B-Line Eaton Series C complete...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$768.41
B-Line Eaton Series C complete , F-, FD, Complete , Fixed thermal, fixed magnetic trip type, Single-pole, 60A, 347 Vac, 125 Vdc, 35 kAIC at 277 Vac,

B-Line Eaton Series C complete , F-, FD, Complete , Fixed thermal, fixed magnetic trip type, Single-pole, 60A, 347 Vac, 125 Vdc, 35 kAIC at 277 Vac,

(No reviews yet) Write a Review

Model: FD1060V
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$768.41
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, fixed magnetic trip type, Single-pole, 60A, 347 Vac, 125 Vdc, 35 kAIC at 277 Vac, 18 kAIC at 347 Vac, Load side, 50°C, 50/60 Hz

FD1060V - spec sheet

Manufacturer Resources

Spec Sheet

Product Specs

Amperage Rating:
60A
Calibration:
50°C
Certifications:
UL Listed
Circuit Breaker Frame Type:
Complete breaker
Circuit Breaker Type:
FD
Frame:
F-frame
Frequency Rating:
50/60 Hz
Interrupt Rating:
35 kAIC at 277 Vac, 18 kAIC at 347 Vac
Number Of Poles:
Single-pole
Product Height:
6 IN
Product Length Depth:
1 IN
Product Weight:
1 LB
Product Width:
1 IN
Series:
Series C
Terminals:
Load side
Trip Type:
Fixed thermal, fixed magnetic
Voltage Rating:
347 Vac, 125 Vdc
Department:
Electrical
Product Length:
1 in

B-LINE FD1060V – Frequently Asked Questions

1) Can the Eaton FD1060V breaker be used on a 347/600V lighting panel?
The FD1060V is rated 347 Vac, so it can be applied on the 347V line-to-neutral side of a 480Y/277 or 600Y/347 system as a single-pole device. At 347 Vac its interrupting rating drops to 18 kAIC; at 277 Vac it holds 35 kAIC. Match the available fault current at your panel to the right one of those two numbers before you apply it.
2) Is the FD1060V a complete breaker or just a trip unit I have to add to a frame?
It ships as a complete breaker on the Eaton Series C F-frame, so there is no separate trip unit or frame to order. The trip is fixed thermal, fixed magnetic, meaning the 60A thermal element and the instantaneous magnetic pickup are factory set and not field adjustable. If you need an adjustable instantaneous setting, an FD with an adjustable magnetic trip is the different part.
3) What exact part number do I order to replace a failed 60A single-pole FD breaker?
The catalog number is FD1060V, an Eaton Series C F-frame FD breaker, single-pole, 60A, with fixed thermal and fixed magnetic trip. Match the V suffix as well as the amperage, since it identifies this particular voltage and interrupting rating combination rather than a standard FD1060.
4) Will a 60 amp FD breaker work on a DC circuit?
Yes, the FD1060V carries a 125 Vdc rating alongside its ac ratings, so it can be applied to DC control or battery circuits up to 125 Vdc. As a single-pole device on DC, follow the manufacturer's pole-series requirements for your system grounding arrangement. On AC it is rated for 50/60 Hz service.
5) Does the FD1060V come with lugs, and which end do they land on?
Terminals are supplied on the load side. The line side connects by whatever the enclosure or panel provides, so if you are feeding it in an individually mounted enclosure, confirm you have line-side connectors for your conductor size. Load-side terminals only is typical for an FD used as a branch device.
6) Is the Eaton FD1060V UL Listed for use in a commercial panelboard?
Yes, the FD1060V is UL Listed. It is a molded case circuit breaker in Eaton's Series C line, F-frame, single-pole, 60A.
7) How much space does an FD frame single-pole breaker take up in an enclosure?
The FD1060V measures 6 x 1 x 1 inches and weighs 1 lb, so a single pole occupies a narrow slot. Use those figures when you are laying out a small enclosure or checking gutter clearance around the breaker.
