Bolts 1/4-20 X 1 G5 Hx Tap Blt St-zn (Jar 100)
Additional Notes
- Other sizes and quantities available by request
Features
- Used to mount motor to machinery. Also popular in automotive and truck repair
- A cap screw made from medium carbon steel and heat-treated
Manufacturer Resources
Product Specs
- Arra Compliant:
- U
- Buy American Compliant:
- U
- Division:
- Electrical H1
- Fastener Head Height:
- May-32 in.
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 0.428 - 0.438 in.
- Fastener Height:
- 0.150 - 0.163
- Fastener Length:
- 1
- Fastener Width:
- 0.488 - 0.505
- Grade:
- 5
- Hardness:
- Rockwell C25-34
- Language Code:
- EN
- Material Standard:
- AISI 1008 - 1026
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Tap_Bolt_St-Zn_and_18-8_SS.pdf
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- CT
- Outside Diameter:
- 0.2450 - 0.2500 IN
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 2.7 in
- Product Length:
- 3 in
- Product Weight:
- 767 g
- Product Width:
- 76.2 MM
- Sub Division:
- Electrical-E H2
- Tensile Strength:
- 120000 psi minimum
- Thread Direction:
- Right Hand
- Thread Per Inch:
- 20
- Thread Standard:
- ASME B18.2.1-2012
- Wrenching Height:
- 0.106
- Yield Strength:
- 92000 psi minimum
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- G5HTB and JG5HTB
- Product Finish:
- Zinc
- Product Details:
- Hexagonal Bolt
- Product Material:
- Steel
Metallics JG5HTB2 – Frequently Asked Questions
1) Is the Metallics JG5HTB2 hex tap bolt threaded all the way to the head?
Yes. A hex tap bolt is fully threaded, which is what separates it from a partially threaded hex cap screw. The JG5HTB2 is a 1/4-20 by 1 inch Grade 5 hex tap bolt, 20 threads per inch, right-hand thread, made to ASME B18.2.1-2012. Full threading means you can run it into a tapped hole to whatever depth the hole allows rather than being limited by a grip length.
2) What size hole do I need for a 1/4-20 hex tap bolt?
The bolt shank runs 0.2450 to 0.2500 inches in diameter, so a 1/4 inch nominal clearance hole will be tight. For a through hole use a 9/32 inch bit for normal clearance. For a tapped hole, the mating thread is 1/4-20 right hand.
3) What wrench or socket size fits a 1/4-20 Grade 5 hex tap bolt?
The head measures 0.428 to 0.438 inches across the flats, so a 7/16 inch wrench or socket is the fit. That is the standard hex size for a 1/4-20 bolt head.
4) Will a zinc plated Grade 5 bolt hold up outdoors or in a damp mechanical room?
The JG5HTB2 is steel with a zinc finish, which handles indoor and sheltered conditions and incidental moisture. Zinc plating is a sacrificial coating, not a stainless material, so for continuous wet exposure, coastal air, or chemical washdown you want 18-8 stainless or hot dip galvanized instead. Note that stainless will not give you Grade 5 strength numbers.
5) How many bolts come in a jar of Metallics JG5HTB2?
100 pieces per jar, and the jar is the minimum order quantity. The packaged jar weighs 767 grams. Jar packaging suits a service truck or a shop bench where you are pulling a handful at a time rather than opening a bulk box.
6) Do these bolts come with nuts or washers?
No. The jar contains 100 hex tap bolts only. Nuts, flat washers, and lock washers are ordered separately, and for a Grade 5 bolt you want a Grade 5 or higher nut so the nut is not the weak point in the joint.
7) Can I use these Metallics bolts on a Buy American or ARRA funded job?
Country of origin on the JG5HTB2 is listed as multiple, meaning the sourcing is not tied to a single country. For federally funded work with domestic sourcing requirements, specify a fastener with a documented US origin rather than this one.
8) I need a different length or diameter in the same Grade 5 hex tap bolt. Is that available?
Yes. The G5HTB and JG5HTB series runs beyond the 1/4-20 by 1 inch JG5HTB2, and other sizes and quantities can be supplied by request. The construction is the same across the series: medium carbon steel cap screw, heat treated, zinc plated.
