Baldwin Estate 5103 Left Hand Half Dummy Lever with 5048 Rose

The lever itself is shaped and cast for one direction, so a left hand Estate 5103 has the lever swinging down toward the left when it is mounted. Stand outside the door, on the side the dummy trim will be seen from, and check which way the lever should point. Order the right hand version if it points the other way. Because there is no latch to reverse, a dummy lever cannot be re-handed in the field the way a non-handed passage lock can.

No. The 5103 half dummy has no latch or spindle running through the door, so it fastens to the face of the door without a cross bore or edge bore. Baldwin's Estate cylindrical sets in this family use the standard 2-1/8 inch door prep for their operating functions, but if the door is already bored for a lock and you are covering that prep with a dummy, check that the 5048 rose is large enough to cover the hole before you mount it.

Baldwin's Estate 5103 is a residential product, built for homes, condos, and high-end multi-family interiors where appearance drives the choice. For commercial corridors or institutional openings, buyers normally specify a Grade 1 or Grade 2 cylindrical set. Comparable dummy trims built for that use include the BEST 9K Series 1DT single dummy trim, which is Grade 1 heavy duty, and the BEST 7KC Series single dummy trim, which is Grade 2 medium duty.

No - they do different jobs. The Baldwin Estate 5103 LDM is a dummy, so it is surface-mounted trim with no latch and no moving mechanism. A passage lever such as the Dexter C1000 Grade 1 passage, the Falcon B101 Grade 2 passage, or the Callan Asheville Grade 3 passage leverset operates a latchbolt and requires a bored door with a latch prep. Use a dummy only where the door is held closed by a ball catch, roller catch, or magnet, such as a closet or an inactive French door leaf.

The Baldwin Estate 5103 half dummy is a residential product. For a commercial opening, the BEST 9K Series 1DT single dummy trim is a Grade 1 heavy duty non-keyed dummy lever, and the BEST 7KC Series single dummy trim is the Grade 2 medium duty equivalent. The Accentra 455LN Augusta is another Grade 1 heavy duty single dummy cylindrical lever in the 5400 Series. All three are dummy function like the 5103 but carry ANSI/BHMA grading for commercial traffic.

Emtek offers dummy leversets in comparable decorative brass styling: the Arts & Crafts lever dummy and the Hammered lever dummy in the Arts & Crafts collection, and the Cortina lever dummy in the Classic Brass leverset line. All three are dummy function like the Baldwin Estate 5103, so they mount as pull-only trim with no latch. The key ordering difference is that those Emtek dummies are sold as pairs, while the Baldwin 5103 LDM is a half dummy for one face of the door.

Eleven finishes: 003 Polished Brass, 031 Non-Lacquered Brass, 033 Vintage Brass, 044 Satin Brass, 055 Polished Nickel, 056 Satin Nickel, 076 Graphite Nickel, 102 Oil Rubbed Bronze, 112 Venetian Bronze, 190 Satin Black, and 260 Polished Chrome. Those are the standard Baldwin Estate finish codes, so a 5103 dummy in 056 will match a passage or privacy set from the same Estate collection ordered in 056. Note that 031 non-lacquered brass is a living finish and will patina over time, so it will not stay matched to a lacquered 003 opening.

For a pair of doors where you want a lever on both outside faces, you need two half dummies, and they are ordered by hand, so one left hand and one right hand in most layouts. If you want levers on both faces of the same door leaf, that is a full dummy or a dummy pair rather than two halves. Emtek, for example, lists its Arts and Crafts and Cortina levers as dummy pairs for that situation.

A half dummy needs no latch and no strike, because nothing retracts and nothing catches. You get the 5103 lever on the 5048 rose with the mounting screws to fix it to the door face. What it does not do is hold the door shut, so on a closet or french door you will need a separate ball catch, roller catch, or magnetic catch to keep the leaf closed.

The Callan Bentley is a Grade 2 dummy lever and is the simpler alternative when the opening only needs a functional pull rather than the Estate Series decorative brass styling. The Baldwin 5103 half dummy is offered across eleven finishes including Polished Brass, Non-Lacquered Brass, Polished Nickel, Oil Rubbed Bronze and Satin Black, so choose it when the trim has to match an existing Baldwin finish scheme on the rest of the doors.

A dummy will not lock anything. For bed and bath use, the Kwikset 300BRNL Breton is a Grade 3 privacy lever set for doors 1-3/8 inch to 1-3/4 inch thick, and the Arrow MK02-TA is a Grade 1 privacy set with a Tudor knob and a fire rating. Many buyers pair a privacy or passage set on the active door with the Baldwin 5103 half dummy on an inactive leaf so the trim matches across both.

Not for ordering purposes. The Baldwin Estate 5103 LDM is a half dummy, meaning one lever and one 5048 rose for a single face of the door. The Emtek Arts & Crafts and Cortina dummy leversets are supplied as pairs, covering both faces. If you are trimming only the pull side of a closet or an inactive leaf, the half dummy is the correct order; if both faces are visible, you need a pair or two half dummies.

The Baldwin Estate 5103 LDM is handed, so a left hand unit will read upside down on a right hand door and you need the matching hand. If handing is a recurring headache across a fleet of doors, non-handed lever designs exist in the commercial lines: the Falcon B101 Grade 2 passage and the Falcon K101 Grade 1 passage both use non-handed levers. Those are latching passage sets rather than dummies, so they suit doors that actually need to latch.

Because the half dummy is surface mounted to one face and nothing passes through the door, door thickness is not a constraint the way it is on a bored lock. A 1-3/8 inch interior door and a 1-3/4 inch door both take it the same way. What matters instead is having solid material behind the mounting point for the screws, which is a consideration on hollow core doors.
