Metallics JG5HC122 Bolts 7/16-14 X 2-1/2 G5 Hxbt St-zn (Jar 50)
Model: MET-JG5HC122
Bolts 7/16-14 X 2-1/2 G5 Hxbt St-zn (Jar 50)
Additional Notes
Other sizes and quantities available by request
Features
A cap screw made from medium carbon steel and heat-treated
Used to mount...
Metallics
$52.27
$3.86
Bolts 7/16-14 X 1 G5 Hxbt St-zn (Jar 50)
Additional Notes
- Other sizes and quantities available by request
Features
- Used to mount motor to machinery. Also popular in automotive and truck repair
- A cap screw made from medium carbon steel and heat-treated
Manufacturer Resources
Product Specs
- Arra Compliant:
- N
- Buy American Compliant:
- No
- Division:
- Electrical H1
- Fastener Head Height:
- Sep-32 in.
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 0.612 - 0.625 in.
- Fastener Height:
- 0.272 - 0.291
- Fastener Length:
- 1
- Fastener Width:
- 0.698 - 0.722
- Field Application:
- Electrical, Plumbing, Heating and Air Conditioning Industries
- Grade:
- 5
- Hardness:
- Rockwell C25-34
- Language Code:
- EN
- Material Standard:
- AISI 1008 - 1026
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Gr_5_Hex_Bolt_Dom_St-Zn.pdf
- Order Minimum Imperial:
- 50
- Order Minimum Uom Imperial:
- EA
- Outside Diameter:
- 0.4305 - 0.4375 IN
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 4.57 in
- Product Length:
- 3 in
- Product Weight:
- 1411 g
- Product Width:
- 76.2 MM
- Sub Division:
- Electrical-E H2
- Tensile Strength:
- 120000 psi minimum
- Thread Per Inch:
- 14
- Thread Standard:
- ASME B18.2.1-2012
- Voltage Rating:
- Zinc Chromate
- Wrenching Height:
- 0.195
- Yield Strength:
- 92000 psi minimum
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- G5HC and JG5HC
- Product Finish:
- Zinc
- Product Details:
- Hexagonal Bolt
- Product Material:
- Steel
Metallics JG5HC119 – Frequently Asked Questions
1) What thread size and length is the Metallics JG5HC119 hex bolt?
It is a 7/16-14 hex cap screw, 1 inch long. The thread is 14 threads per inch (UNC coarse), and the shank measures 0.4305 to 0.4375 inch outside diameter. So it takes a 7/16-14 nut or a tapped 7/16-14 hole.
2) Is the Metallics JG5HC119 strong enough for mounting a motor to a machine base?
That is the application it is built for. It is a Grade 5 medium carbon steel cap screw, heat treated to Rockwell C25-34, with 120,000 psi minimum tensile and 92,000 psi minimum yield. Grade 5 is the normal choice for motor mounting, equipment bases, and automotive or truck repair work.
3) Is the Metallics JG5HC119 bolt Buy American or ARRA compliant for a government job?
No. It is not Buy American compliant and not ARRA compliant, and the country of origin is listed as multiple. For a federally funded project with domestic sourcing requirements, you will need a domestic-origin Grade 5 hex cap screw instead.
4) Will a zinc plated Grade 5 bolt hold up outdoors or in a wet mechanical room?
The JG5HC119 is steel with a zinc finish, which handles indoor and sheltered mechanical spaces well but is not a marine or continuously wet coating. For direct weather exposure or washdown areas, hot dip galvanized or stainless is the better call.
5) How many bolts come in a jar of Metallics JG5HC119?
They ship 50 pieces in a jar, and 50 each is the order minimum. The jar as packed weighs 1411 g.
6) Does the thread on this Metallics hex bolt conform to a dimensional standard?
Yes. The JG5HC119 is made to ASME B18.2.1-2012, the dimensional standard for square and hex bolts and screws, from AISI 1008-1026 steel. If a drawing calls out B18.2.1 hex cap screws, this meets that callout.
7) How much grip length does a 1 inch long 7/16-14 Grade 5 bolt give me?
Length is measured under the head, so the 1 inch dimension on the JG5HC119 is your usable grip plus thread engagement; the head itself adds 0.272 to 0.291 inch of height on top. Size your stack so the bolt still picks up full thread in the nut or tapped hole.
8) Can electrical and HVAC contractors use these bolts for strut, hangers, and equipment mounting?
Yes, the G5HC and JG5HC series is stocked for the electrical, plumbing, heating and air conditioning trades. A 7/16-14 x 1 Grade 5 hex cap screw is a common size for equipment mounting and hanger connections where a Grade 2 bolt is not strong enough.
