BALDWIN Estate 5452V Passage Lever with R030 Rose
- Knob or lever set paired with roses with a privacy lock to both close and secure any door with the 2.125" standard door preparation.
- Privacy sets include everything needed to install the lock onto your door.
- Dependability, quality, and high design. Baldwin's Quick Ship items are ready to ship to you within 5 business days from ordering.
- This hardware has the subtle simplicity and clean aesthetic that pairs so well with a contemporary home.
KEY FEATURES
- The Beavertail Lever is aesthetically pleasing with an imaginatively curved design for easy use.
- Sold as a pair or an individual, knobs and levers can be used to create your own unique look.
- Pair mix and match knobs and levers with roses for interior sets like passage and privacy, or customize mortise lock sets utilizing handle set trim or a wide variety of escutcheon plates.
- This style is featured in Quick Ship as part of a complete Passage, Privacy, Full Dummy or Half Dummy set.
FEATURES
- Works with 1-3/8” and 1-3/4” thick doors
- PASS and PRIV functions ship with a full lip strike and Pre-Drilled Door Adaptor.
- Quick Ship is only available with 2 3/8” backset latch.
- Ships with a Full Lip Strike.
RESOURCES & DOWNLOADS
Manufacturer Resources
Product Specs
- Keyed Function:
- Non-Keyed
- Subcategory:
- Door Levers
- Product Group:
- Mechanical Locks
- Product Subgroup:
- Bored Locksets
- Product Type:
- Leversets
- Keyed:
- No
- Commercial/Residential:
- Residential
- Handle Type:
- Lever
- Lock Function:
- Passage
- Edge Bore:
- 1"
- Collection:
- Estate Series
- Product Attribute:
- Cylindrical Locks
- Product Model:
- 5452V
- Backset (Distance):
- 2-3/8 or 2-3/4
- Product Function:
- Passage/Hall/Closet
- Door Hand Direction:
- Reversible
- Product Design:
- Rustic
- Product Category:
- Mechanical Locks
- Department:
- Door Hardware
Baldwin 5452V102PASS – Frequently Asked Questions
1) Will the Baldwin Estate 5452V passage lever fit a standard pre-drilled interior door?
Yes. The 5452V Beavertail lever with R030 rose installs into the standard 2-1/8 inch cross bore with a 1 inch edge bore, and works on doors 1-3/8 inch or 1-3/4 inch thick. Backset is either 2-3/8 or 2-3/4 inch, so it drops into either of the two usual residential preps.
2) Does the Baldwin 5452V lever lock, or is it just a latch?
It does not lock. The 5452V is a passage function set, non-keyed with no privacy turn, so the lever simply retracts the latch from either side. Use it on halls, closets and pantry doors. For a bedroom or bath you want a privacy set with a thumbturn instead.
3) Can I use the Baldwin 5452V passage lever on commercial office or school doors?
It is built as residential hardware, not a commercial grade lockset. For a leased office corridor, school or anything taking public traffic, go with a Grade 1 or Grade 2 cylindrical passage lever instead: the Falcon K101 is a Grade 1 heavy duty passage lever, and the Accentra 5301LN Augusta is a Grade 2 passage option.
4) Is there a passage lever equivalent to the Baldwin Estate 5452V that works on a 2 inch thick door?
The Baldwin Estate 5452V is built for 1-3/8 inch and 1-3/4 inch doors. If the slab is thicker, the Hager 2510 Grade 2 passage lever with the Withnell design covers 1-3/8 inch to 2 inch, the Falcon K101 Grade 1 passage lock covers 1-3/8 inch to 2-1/4 inch, and the Arrow GL01 Grade 2 Sierra lever passage lock covers 1-3/4 inch to 2 inch. The Corbin Russwin CL3110 Grade 1 passage lever also runs 1-3/4 inch to 2 inch.
5) What is a commercial-grade alternative to the Baldwin Estate 5452V passage lever for a high-traffic corridor door?
The Baldwin Estate 5452V is a residential passage leverset with the Beavertail lever on an R030 rose. For heavy commercial traffic, the Falcon K101 is a Grade 1 heavy duty cylindrical passage lock with non-handed levers, fire rated, covering doors 1-3/8 inch to 2-1/4 inch thick, and the Falcon T101 is a Grade 1 heavy duty passage lever with Pressure Release Technology. The Corbin Russwin CL3110 is a Grade 1 vandal resistant passage/closet lever, fire rated, for 1-3/4 inch to 2 inch doors. All three trade the Estate decorative styling for commercial-duty construction.
6) I need a privacy lever for a bedroom or bath instead of the Baldwin 5452V passage function - what should I order?
The Baldwin Estate 5452V is passage function, non-keyed, with no locking at all, so it will not work on a bathroom or bedroom door that needs to lock. For privacy function, the Kwikset 300BRNL Breton is a Grade 3 privacy leverset for 1-3/8 inch to 1-3/4 inch doors, and the Hager 2540 is a Grade 2 privacy cylindrical lock with the Withnell lever for 1-3/8 inch to 2 inch doors. The Arrow MK02-TA is a privacy cylindrical lock with a Tudor knob if a knob is acceptable.
