B-Line Eaton auxiliary support...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$102.77
$72.09
B-Line Eaton auxiliary support kit, Yellow zinc dichromate finish, Steel material, Includes 3/8”-16 V-Bolt, framing clips and hardware, Rack to tube

B-Line Eaton auxiliary support kit, Yellow zinc dichromate finish, Steel material, Includes 3/8”-16 V-Bolt, framing clips and hardware, Rack to tube

(No reviews yet) Write a Review

Model: SB2218AYZ
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$102.77
$72.09
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Image coming soon

B-Line SB2528D Eaton auxiliary support kit, Pad - Polyester fiberglass, V-bolts, framing clips and hardware - Steel, Pad, V-bolt, framing clips, sleeve kits and hardware, Includes pad - Red, J-Bolts and hardware - Yellow Zinc, Top angle isolation kit

Model: BLN-SB2528D

Eaton auxiliary support kit, Pad - Polyester fiberglass, V-bolts, framing clips and hardware - Steel, Pad, V-bolt, framing clips, sleeve kits and hardware, Includes pad - Red, J-Bolts and hardware -...

B-LINE

$138.84
$120.80
Eaton auxiliary support kit, Yellow zinc dichromate finish, Steel material, Includes 3/8”-16 V-Bolt, (4) framing clips and hardware, Rack to tube V-bolt kit

Manufacturer Resources

Product Specs

Certifications:
Not Applicable
Product Height:
2 in
Product Length Depth:
4 in
Product Weight:
.94 lb
Product Width:
.562 in
Department:
Electrical
Product Model:
V-bolt kit
Product Finish:
Yellow zinc chromate
Product Material:
Steel

B-LINE SB2218AYZ – Frequently Asked Questions

1) What comes in the B-Line SB2218AYZ V-bolt support kit?
The SB2218AYZ kit ships as a complete rack-to-tube V-bolt assembly: one 3/8 inch-16 V-bolt, four framing clips, and the mounting hardware. Nothing else is needed to tie a cable rack or channel bracket to a round tube or pipe, though the rack or channel itself is a separate item.
2) What is a rack-to-tube V-bolt kit used for on an electrical install?
A V-bolt kit clamps support hardware onto round members, so it is what you use when there is no flat surface or strut to bolt to. The V shape seats on the curve of a pipe or tube and the framing clips hold the mating channel or rack, which is a different job from a beam clamp (flange) or a strut nut (channel). Pick the V-bolt style when your support point is round.
3) What thread size is the B-Line V-bolt, and what nut do I need if I lose one?
The V-bolt is 3/8 inch-16, which is standard coarse thread, so any 3/8-16 hex nut will thread on. The kit already includes its hardware.
4) Is the yellow zinc finish on the B-Line SB2218AYZ suitable for a damp or outdoor location?
The kit is steel with a yellow zinc chromate finish. That is a corrosion-resistant plating meant for indoor and sheltered service, not a hot-dip galvanized or stainless part. For continuous outdoor exposure, wash-down areas, or coastal sites, specify a hot-dip galvanized or stainless equivalent instead.
5) What part number do I order for the B-Line Eaton yellow zinc rack-to-tube V-bolt kit?
Order by MPN SB2218AYZ. It is a single-configuration item from B-Line by Eaton, so there is no finish or size choice to specify: steel, yellow zinc chromate, 3/8 inch-16 V-bolt with four framing clips.
6) How big is the B-Line SB2218AYZ V-bolt kit and how much does it weigh?
Stated dimensions are 4 in, 2 in, and .562 in, with a shipping weight of .94 lb per kit. Handy if you are pricing out a bulk pull for a rack run and need to know what a box of them adds up to.
