Bolts M6 X 40 Hxbt SS (Jar 100)
Additional Notes
- Other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Dimensional Standard:
- DIN 933
- Division:
- Electrical H1
- Fastener Head Type:
- Hex
- Fastener Head Width:
- 9.78 - 10 in.
- Fastener Height:
- 3.85 - 4.15
- Fastener Length:
- 40mm
- Fastener Width:
- 11.05
- Grade:
- A-2
- Language Code:
- EN
- Material Standard:
- ISO 3506
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-Hex_Hd_Metric_Bolt_18-8_and_316_SS.pdf
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- CT
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 5.75 in
- Product Length:
- 3.5 in
- Product Weight:
- 971 g
- Product Width:
- 88.9 MM
- Sub Division:
- Electrical-E H2
- Thread Pitch:
- 1
- Thread Standard:
- ISO 724|ISO 965-1
- Wrenching Height:
- 2.7
- Department:
- Electrical
- Product Subgroup:
- Bolts
- Product Type:
- Hexagonal Bolt
- Type2:
- Hexagonal Bolt
- Series:
- JMSBHC
- Product Details:
- Hexagonal Bolt
- Product Material:
- 18-8 Stainless Steel
Metallics JMSBHC69 – Frequently Asked Questions
1) What grade of stainless are these Metallics M6 bolts, and are they OK outdoors?
They're 18-8 stainless, designated A2 under ISO 3506. A2/18-8 handles general outdoor and damp indoor exposure well, which is why it gets used for enclosure and strut hardware. For coastal salt spray or pool chemical areas, step up to 316 (A4) stainless instead.
2) What size wrench or socket do I need for these M6 hex bolts?
Standard DIN 933 M6 heads take a 10mm wrench. The spec sheet gives a head width at the 10 mark and a head height in the 3.85 to 4.15 range, consistent with a 10mm across-flats hex head. A 10mm socket or combination wrench is what you want on the truck.
3) How many bolts come in a jar of Metallics JMSBHC69, and is 100 the minimum order?
Each jar holds 100 M6 x 40 stainless hex bolts, and 100 count is the order minimum, so a single jar is the smallest buy. Total shipping weight for the jar is 971 g. Other sizes and quantities can be arranged on request.
4) Do these M6 bolts meet Buy American and ARRA requirements for a public project?
The JMSBHC69 is flagged compliant for both ARRA and Buy American in the manufacturer data, with country of origin China. On federally funded work, submit those compliance flags with your product data for the specifying authority's sign-off, since fastener provisions vary by contract.
5) Can I mix these stainless bolts with galvanized or plated steel nuts?
Mechanically yes, any coarse M6 nut threads on. But pairing 18-8 stainless with zinc or galvanized steel in a wet location sets up galvanic action that eats the coating on the cheaper part. For outdoor or damp runs, use A2 stainless nuts and washers to match the bolt.
6) Are nuts and washers included with the Metallics JMSBHC69 jar?
No. The jar is 100 hex bolts only, M6 x 40 in 18-8 stainless. Order matching A2 stainless hex nuts and flat washers separately if the joint needs them.