7) The opening needs to be keyed - what replaces the Baldwin Estate 5452V passage lever?
The Baldwin Estate 5452V is non-keyed and cannot accept a cylinder. For a keyed opening in the same lever format, the Cal-Royal AG00 is a Grade 2 entrance lever with a 6-pin Schlage C keyway keyed different on a 2-3/8 inch backset, the Cal-Royal AG05 is a Grade 2 storeroom lever with a deadlocking latchbolt, and the Cal-Royal AG03 is a classroom lever with Schlage C keyway on a 2-3/4 inch backset. Hager offers the 2525 Grade 2 entry lever and the 2580 Grade 2 storeroom lever with the Withnell lever, both for 1-3/8 inch to 2 inch doors.
8) What passage lever should I use in place of the Baldwin Estate 5452V on a fire rated door?
The Baldwin Estate 5452V ships with a full lip strike and a pre-drilled door adaptor for residential openings. Where a fire rating is required, the Falcon K101 is a Grade 1 fire rated passage cylindrical lock with non-handed levers for 1-3/8 inch to 2-1/4 inch doors, and the Corbin Russwin CL3110 is a Grade 1 fire rated passage/closet lever for 1-3/4 inch to 2 inch doors. On the residential side the Kwikset 200DL-RCALFD Delta passage lever uses a round corner adjustable 20 minute UL latch with a round corner strike.
9) Do I have to order the Baldwin 5452V lever handed for a left or right door?
No handing to specify. The 5452V is reversible, so the same set works on a left or right hand door.
10) What comes in the box with the Baldwin Estate 5452V passage set?
The passage set ships complete for the door: lever trim with R030 roses, latch, a full lip strike and a pre-drilled door adaptor. Quick Ship configurations come with the 2-3/8 inch backset latch.
11) I need a matching set of interior door hardware. Can I mix the 5452V lever with knobs on other doors?
Yes. Estate Series levers and knobs are sold as pairs or singles and mix and match with the roses, so you can run the Beavertail lever on some openings and a knob on others while keeping one finish and one rose style across the house. The same trim is offered in passage, privacy, full dummy and half dummy, so a closet and a bath door can look identical.
12) What is a good lower cost passage lever alternative to the Baldwin Estate 5452V for a rental unit?
For apartment turns where the Estate finish is not the point, the Kwikset 200BRNL Breton is a Grade 3 passage lever for 1-3/8 to 1-3/4 inch doors, and the Bravura Atlanta and Orlando are Grade 2 passage leversets with round trim. All three do the same job on hall and closet doors.
13) What is the closest straight substitute for the Baldwin Estate 5452V passage lever if I want a simpler residential-price leverset?
The Baldwin Estate 5452V is a non-keyed passage leverset for hall and closet doors. Comparable passage leversets include the Kwikset 200BRNL Breton, a Grade 3 passage lever for 1-3/8 inch to 1-3/4 inch doors, the Kwikset 200DL Delta passage lever which is reversible with an adjustable 6AL latch and RCS strike, and the Callan Asheville, a Grade 3 passage leverset in satin nickel. Bravura also offers Grade 2 passage leversets in the Atlanta, Orlando and Miramar round-trim designs and the Tampa square-trim design if you want rose shape choices.
14) I need keyless code entry on this door instead of the Baldwin Estate 5452V - what lever options are there?
The Baldwin Estate 5452V is a mechanical non-keyed passage lever with no access control. For code entry in a lever format, the Lockey 2835 is a mechanical pushbutton keyless lever lock with passage function and ADA compliance for doors 1-3/16 inch to 2 inch, the Lockey 2835DC adds a double combination, and the Lockey 1150 is a heavy duty mechanical keypad lever set with double combination for 1-1/8 inch to 2 inch doors. Electronic options include the Delaney LP250 Grade 2 keypad leverlock and the Emtek Classic keypad leverset.
15) For a multi-family building standardizing on one passage lever, how does the Baldwin Estate 5452V compare to spec-grade options?
The Baldwin Estate 5452V is a residential Estate Series passage lever offered in Oil Rubbed Bronze, Venetian Bronze, Satin Black and Distressed Oil Rubbed Bronze, which suits unit interiors where appearance drives the choice. For corridor and back-of-house doors in the same building, Design Hardware offers the X75 Grade 1 passage lever and the J75 Grade 2 passage lever, both flat lever on 1-3/4 inch doors, and Accentra offers the 5301LN Augusta Grade 2 passage lever in the 5300 Series and the 4601LN Grade 2 passage lever with Augusta trim in the 4600 Series. Falcon B101 is a Grade 2 medium duty non-handed passage lever.
16) What finishes does the Baldwin Estate 5452V Beavertail lever come in?
Four: 102 Oil Rubbed Bronze, 112 Venetian Bronze, 190 Satin Black and 402 Distressed Oil Rubbed Bronze. All four are dark tones, which is why the set reads well against rustic and contemporary interiors. If you are matching other Estate Series trim in the house, match by the number, not the name.
