Metallics JMHTB14501 Bolts M14 x 50 C10.9 Hx Tap Blt St-zn (Jar 50)

Metallics JMHTB14501 Bolts M14 x 50 C10.9 Hx Tap Blt St-zn (Jar 50)

(No reviews yet) Write a Review

Model: JMHTB14501
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$52.59
$3.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Bolts M14 x 50 C10.9 Hx Tap Blt St-zn (Jar 50)

  • Features

    • Used in automotive and fleet industries where greater tensile strength is required that can be achieved with a class 8.8 fastener
    • A Hex headed extrnally threaded fastener with washer-face beneath the head, a metric thread pitch, made from high alloy steel and heat-treated. The threads on the shank extended all of the way to directly beneath the head.

  • Additional Notes

    • Other sizes and quantities available by request

Manufacturer Resources

Product Specs

Arra Compliant:
N
Buy American Compliant:
No
Division:
Electrical H1
Fastener Head Type:
Hex
Fastener Head Width:
20.64 - 21 in.
Fastener Height:
8.62 - 8.98
Fastener Length:
50mm
Fastener Width:
22.36
Grade:
10.9
Hardness:
Rockwell C32-39
Language Code:
EN
Order Minimum Imperial:
50
Order Minimum Uom Imperial:
EA
Outside Diameter:
19.37 IN
Pack Type:
Jar
Product Group:
Fasteners
Sub Division:
Electrical-E H2
Tensile Strength:
150800 psi minimum
Thread Direction:
Right Hand
Thread Pitch:
1.25
Thread Type:
UNC
Yield Strength:
136300 psi minimum
Department:
Electrical
Product Subgroup:
Bolts
Product Type:
Hexagonal Bolt
Type2:
Hexagonal Bolt
Series:
MHTB and JMHTB
Product Finish:
Zinc
Product Details:
Hexagonal Bolt
Product Material:
Steel

Metallics JMHTB14501 – Frequently Asked Questions

1) What thread size and pitch are the Metallics JMHTB14501 hex bolts?
The JMHTB14501 is an M14 bolt with a 1.25 mm thread pitch, right hand thread, and a 50 mm length. That 1.25 pitch is the fine-thread M14, not the coarse 2.0, so it will not run into a standard coarse M14 nut or tapped hole. Check the tapped hole before ordering.
2) Is a class 10.9 bolt strong enough to replace an 8.8 bolt on fleet or equipment repair?
Yes. The JMHTB14501 is grade 10.9 with a minimum tensile strength of 150,800 psi and minimum yield of 136,300 psi, which is the step up from class 8.8 used where higher clamp load is needed. It is high alloy steel, heat treated to Rockwell C32-39. Going the other way, do not substitute an 8.8 where a 10.9 was specified.
3) Do these Metallics bolts meet Buy American or ARRA requirements for a government job?
No. The JMHTB14501 is not Buy American compliant and is not ARRA compliant, with multiple countries of origin on record. If your contract carries a domestic sourcing clause, this part will not satisfy it.
4) Are these M14 hex bolts fully threaded or do they have a shoulder?
Fully threaded. The threads on the JMHTB14501 run all the way up to directly beneath the hex head, and there is a washer face under the head. If your joint needs an unthreaded shank through the shear plane, this tap bolt is the wrong style.
5) Will zinc plated grade 10.9 bolts hold up outdoors?
The JMHTB14501 is steel with a zinc finish, which handles indoor and sheltered use and light weather exposure. For sustained wet, coastal, or chemical exposure a zinc plated alloy bolt is not the right pick, and high strength alloy fasteners are sensitive to corrosion driven cracking, so specify a fastener rated for that environment instead.
6) How are the Metallics M14 x 50 hex tap bolts packaged and what is the minimum order?
They ship in a jar of 50, and the order minimum is 50 each. Handy for a service truck or a shop bin rather than bulk box quantities. Metallics lists other sizes and quantities by request.
7) What head style is the JMHTB14501 and what drives it?
Hex head, driven with a wrench or socket, with a washer face underneath so it seats flat without a separate washer on a clean machined surface. Part of the Metallics MHTB and JMHTB hex tap bolt series.
