Baldwin Reserve Westcliff Full Dummy Entry Handleset with Traditional Rose

It's a pull only. The Westcliff full dummy set has no latch and no locking mechanism, so nothing engages the frame. Dummy trim is what you put on the inactive leaf of a double door, or on a door that stays fixed. If you need the door to stay shut, you need a passage or keyed handleset on that leaf instead.

Both sides come in the box. It's a dummy "set," meaning exterior handleset plus interior trim, so one order dresses both faces of the leaf. That's why you pick an inside knob or lever style when you order: Ellipse Knob, Round Knob, Traditional Knob, or a handed Curve, Decorative, or Federal lever.

Only if you choose a lever for the inside. The Curve, Decorative, and Federal levers are each ordered left hand or right hand, so you have to know which way the door swings before you order. The knob options, Ellipse, Round, and Traditional, are not handed, so a knob sidesteps the question entirely.

The dummy goes on the inactive leaf, and the active leaf takes a passage or keyed handleset. Order them in the same Reserve finish and the same rose so the pair reads as one set. For the keyed side, Baldwin Reserve keyed handlesets share the Reserve trim; if you're on a residential job and want a lower-cost keyed leaf, the Schlage F60 Addison keyed entry handleset with Accent lever is a Grade 2 residential option that fits 1-3/8 to 1-3/4 inch doors.

Emtek's brass mortise entrance handlesets are offered in a dummy function across four series: the 3002 Memphis, the 3004 Hamilton, the 3005 Melrose, and the 3006 Manhattan. All four are dummy function, so like the Baldwin Reserve Westcliff they have no latch and no locking mechanism and act purely as a pull. The Westcliff is a bored handleset with a 1 inch edge bore, so the door prep is different: an Emtek mortise body needs a mortise pocket cut into the door edge rather than a bored crossbore and edge bore. If your door is already prepped for a mortise handleset, the Emtek dummies drop into that prep; if it is bored, the Westcliff matches.

The Weslock 6695 Belmont dummy handleset with Impresa knob is the nearest straight equivalent, listed in the Elegance Series with a dummy function and a 1-3/8 inch to 2 inch door thickness range. The Weslock 2815 Hillcrest dummy handleset with New Heaven lever covers the same dummy function in the Premiere Essentials Series with the same 1-3/8 inch to 2 inch range, and gives you a lever inside rather than a knob. Both are dummy handlesets like the Westcliff, meaning no latch and no locking mechanism, so they serve the same inactive leaf of a double door.

The Westcliff full dummy is non-keyed with a dummy function, so it handles the inactive leaf only; the active leaf takes a keyed or passage handleset. On the keyed side, the Schlage Residential F60 Addison single cylinder keyed entry handleset with Accent lever is an F Series Grade 2 entrance function fitting doors 1-3/8 inch to 1-3/4 inch, and the Weslock 1411 Traditionale Colonial handleset with Eleganti knob is a single cylinder keyed entry in the Traditionale series fitting 1-3/4 inch to 2-1/4 inch doors. If you want the active leaf latching but not locking, the Schlage Residential JE285 Barcelona handleset with Seville lever is a non-keyed J Series Grade 2 unit for 1-3/8 inch to 1-3/4 inch doors. Match the door thickness of the active leaf to the range on whichever you pick.

The edge bore spec is 1 inch. Because the dummy set carries no latch, that edge prep is for mounting hardware rather than a latch case, and there's no strike to cut into the frame. On a new double door install, the inactive leaf gets far less prep than the active one.

Yes. Interior trim ships in the same finish as the exterior by default, but a split finish can be requested and specified at the time of order. That's the usual move when the exterior has to match a bronze entry and the interior has to match satin nickel elsewhere in the house. Eight finishes are offered: Polished Brass PVD, Satin Brass PVD, Polished Nickel PVD, Venetian Bronze, Satin Nickel, Matte Antique Nickel, Satin Black, and Polished Chrome.

Three Traditional rose shapes are offered on the Westcliff dummy: Traditional Arch, Traditional Round, and Traditional Square. Pick whichever shape is already on the other Reserve openings in the building, since the rose is the visible plate behind the knob or lever and a mismatched shape is the thing you notice from across a room. The Westcliff is a Traditional design within the Reserve Series.

It's a residential product, and it's tested to exceed ANSI/BHMA Grade 2 security. For multi-family common areas or a commercial opening where a Grade 1 spec is on the drawing, this isn't the part. On residential units and interiors it's in line with the Grade 2 residential handlesets from Schlage's F and J series.

No. It's non-keyed with no cylinder and no locking mechanism, so there's nothing to key now or later. If the opening will eventually need to lock, buy a keyed handleset for that leaf up front rather than planning to convert a dummy.

