B-Line Eaton Series G , EG-, ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,087.30
B-Line Eaton Series G , EG-, EG, Complete , Fixed thermal, fixed magnetic trip, Two-pole, 35A, 600Y/347 Vac, 35 kAIC at 240 Vac, 25 kAIC at 480 Vac,

B-Line Eaton Series G , EG-, EG, Complete , Fixed thermal, fixed magnetic trip, Two-pole, 35A, 600Y/347 Vac, 35 kAIC at 240 Vac, 25 kAIC at 480 Vac,

(No reviews yet) Write a Review

Model: EGE2035FFG
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,087.30
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton Series G molded case circuit breaker, EG-frame, EG, Complete breaker, Fixed thermal, fixed magnetic trip, Two-pole, 35A, 600Y/347 Vac, 35 kAIC at 240 Vac, 25 kAIC at 480 Vac, 18 kAIC at 600Y/347 Vac, Line and load, 50/60 Hz

Manufacturer Resources

Product Specs

Amperage Rating:
35A
Certifications:
CSA Certified
Circuit Breaker Frame Type:
Complete breaker
Circuit Breaker Type:
EG
Compliances:
CE Marked
Frame:
EG
Frequency Rating:
50/60 Hz
Interrupt Rating:
35 kAIC at 240 Vac
Number Of Poles:
Two-pole
Product Height:
5.5 in
Product Length Depth:
2.99 in
Product Weight:
2 lb
Product Width:
2 in
Series:
Series G
Terminals:
Line and load
Trip Type:
Fixed thermal, fixed magnetic
Voltage Rating:
600Y/347 Vac
Department:
Electrical
Product Group:
Electrical Components
Product Subgroup:
Circuit Breakers
Product Type:
Complete breaker
Product Details:
Complete breaker

B-LINE EGE2035FFG – Frequently Asked Questions

1) What interrupting rating does the Eaton Series G EGE2035FFG two-pole 35A breaker have at 240V, 480V and 600Y/347V?
The EGE2035FFG carries 35 kAIC at 240 Vac, 25 kAIC at 480 Vac, and 18 kAIC at 600Y/347 Vac. If your panel's available fault current at the point of installation exceeds any of those figures at your system voltage, this EG-frame breaker is not the right device for that location.
2) Can I use this 35A Eaton EG-frame breaker on a 480V or 600Y/347V three-phase system?
Yes, the EGE2035FFG is rated to 600Y/347 Vac, so it can be applied on 240, 480 and 600Y/347 Vac systems. It's a two-pole device, so on a three-phase system it serves two-pole loads or line-to-line circuits; a three-phase load needs a three-pole breaker of the same frame. It's rated 50/60 Hz.
3) Is the Eaton EGE2035FFG adjustable, or is the trip setting fixed?
Fixed on both counts. The EGE2035FFG uses a fixed thermal, fixed magnetic trip unit, so there is no field-adjustable long-time or instantaneous dial. It protects at its 35A rating as supplied. If your coordination study calls for an adjustable instantaneous setting, you need an adjustable-trip unit rather than this FF version.
4) I need to replace an EG-frame breaker in an existing Eaton panel. Will this one drop in?
The EGE2035FFG is an EG-frame Series G breaker, so it matches other EG-frame positions. Confirm the breaker coming out is also EG frame, two-pole, and that 35A suits the circuit. Pole count and frame are the two things that decide the fit; an EG two-pole will not fill a three-pole space.
5) Does this Eaton Series G breaker come with lugs, or do I have to order terminals separately?
Line and load terminals are included with the EGE2035FFG. It ships as a complete breaker, meaning the frame and trip unit come assembled as one unit ready to install, not as a frame needing a separate trip unit.
6) What are the dimensions and weight of the Eaton EGE2035FFG two-pole breaker for panel space planning?
The breaker measures 5.5 in height, 2 in width, and 2.99 in length/depth, and weighs 2 lb. Use those figures to confirm the pocket and cover cutout in your panelboard or enclosure before you commit.
7) Is the Eaton EGE2035FFG breaker acceptable for a Canadian jobsite?
It is CSA Certified and CE Marked, which covers the Canadian inspection requirement and European marking. That matters for institutional and government specs that call out third-party certification on molded case breakers.
