Metallics JHTB71 Bolts 5/8-11 ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$60.36
$13.50
Metallics JHTB71 Bolts 5/8-11 x 2-1/2 Hx Tap Blt St-zn (Jar 25)

Metallics JHTB71 Bolts 5/8-11 x 2-1/2 Hx Tap Blt St-zn (Jar 25)

(No reviews yet) Write a Review

Model: JHTB71
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$60.36
$13.50
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Bolts 5/8-11 x 2-1/2 Hx Tap Blt St-zn (Jar 25)

  • Additional Notes

    • Other sizes and quantities available by request

Manufacturer Resources

Product Specs

Arra Compliant:
N
Buy American Compliant:
No
Division:
Electrical H1
Fastener Head Height:
27/64 in.
Fastener Head Type:
Hex
Fastener Head Width:
0.906 - 0.938 in.
Fastener Height:
0.378 - 0.444
Fastener Length:
2/1/02
Fastener Width:
1.033 - 1.083
Field Application:
Complete Thread Engagement Applications, Electrical, Plumbing, Heating, Air Conditioning Industries
Hardness:
Rockwell B69-B100
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Tap_Bolt_St-Zn_and_18-8_SS.pdf
Order Minimum Imperial:
25
Order Minimum Uom Imperial:
EA
Pack Type:
Jar
Product Group:
Fasteners
Product Height:
7.25 in
Product Length:
4.5 in
Product Weight:
2926 g
Product Width:
114.3 MM
Sub Division:
Electrical-E H2
Tensile Strength:
60000 psi minimum
Thread Direction:
Right Hand
Thread Per Inch:
11
Thread Standard:
IFI-199 (2014)
Department:
Electrical
Product Subgroup:
Bolts
Product Type:
Hexagonal Bolt
Type2:
Hexagonal Bolt
Series:
HTB, JHTB, and JSHTB
Product Finish:
Zinc
Product Details:
Hexagonal Bolt
Product Material:
Steel

Metallics JHTB71 – Frequently Asked Questions

1) Is a hex tap bolt threaded all the way to the head, or does it have a plain shank like a hex cap screw?
A tap bolt is fully threaded to the head, which is the point of the design. Metallics lists the JHTB71 for complete thread engagement applications, so you get usable thread over the whole 2-1/2 inch length. If you need an unthreaded grip length under the head for shear bearing, a hex cap screw is the part to use instead.
2) Do these Metallics tap bolts qualify for a Buy American or ARRA funded job?
No. The JHTB71 is not Buy American compliant and is not ARRA compliant, with country of origin listed as multiple. On a federally funded project with domestic sourcing requirements, you will need a documented domestic fastener instead.
3) What wrench or socket size do I need for a 5/8-11 Metallics tap bolt?
Head width across flats measures 0.906 to 0.938 in., which is a 15/16 inch wrench or socket. Head height is 27/64 in., worth knowing if you are working inside a channel or a tight boxed space.
4) Are these zinc plated steel bolts okay for outdoor or damp electrical work?
The JHTB71 is steel with a zinc finish, which handles indoor and normally dry or occasionally damp locations. For wet, coastal, or chemically aggressive runs, step up to the stainless version of the series (JSHTB) rather than zinc plated steel.
5) How many bolts come in a jar, and can I buy just a few?
The JHTB71 ships as a jar of 25, and 25 each is the order minimum, so the jar is the smallest buy. Metallics makes other sizes and quantities of the HTB/JHTB/JSHTB tap bolts available by request if 5/8-11 x 2-1/2 is not the length you need.
6) Can I use a hex tap bolt with a nut and washers as a through bolt?
Yes. Because the JHTB71 is threaded the full 2-1/2 inches, it takes a 5/8-11 nut anywhere along the shank, so it works as a through bolt in drilled plate or channel as readily as in a tapped hole. Nuts and washers are not included with the jar, so order those separately.
