AL SERV ENTR SPLICE 1/0 2/0 1/0 RED
Manufacturer Resources
Product Specs
- Connection Type:
- Compression
- Country Of Origin:
- United States (US)
- Insulation Material:
- Insulated
- Number Of Conductors:
- 2
- Product Group:
- Wire Connectors & Terminals
- Product Type:
- Compression Splice
- Selling Unit Of Measure:
- each
- Standards:
- ANSI C119.4
- Type2:
- Wire or cable compression splice
- Department:
- Electrical
- Product Subgroup:
- Wire Connectors
- Product Size:
- 5-1/2 inches long
- Product Color:
- Yellow/Red
Blackburn X 1 N 102 – Frequently Asked Questions
1) What wire sizes does the Blackburn X 1 N 102 service entrance splice take?
The Blackburn X 1 N 102 is an aluminum service entrance splice sized for 1/0, 2/0 and 1/0 conductors, joining 2 conductors in one compression splice. It is a two-conductor splice, so it is for making a single run-to-run connection, not a multi-tap.
2) Is the X 1 N 102 splice insulated, or do I have to tape and cover it after crimping?
It comes insulated from the factory, so no separate cover or tape wrap is needed over the barrel once the crimp is made. The body is color coded yellow/red to identify the die and conductor range.
3) Do I need a crimping tool for this Blackburn splice, or is it a set-screw connector?
Compression only. The X 1 N 102 is a crimp splice, so it needs a hydraulic or battery compression tool with the matching die set. If you want a connection you can make with a hex key instead, you need a set-screw (mechanical) service entrance connector rather than this one.
4) Is this Blackburn splice approved for aluminum service entrance conductors?
Yes. It is an aluminum service entrance splice built to ANSI C119.4, the standard covering connectors for aluminum and copper conductors in underground and service applications. That is the spec an inspector or utility will ask for on a direct-buried or service splice.
5) Will the X 1 N 102 splice fit inside a meter socket or service entrance can?
Plan on 5-1/2 inches of straight length for the splice body alone, plus room for the tool head to close around it. In a tight meter socket or pedestal, measure the available run before committing, because a compression splice cannot be shortened.
6) Is the Blackburn X 1 N 102 made in the USA for a government or public works job?
Country of origin is the United States, which is what a government, school district, or municipal buyer needs for domestic-preference documentation. The part number to cite on the submittal is Blackburn X 1 N 102.
7) How is the X 1 N 102 sold, individually or in a bag?
Sold each, so the quantity you order is the number of splices you get. Order one per conductor pair being joined, which means three for a typical 1/0-2/0-1/0 triplex service run.
