Bravura Tampa with Square Trim...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$139.00
$66.68
Bravura Bravura Tampa with Square Trim Privacy Leverset, Grade 2 BVR-BV333712

Bravura Tampa with Square Trim Privacy Leverset, Grade 2

(No reviews yet) Write a Review

Model: BV333711
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$139.00
$66.68
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bravura Tampa with Square Trim Privacy Leverset

Experience true luxury with high quality Bravura door hardware. This piece exceeds ANSI rated grade 2 standards on the internal mechanics for long lasting smooth quality you can feel with every use.

Privacy Function: Privacy door hardware features a locking mechanism on the interior for use on bedroom and bathroom doors where locking is needed. The exterior side features a small pin hole to unlock the door hardware from the outside.

Features

  • Solid Brass
  • Reversible
  • Smooth operation
  • Grade 2
  • Residential

Specifications

  • Door Prep
    • 2-1/8" deadbolt cross bore
    • 2-1/8" cross bore
    • 1" edge bore
    • 1" x 2-1/4" latch face
  • Door Thickness: 1-3/8” ~ 2”, 2-1/4” Extension Kits Available
  • Latches
    • Backset: 2-3/8” Standard and 2-3/4” Optional
    • Faceplate: 1” x 2-1/4” round corner
    • Bolt: 1/2” Solid Brass throw
  • Backset: 2-3/8” Standard and 2-3/4” Optional
  • Strikes: Full lip round corner (9103) and square

Technical Specification Download

Manufacturer Resources

Product Specs

Subcategory:
Bored Locksets
Series:
Tampa
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Commercial/Residential:
Residential
Lock Function:
Privacy
Product Type:
Leversets
Grade:
Grade 2
Product Attribute:
Cylindrical Locks
Product Function:
Privacy/Bed/Bath
Product Category:
Mechanical Locks
Department:
Door Hardware