No. The Kwikset 687AMD Amador single cylinder handleset is a Grade 3 entrance function keyed door entry supplied as exterior only, and the same is true of the Kwikset 687BW Belleview. Exterior only means no interior trim in the box. The Baldwin Reserve Westcliff full dummy is a set, shipping both the interior and exterior handleset, and it is non-keyed with no latch or locking mechanism at all. So the Amador and Belleview solve a keyed exterior door, not the inactive leaf of a double door, and they will not give you matching trim on the inside face.

Both are Kwikset 687AMD Amador single cylinder keyed entry handlesets, Grade 3, exterior only, for 1-3/4 inch doors. The SMC version specifies an SC1 keyway with SmartKey, while the SMT version is listed as SmartKey without the SC1 keyway call-out. If you are keying to an existing SC1 system, that keyway designation is the one to order against. Neither is a match for the Baldwin Reserve Westcliff full dummy, which is non-keyed.

An electronic handleset is built around a working deadbolt, so it is not an inactive leaf part. The Yale Real Living BYRD226CBARX Assure Lock pairs a Wi-Fi and Bluetooth touchscreen deadbolt with the Ridgefield handleset for 1-3/4 inch to 2-1/4 inch doors, the BYRD226NRRX is the standalone version of the same Ridgefield combination for the same thickness range, and the Kwikset 815SCEHFL-CP913CNT San Clemente handleset carries a Contemporary SmartCode keypad electronic deadbolt with Halifax lever trim on 1-3/4 inch doors. Those go on the active, latching leaf. The Baldwin Reserve Westcliff full dummy is non-keyed with no latch or locking mechanism and is the part for the leaf that stays fixed.

Among comparable handlesets, the Schlage Residential F60 Addison keyed entry with Accent lever and the Schlage Residential JE285 Barcelona with Seville lever are both Grade 2, as is the Schlage Residential JI18/19 interconnected lock and the Master Lock HDLBA0615/4D single cylinder deadbolt handleset. The Kwikset 687AMD Amador and 687BW Belleview handlesets are Grade 3. The Baldwin Reserve Westcliff full dummy is tested to exceed ANSI/BHMA Grade 2 security. For a facility standardizing on a grade, note that a dummy set has no latch or locking mechanism, so grade there speaks to construction and finish durability rather than to a locking cycle.

The Baldwin Reserve Westcliff full dummy offers handed lever trim inside, with left and right handed Curve, Decorative, and Federal levers alongside Ellipse, Round, and Traditional knobs, so specify the hand when the lever is chosen. The Weslock 2815 Hillcrest dummy handleset pairs with the New Heaven lever and is a dummy function for 1-3/8 inch to 2 inch doors. If a knob suits, the Weslock 6695 Belmont dummy uses the Impresa knob over a 1-3/8 inch to 2 inch range.

Not as a matched pair. The Westcliff dummy is Baldwin Reserve trim, so it matches other Baldwin Reserve hardware, not an electronic deadbolt handleset from another brand. If the plan is a keypad or Wi-Fi front door with a matching second leaf, buy both leaves from the same family, for example the Yale Assure Lock touchscreen deadbolt with Ridgefield handleset, which fits 1-3/4 inch to 2-1/4 inch doors, or the Kwikset San Clemente handleset with Contemporary SmartCode keypad deadbolt for 1-3/4 inch doors.

The Westcliff is a Reserve Series residential handleset ordered across eight finishes, nine inside knob and lever styles, and three rose shapes, which is a lot of configuration. If you want a single ordering decision instead, the Pamex FS7P31 Lexington single cylinder handleset comes fixed in satin nickel for 1-3/8 inch to 1-3/4 inch doors, and the Master Lock HDLBA0615/4D is a Grade 2 single cylinder deadbolt handleset in the HDLB Series with an entrance function. Both are keyed entry parts rather than dummies, so use them where the door actually needs to lock.

Deltana lists several solid brass entry handlesets: the 803871B Hanover, the 815871 St. Ann, and the 825871 Kingston, all entry function in solid brass, plus the 810871 Montego for doors 1-3/8 inch to 2 inch. Emtek's 3002 Memphis, 3004 Hamilton, 3005 Melrose, and 3006 Manhattan are brass mortise entrance handlesets in a dummy function. The Deltana units are entry function and so lock; the Emtek dummies match the Baldwin Reserve Westcliff full dummy on function, which is non-keyed with no latch.

No. The Schlage Residential JI18/19 is an interconnected passage lock with a keyed deadbolt and Torino lever in satin stainless steel, a JI Series Grade 2 passage function for 1-3/8 inch to 1-3/4 inch doors. It links a lever latch and a deadbolt so one motion retracts both, and it is a lever trim rather than a gripping handle. The Baldwin Reserve Westcliff is a handleset with an exterior grip and an inside knob or lever, and as a full dummy it has no latch and no deadbolt to interconnect. They do not swap for each other.
