaton B-Line wireway approved for Canadian jobs?
It is certified to CSA C22.2, so it can be specified on Canadian projects as well as US work.
6) What color is the B-Line 4412 wireway, and will it match my existing panelboards?
It is finished in ANSI 61 gray, the standard light gray used on most commercial panelboards, disconnects, and control enclosures. Running it alongside existing gear in ANSI 61 gives a consistent look with no field painting.
