Bolt 3/8-16 x 4 Hx Tap Blt 18-8 (100 pcs)
Manufacturer Resources
Product Specs
- Division:
- Electrical H1
- Product Group:
- Fasteners
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Bolts
Metallics SHTB60 – Frequently Asked Questions
1) Is the Metallics SHTB60 bolt stainless steel, and will it hold up outdoors?
It is 18-8 stainless, the common austenitic grade (roughly 18 percent chromium, 8 percent nickel) equivalent to 304. That gives good corrosion resistance for exterior, damp, and wash-down work, which is why it gets specified for outdoor strut and channel runs, pump and equipment mounting, and coastal-adjacent jobs. For direct salt spray or chemical immersion, a 316 fastener is the better call.
2) How many bolts come in a box of Metallics SHTB60?
Each box holds 100 pieces of the 3/8-16 x 4 inch 18-8 hex tap bolt. That is a stocking quantity for an electrical or MRO crib, not a single-job pack, so if you only need a handful for one hanger run you will have plenty left over.
3) Will a 3/8-16 stainless hex tap bolt work with strut channel and 3/8 inch channel nuts?
Yes. 3/8-16 is the standard coarse thread used on 3/8 inch channel nuts and strut hardware, and the SHTB60 is fully threaded along its 4 inch length, so it engages a channel nut at any depth. Pair it with stainless nuts, washers, and channel nuts so you are not mixing stainless with plain or galvanized steel in a wet location.
4) What is the difference between a hex tap bolt and a regular hex cap screw?
A tap bolt is threaded right up to the head; a hex cap screw of the same size has an unthreaded shank under the head. The SHTB60 is the tap bolt version in 3/8-16 x 4, so it suits threading directly into a tapped hole, into a channel nut, or through stacked material where the clamp thickness is not fixed. If you specifically want an unthreaded body bearing in a shear joint, order a hex cap screw instead.
5) Does the Metallics SHTB60 come with nuts and washers?
No. The SHTB60 is bolts only, 100 pieces of the 3/8-16 x 4 inch 18-8 hex tap bolt. Nuts, flat washers, and lock washers are ordered separately, and for this bolt you want them in 3/8 inch 18-8 stainless to keep the joint from galvanic corrosion.
6) What wrench or socket size does a 3/8-16 hex tap bolt take?
A 3/8 inch diameter hex bolt uses a 9/16 inch hex head, so a 9/16 socket or wrench drives the SHTB60. Stainless galls easily when run down hard, so use an anti-seize on the threads if you are torquing into a stainless nut or tapped stainless hole.
How fast can I get the Metallics SHTB60 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Metallics SHTB60 come with a warranty?
Absolutely. The Metallics SHTB60 is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Metallics SHTB60?
You can call, text, or email our expert support team for fast answers. We’re here to help with
product
selection,
installation tips, and troubleshooting. Contact Us
