BEA 10EMS475X Panther Family 4.75" Square Wireless Push Plate with 433 MHz Technology

BEA 10EMS475X Panther Family 4.75" Square Wireless Push Plate with 433 MHz Technology

Professional Wireless Access Control Solution

The BEA 10EMS475X Panther Family wireless push plate combines 433 MHz radio frequency technology with a 4.75" square design for versatile access control applications. This weather-rated IP65 push plate eliminates wiring requirements through integrated wireless transmission, offering enhanced installation flexibility in both indoor and outdoor environments where traditional hardwired solutions are impractical.

Professional Features & Benefits

• Wireless Technology Integration: 433 MHz radio frequency transmission eliminates the need to run wires from the push plate, reducing installation time and complexity.
• Weather-Resistant Construction: IP65 rated housing creates a weather resistant barrier enabling outdoor mounting and wash-down applications.
• ADA Compliance: Enhances accessibility with ADA-compliant design available in a variety of popular faceplate graphic options.
• Vandal-Resistant Design: Concealed fasteners minimize vandalism and unauthorized tampering.
• Integrated Mounting System: Includes integrated wireless transmitter and mounting box for streamlined installation without additional mounting hardware.
• Flexible Installation Options: Offers greater mounting flexibility in areas where hardwired push plates cannot be mounted due to structural or wiring limitations.
• Square Profile Design: 4.75" square configuration provides professional appearance suitable for commercial applications.

Technical Specifications

• Transmitter Frequency: 433 MHz or 900 MHz
• Power (433 MHz): (1) 12 V Type A23
• Power (900 MHz): (2) CR2032
• Faceplate Material: 16 Gauge, 304 2B Stainless Steel
• Housing Material: ABS Plastic
• Mounting Options: Surface or bollard mount
• Dimensions (6 Inch Round): 6.33 in (dia.) x 1.45 in (D)
• Dimensions (4.75 Inch Round): 5.12 in (dia.) x 1.42 in (D)
• Dimensions (4.75 Inch Square): 5.12 in (W) x 5.12 in (H) x 1.42 in (D)
• Weight (6 Inch Round): 1.2 lbs
• Weight (4.75 Inch Round): 1.14 lbs
• Weight (4.75 Inch Square): 1.04 lbs
• Degree of Protection: NEMA 4 / IP65
• Certification: FCC IC Part 15 Approved

Installation & Operation

1. Select appropriate mounting location ensuring adequate clearance for wireless signal transmission to the corresponding receiver unit.
2. Mount the integrated mounting box using appropriate fasteners for the mounting surface material.
3. Configure the wireless transmitter frequency settings to match the corresponding wireless receiver (sold separately).
4. Test wireless signal transmission range and reliability from the installation location to the receiver.
5. Verify push plate operation and wireless communication with the access control system.
6. Complete final inspection and document wireless settings. Refer to manufacturer documentation for complete programming instructions and troubleshooting.

Professional Applications

• Commercial Building Access Control Systems
• Healthcare Facility Automatic Door Operation
• Educational Institution Accessibility Compliance
• Retail Establishment Entry Systems
• Industrial Facility Personnel Access
• Outdoor Installation Requirements
• Wash-Down Environment Applications

Why Choose BEA Quality?

BEA Panther Family wireless push plates deliver professional-grade reliability with IP65 weather-resistant construction and vandal-resistant design features. The integrated 433 MHz wireless technology eliminates installation complexity while maintaining dependable performance in demanding commercial environments. Engineered for accessibility compliance and flexible mounting applications where traditional wired solutions are impractical.