Bravura BV333711 – Frequently Asked Questions

1) Will the Bravura Tampa privacy leverset fit a 1-3/4 inch door, and what about thicker doors?
The Tampa privacy leverset covers 1-3/8 inch through 2 inch doors as supplied, so a standard 1-3/4 inch interior door is well inside the range. For 2-1/4 inch doors there are extension kits. If your bedroom and bath doors are a mix of 1-3/8 and 1-3/4, the same lock handles both without a different part number.
2) What door prep does the Bravura Tampa leverset need, and will it drop into an existing bored door?
Prep is the standard bored pattern: 2-1/8 inch cross bore, 1 inch edge bore, and a 1 inch x 2-1/4 inch latch face. A door already bored for a common residential cylindrical lock takes it with no new drilling. The latch faceplate is 1 inch x 2-1/4 inch with round corners, so it sits in an existing round corner mortise for the latch.
3) Do I need to order a 2-3/8 or 2-3/4 inch backset for the Bravura Tampa lever?
Backset is a required choice when you order: 2-3/8 inch is standard and 2-3/4 inch is the option. Measure from the door edge to the center of the existing bore. Those are the two backsets used on residential doors, so one of the two will match what is already drilled. Getting it wrong means the lever will not line up with the hole.
4) Will the Bravura Tampa privacy latch work with the strike plate already in my door frame?
The bolt is a 1/2 inch solid brass throw, which is the normal residential latch projection, and it ships with a choice of strikes: a full lip round corner (9103) and a square strike. So whether your frame is prepped square or round corner, there is a matching strike. If you are reusing the frame's existing strike, the 1/2 inch throw will engage a standard residential strike pocket.
5) How does the privacy function on a bedroom or bathroom lever work if someone gets locked in?
Privacy function means it locks from the inside only, with no key. The outside face has a small emergency pin hole, so a straightened wire or the supplied tool releases it from the corridor side. That is what makes it right for bedrooms and baths and wrong for an exterior or entry door, where you want a keyed entrance lock instead.
6) What is the closest equivalent to the Bravura Tampa privacy leverset in another brand?
The Bravura Tampa square trim leverset is a Grade 2 privacy lever for bed and bath doors. The Hager 2540 with the Withnell lever is also a Grade 2 privacy cylindrical lock, and it lists a door thickness range of 1-3/8 inch to 2 inch, matching the 1-3/8 inch to 2 inch range the Tampa covers. The Withnell is a curved commercial-style lever where the Tampa uses square trim, so the mechanical function lines up and the visual style is what changes.
7) The Bravura Tampa is marked residential - what should go on a commercial bathroom door instead?
The Bravura Tampa is a residential Grade 2 privacy leverset. For a heavier-traffic opening the Arrow MK02-TA is a privacy lock for bed and bath doors carried at Grade 1 with a fire rating and a door thickness range of 1-3/4 inch to 2 inch. It uses a Tudor knob rather than a lever, so if ADA lever operation is a requirement for the facility that trades one attribute for the other.
8) I need the same look as the Bravura Tampa on a closet door that should not lock - what do I order?
A privacy lever like the Bravura Tampa has an interior locking mechanism with an emergency pin hole outside, which a closet does not need. Passage function is the match there: the Falcon B101 is a Grade 2 cylindrical passage lever with a non-handed design, and the Hager 2510 is a Grade 2 passage lever with the Withnell design covering 1-3/8 inch to 2 inch doors. Both latch and release without any locking, on the same 2-1/8 inch cross bore prep a cylindrical lever uses.
9) Is the Bravura Tampa lever handed, or does one part work on both left and right hand doors?
Non-issue here. The Tampa lever is reversible, so a single lock covers left and right hand doors. For a property manager doing a whole floor of bedroom and bath doors, that means one SKU per finish rather than tracking handing door by door.
10) Is a Grade 2 lever like the Bravura Tampa heavy enough for an apartment building or hotel, or do I need Grade 1?
The Tampa is Grade 2 and is built as residential hardware, so it suits apartments, condos, and single-family bedroom and bath doors. For high traffic commercial openings, step up to a Grade 1 cylindrical lever such as the Corbin Russwin CL3110 or the Falcon K101, both Grade 1 heavy duty. If you want a Grade 2 commercial lever instead, the Hager 2540 privacy lock with the Withnell lever is the closer commercial-grade privacy option.
11) I need matching passage and dummy levers to go with a privacy lever on the same hallway. What are my options?
The Tampa privacy leverset is the bed and bath function only. For matching passage and dummy hardware in the same trim family you would order those functions separately. If you are willing to switch brands for the whole opening set, the Baldwin Estate 5103 is sold in privacy, passage, and left and right hand half dummy, all with the 5048 rose, so the trim matches across every door in a hallway.
12) Can I use the Bravura Tampa privacy lever on a fire rated door?
The Tampa is a residential Grade 2 privacy lever. For a fire rated opening, choose a lock the manufacturer rates for it, such as the Corbin Russwin CL3110 Grade 1 passage lock or the Falcon K101 Grade 1 passage lock, both of which carry a fire rating. On a privacy function specifically, the Arrow MK02-TA privacy lock is fire rated, though it is a knob rather than a lever.
13) Does the Bravura Tampa privacy set include a deadbolt or work with one?
No deadbolt is part of a privacy lever, and there is no keyed cylinder on it. The door prep does call out a 2-1/8 inch deadbolt cross bore alongside the 2-1/8 inch lock cross bore, so a door prepped for both a lever and a deadbolt takes the Tampa in the lower bore. The deadbolt itself is a separate order.
14) Is there a residential-grade privacy lever that costs less to standardize on than the Bravura Tampa?
The Kwikset 300BRNL Breton privacy lever set is a Grade 3 privacy lever for bed and bath doors with a door thickness range of 1-3/8 inch to 1-3/4 inch. The Bravura Tampa is Grade 2 and covers 1-3/8 inch to 2 inch, with 2-1/4 inch extension kits available. On a 2 inch door the Breton is outside its stated range and the Tampa is not, so thickness decides this before grade does.
15) Can a keyed entry lever be used in place of the Bravura Tampa privacy leverset?
No - they are different functions on the same cylindrical prep. The Bravura Tampa locks from the inside with a pin hole release outside and takes no key. The Hager 2525 is a Grade 2 cylindrical entry lock and the Cal-Royal AG00 is a Grade 2 entrance lever with a 6-pin Schlage C keyway keyed different, both of which lock and unlock by key from the corridor side. On a bedroom or bathroom door that means an occupant can be locked out rather than released from outside.
16) What do I put on the inactive side of a double door to match a Bravura Tampa lever?
A dummy trim is the part for a door leaf with no latch. The Callan Bentley is a Grade 2 dummy lever and the BEST 7KC Series 1DT is a Grade 2 medium duty single dummy trim cylindrical lever. The Bravura Tampa is a working Grade 2 privacy leverset with a 1/2 inch solid brass latch throw, so it is not the part for a fixed leaf.
17) Which privacy lever handles a door thicker than 2 inches?
The Bravura Tampa covers 1-3/8 inch through 2 inch doors, with 2-1/4 inch extension kits available for thicker stock. Among comparable cylindrical levers the Falcon K101 states a 1-3/8 inch to 2-1/4 inch door thickness range in one lockset, though it is a Grade 1 heavy duty passage function rather than privacy, so it does not lock. For a thick bedroom or bath door that still needs to lock, the Tampa with the extension kit is the route that keeps privacy function.
18) Bravura Tampa versus a Baldwin Estate privacy lever - what is the difference?
Both are privacy levers for bed and bath doors. The Baldwin Estate 5103 privacy lever is supplied with the 5048 rose, a round rose trim, while the Bravura Tampa uses square trim and is an ANSI Grade 2 residential set in solid brass, reversible, with a 2-3/8 inch standard or 2-3/4 inch optional backset. Choose on trim shape and backset first - the rose profile is what a property manager will see next to existing doors.
19) What lever goes on a storeroom or utility door in the same building as Bravura Tampa privacy sets?
Storeroom function is the one for a door that stays locked outside and always releases from inside. The Cal-Royal AG05 is a Grade 2 storeroom lever lockset with a deadlocking latchbolt covering 1-3/8 inch to 1-3/4 inch doors, and the Hager 2580 with the Withnell lever is a Grade 2 storeroom lock for 1-3/8 inch to 2 inch doors. Both are keyed; the Bravura Tampa is a non-keyed privacy set and will not secure a storeroom.
20) What finishes does the Bravura Tampa square trim privacy lever come in?
Three finishes: US15 satin nickel, US10B oil rubbed bronze, and US19 black. That is the full range on the Tampa privacy lever, so if you are matching existing hardware across a set of doors, the match has to be one of those three.
21) What is the Bravura Tampa lever made of?
Solid brass, including the latch bolt, which is a 1/2 inch solid brass throw. Brass construction is what you want on a bathroom door where humidity is constant.
22) Is a keypad lever a substitute for a bathroom privacy lever?
Not for the same job. Keypad levers such as the Delaney LP250 electronic keypad leverlock, rated Grade 2, and the Lockey 2835 mechanical pushbutton keyless lever with a 1-3/16 inch to 2 inch door thickness range are built for controlled access at an entrance. A bed or bath door needs the Bravura Tampa privacy arrangement: interior locking with a small exterior pin hole that opens the door from outside in an emergency, no code to enter.
