Metallics G5HTB80 Bolts 5/8-11 X 6 G5 Hx Tap Blt St-zn (Box 50)

Metallics G5HTB80 Bolts 5/8-11 X 6 G5 Hx Tap Blt St-zn (Box 50)

(No reviews yet) Write a Review

Model: G5HTB80
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$59.94
$13.50
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Bolts 5/8-11 X 6 G5 Hx Tap Blt St-zn (Box 50)

  • Additional Notes

    • Other sizes and quantities available by request

  • Features

    • Used to mount motor to machinery. Also popular in automotive and truck repair
    • A cap screw made from medium carbon steel and heat-treated

Manufacturer Resources

Product Specs

Arra Compliant:
C
Buy American Compliant:
C
Division:
Electrical H1
Fastener Head Height:
25/64 in.
Fastener Head Type:
Hex
Fastener Head Width:
0.922 - 0.938 in.
Fastener Height:
0.378 - 0.403
Fastener Length:
6
Fastener Width:
1.051 - 1.083
Grade:
5
Hardness:
Rockwell C19-30
Language Code:
EN
Material Standard:
AISI 1008 - 1026
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Tap_Bolt_St-Zn_and_18-8_SS.pdf
Order Minimum Imperial:
50
Order Minimum Uom Imperial:
CT
Outside Diameter:
0.6170 - 0.6250 IN
Pack Type:
Box
Product Group:
Fasteners
Product Height:
6 in
Product Length:
7.25 in
Product Weight:
25.36 lbs
Product Width:
6.25 in
Sub Division:
Electrical-E H2
Tensile Strength:
105000 psi minimum
Thread Direction:
Right Hand
Thread Per Inch:
11
Thread Standard:
ASME B18.2.1-2012
Wrenching Height:
0.269
Yield Strength:
105000 psi minimum
Department:
Electrical
Product Subgroup:
Bolts
Product Type:
Hexagonal Tap Bolt
Type2:
Hexagonal Tap Bolt
Series:
G5HTB and JG5HTB
Product Finish:
Zinc
Product Details:
Hexagonal Tap Bolt
Product Material:
Steel

Metallics G5HTB80 – Frequently Asked Questions

1) Is the Metallics G5HTB80 hex tap bolt threaded the full 6 inch length?
Yes. A tap bolt is threaded the entire length of the shank rather than having a plain grip section, which is why it's used to bolt into tapped holes such as motor mounting feet. The G5HTB80 is a 5/8-11 bolt, 6 inches long, with right hand threads at 11 threads per inch.
2) Is a Grade 5 zinc plated bolt strong enough for mounting a motor to a machine base?
Yes, that is the intended use. Grade 5 means medium carbon steel, heat treated, with 105,000 psi minimum tensile and yield strength and a hardness of Rockwell C19-30. That covers motor mounting, machinery, and automotive and truck repair work. The zinc plating gives basic corrosion resistance for indoor and sheltered use; for sustained outdoor or wet exposure, stainless is the better call.
3) Will a 5/8-11 bolt pass through a 5/8 inch drilled hole?
The shank outside diameter runs 0.6170 to 0.6250 inch, which is at or just under nominal 5/8 (0.625). In practice you want a clearance hole of 11/16 inch for an easy pass-through; a hole drilled exactly 5/8 will be a tight interference fit on the upper end of that tolerance.
4) Does the Metallics G5HTB80 come in a box of 50, and can I buy fewer?
It ships as a box of 50 with a 50-count order minimum, so 50 pieces is the smallest quantity. Metallics does make other sizes and quantities in the G5HTB series available by request.
5) Does this Grade 5 hex tap bolt meet Buy American and ARRA requirements for a public project?
The G5HTB80 is flagged compliant for both Buy American and ARRA in Metallics' product data, with country of origin China. Specifiers on federally funded work should reconcile those two data points against their own project's domestic-content clause before submitting.
6) Do nuts and washers come with the Metallics G5HTB80 bolts?
No. The box of 50 is bolts only. A tap bolt is normally driven into a tapped hole, but if you're through-bolting you'll need to order 5/8-11 hex nuts and 5/8 washers separately.
7) How much does a box of 50 of these 5/8 x 6 bolts weigh?
About 25.36 lbs per box of 50 of the G5HTB80. Worth knowing if you're staging several boxes on a lift or shipping to a jobsite with hand-carry limits.
