Eaton B-Line series strut channel, nuts, all threaded rod, Steel, Channel nuts, Nut without spring, Yellow zinc chromate, 250 lbs pull out strength, 450 lbs slip strength, 5/16"-18 thread size
Manufacturer Resources
Product Specs
- Bolt Thread Rod Size:
- 5/16"-18
- Certifications:
- Not Applicable
- Load Rating Pull Out Strength:
- 250 lbs
- Load Rating Slip Strength:
- 450 lbs
- Product Category:
- Channel nuts
- Product Height:
- .85 in
- Product Length Depth:
- 1.75 in
- Product Weight:
- .067 lb
- Product Width:
- 1.375 in
- Department:
- Electrical
- Product Group:
- Fasteners
- Product Subgroup:
- Washers / Nuts / Bolts / Screws
- Product Type:
- Nut without spring
- Product Finish:
- Yellow zinc chromate
- Product Details:
- Nut without spring
- Product Material:
- Steel
B-LINE N223YZN – Frequently Asked Questions
1) What is the difference between a channel nut without a spring and a spring nut?
The N223YZN is a plain channel nut, no spring attached. A spring nut holds itself in position in the strut while you line up the bolt, which helps on overhead work or vertical runs where gravity fights you. Without the spring you have to hold the nut in place as you start the bolt, but there is nothing to compress and it sits flush in the channel. For bench-level or horizontal work, or where you are installing many at once and want the lower-profile part, the no-spring version is the usual pick.
2) Is a yellow zinc chromate channel nut OK for outdoor or damp locations?
Yellow zinc chromate on steel is a general-purpose indoor corrosion finish. It suits dry interior electrical and mechanical support work. For exterior, wash-down, or corrosive environments, specify a hot-dip galvanized or stainless channel nut instead.
3) Can I use this channel nut to hang all-thread rod for conduit and pipe supports?
That is what it is built for. The N223YZN is a steel strut channel nut for all threaded rod applications, tapped 5/16"-18. Drop your rod through the nut in the strut, or run a 5/16"-18 bolt through a fitting into it. Keep the hung load inside the 250 lb pull out rating.
4) Does the B-Line channel nut come with a bolt or washer?
No. The N223YZN is the nut only, with no spring and no hardware packed with it. Order your 5/16"-18 bolts, threaded rod, and any washers separately so the job is complete when the crew shows up.
5) What size is the B-Line N223YZN channel nut?
It measures 1.75 in by 1.375 in by .85 in and weighs .067 lb each. The 1.375 in dimension is what rides across the channel lips, so it is sized for standard 1-5/8 inch strut. Handy if you are calculating shipping weight on a bulk buy of hanger hardware.
