Spec Sheet
Product Specs
- Base:
- Standard
- Light Modules:
- Red cluster LED
- Series:
- E26
- Used With:
- LED Stacklight Modules
- Voltage Rating:
- 24 Vac/dc
- Department:
- Electrical
- Product Type:
- Stacklight Renewal Part
- Product Length:
- 2.56 IN
- Product Details:
- Stacklight Renewal Part
- Product Height:
- 3.31 IN
- Product Width:
- 2.56 IN
B-LINE E26S16 – Frequently Asked Questions
1) What voltage does the B-Line E26S16 stacklight LED module run on?
The E26S16 cluster LED module is rated 24 Vac/dc, so it works on either 24 volt AC or 24 volt DC control power. If your stack is fed from 120V control wiring, this module is not the right part.
2) What color does the B-Line E26 cluster LED module light up?
Red. The E26S16 is a red cluster LED light module, so it is the part you order when the red segment in an E26 stack has failed or when you are adding a red indication level.
3) Is the E26S16 a complete stacklight or just a replacement segment?
It is a renewal part, not a full tower. The E26S16 is a single LED light module for B-Line E26 Series stacklights, used with the other LED stacklight modules in the stack. You still need the base and the remaining segments to build a working assembly.
4) Will the E26S16 module stack onto my existing B-Line stacklight base?
It uses the standard base configuration for the E26 Series and is built to be used with LED stacklight modules in that family. If your existing tower is a B-Line E26 with a standard base, the red cluster module lands on it. It is not intended for a different series or a non-standard base.
5) How much height does each B-Line E26 LED segment add to the tower?
Each E26S16 module measures 3.31 inches high with a 2.56 x 2.56 inch footprint. If you are fitting a four-level stack under a guard or inside a panel enclosure, multiply that 3.31 inches by the number of segments and add your base and cap.
6) What part number do I order for a red 24V LED module on a B-Line E26 stacklight?
Order B-Line E26S16. That is the manufacturer part number for the red cluster LED module in the E26 Series, rated 24 Vac/dc.
7) Can I mix the E26S16 with other colors in the same stacklight tower?
Yes. The red module is designed to be used with other LED stacklight modules in the E26 Series, so a maintenance team can build the red, amber and green indication they need by stacking segments on one standard base. Keep every module on the same 24 Vac/dc control supply.
