Metallics JG5HTB29 Bolts 3/8-16 X 2-1/4 G5 Hx Tap Blt S (Jar 100)

Metallics JG5HTB29 Bolts 3/8-16 X 2-1/4 G5 Hx Tap Blt S (Jar 100)

(No reviews yet) Write a Review

Model: JG5HTB29
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$51.27
$1.93
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Bolts 3/8-16 X 2-1/4 G5 Hx Tap Blt S (Jar 100)

  • Additional Notes

    • Other sizes and quantities available by request

  • Features

    • Used to mount motor to machinery. Also popular in automotive and truck repair
    • A cap screw made from medium carbon steel and heat-treated

Manufacturer Resources

Product Specs

Arra Compliant:
C
Buy American Compliant:
C
Division:
Electrical H1
Fastener Head Height:
15/64 in.
Fastener Head Type:
Hex
Fastener Head Width:
0.551 - 0.562 in.
Fastener Height:
0.226 - 0.243
Fastener Length:
2/1/04
Fastener Width:
0.628 - 0.650
Grade:
5
Hardness:
Rockwell C19-30
Language Code:
EN
Material Standard:
AISI 1008 - 1026
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Tap_Bolt_St-Zn_and_18-8_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
CT
Outside Diameter:
0.3690 - 0.3750 IN
Pack Type:
Jar
Product Group:
Fasteners
Product Height:
7.25 in
Product Length:
4.5 in
Product Weight:
3307 g
Product Width:
114.3 MM
Sub Division:
Electrical-E H2
Tensile Strength:
105000 psi minimum
Thread Direction:
Right Hand
Thread Per Inch:
16
Thread Standard:
ASME B18.2.1-2012
Wrenching Height:
0.16
Yield Strength:
105000 psi minimum
Department:
Electrical
Product Subgroup:
Bolts
Product Type:
Hexagonal Bolt
Type2:
Hexagonal Bolt
Series:
G5HTB and JG5HTB
Product Finish:
Zinc
Product Details:
Hexagonal Bolt
Product Material:
Steel

Metallics JG5HTB29 – Frequently Asked Questions

1) Are grade 5 bolts strong enough to mount a motor to a machine base?
That is the intended use for these Metallics hex tap bolts. Grade 5 medium carbon steel, heat treated, with 105,000 psi minimum tensile and 105,000 psi minimum yield, and hardness of Rockwell C19-30. They are also commonly used in automotive and truck repair. If a drawing calls out grade 8, these will not satisfy it.
2) Will zinc plated steel hex tap bolts hold up outdoors?
These are steel with a zinc finish, which handles indoor and sheltered mechanical work well but is sacrificial coating only. For wash-down, coastal, or permanently wet exposure, specify a stainless hex tap bolt in the same 3/8-16 x 2-1/4 size instead.
3) How are the JG5HTB29 bolts packaged and what is the minimum order?
They ship in a jar of 100 pieces, and 100 count is the order minimum. Shipped weight of the jar is 3,307 g. If you need a different size or a different count, Metallics offers other sizes and quantities by request.
4) Do these Metallics bolts meet Buy American or ARRA requirements for a public project?
The JG5HTB29 carries both an ARRA compliant and a Buy American compliant designation in Metallics' data, with country of origin listed as China. On a federally funded job, match that against the specific domestic-content clause in your contract, since the two programs apply different tests.
5) Is a hex tap bolt the same thing as a hex cap screw?
Dimensionally the head is the same, but a tap bolt is threaded the full length of the shank while a hex cap screw has an unthreaded grip under the head. Use the JG5HTB29 tap bolt when you are threading into a tapped hole in a casting or machine base and want engagement all the way down. Where the joint needs the shank bearing in a clearance hole, a partially threaded cap screw in 3/8-16 is the better call.
6) What steel are these grade 5 tap bolts made from?
Material is medium carbon steel to AISI 1008-1026, heat treated to reach grade 5 properties. That is the reason the hardness lands at Rockwell C19-30 rather than the softer range you get from an unhardened grade 2 bolt.
