BQL Classic Replacement Circuit Breakers, Bolt-on, 60A, #8-2/0 AWG, Cu/Al, Single-pole, 10 kAIC at 120/240V
Manufacturer Resources
Product Specs
- Amperage Rating:
- 60A
- Circuit Breaker Type:
- BQL
- Compliances:
- HACR Rated
- Interrupt Rating:
- 10 kAIC at 120/240 Vac
- Number Of Poles:
- Single-pole
- Product Height:
- 1 in
- Product Length Depth:
- 5 in
- Product Weight:
- .5 lb
- Product Width:
- 3 in
- Voltage Rating:
- 120/240V
- Wire Size:
- #8-2/0 AWG Cu/Al
- Department:
- Electrical
- Product Group:
- Electrical Components
- Product Subgroup:
- Circuit Breakers
- Product Type:
- Classic replacement circuit breaker
- Product Details:
- Classic replacement circuit breaker
B-LINE BQL60 – Frequently Asked Questions
1) Is the B-Line BQL60 a bolt-on breaker or a plug-in breaker?
BQL60 is a bolt-on single-pole breaker, so it fastens to the panel bus with a mounting screw rather than clipping onto a stab. If your panel interior has plug-in stabs, this one will not seat. Bolt-on and plug-in are not interchangeable in the same mounting position.
2) Will a single-pole BQL60 work on a 240 volt circuit?
Rated 120/240 V, but as a single-pole device it lands on one phase and gives you a 120 V branch circuit. For a 240 V two-wire load such as a water heater or a straight-240 unit heater, you need a two-pole BQL breaker instead.
3) What is the interrupting rating on the B-Line BQL60, and is that enough for my panel?
10 kAIC at 120/240 Vac. That is the standard residential and light commercial AIC level, so it suits panels whose available fault current at the breaker is 10,000 A or less. If your engineer's short circuit study calls for 22 kAIC or higher, this breaker does not meet the spec.
4) Can I use the BQL60 to feed an air conditioner or heat pump?
It is HACR rated, which means it is acceptable for use as the branch circuit protective device on heating, air conditioning and refrigeration equipment where the nameplate calls for an HACR type breaker. Match the 60 A rating to the maximum overcurrent protection listed on the equipment nameplate.
5) What does "classic replacement" mean on a BQL breaker?
It is built as a direct replacement for the older BQL style bolt-on breaker, so it is what you order when you are maintaining an existing panel rather than building new. For a property manager standardizing spares across a building, one BQL60 covers every 60 A single-pole bolt-on position in those panels.
6) How much space does the B-Line BQL60 take up in the panel?
The breaker measures 5 in deep, 3 in wide and 1 in high, and weighs about half a pound. The 1 in height is the single-pole footprint, so it occupies one standard breaker space in the interior.
7) What is the exact part number to order for a 60 amp single-pole BQL bolt-on?
Order B-Line BQL60. That is the 60 A single-pole bolt-on in the BQL series, rated 120/240 V at 10 kAIC.
8) Is the BQL60 a GFCI or AFCI breaker?
No. BQL60 is a standard thermal-magnetic overcurrent device, single-pole, 60 A. If the circuit needs ground fault or arc fault protection, you need a GFCI or AFCI breaker in the correct series, or protection at the device end.
