Bridgeport Fittings 1025 1/2" Aluminum Raintight LB Service Entrance Fitting with NPT Threads

Bridgeport Fittings 1025 1/2" Aluminum Raintight LB Service Entrance Fitting with NPT Threads

(No reviews yet) Write a Review

Model: BPF1025

In Stock (leaves warehouse same day if ordered before 3pm ET)

$18.70
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bridgeport Fittings Aluminum Raintight LB Service Entrance Fitting with NPT Threads

Bridgeport Fittings offers this aluminum raintight LB service entrance fitting, engineered for outdoor conduit installations that require a durable, weatherproof directional fitting at the point of service entry. Sized for 1/2" trade size conduit with NPT threads, this LB-style body allows conductors to enter and exit at a 90° change of direction while helping keep the service entrance connection protected from rain and moisture. Constructed from lightweight, corrosion-resistant aluminum, this fitting is built to hold up to outdoor exposure while providing electricians a straightforward, threaded connection point for residential and commercial service entrance work. Its raintight LB configuration and 1/2" NPT threads make it a practical choice wherever a compact, weather-resistant conduit body is needed at the service entrance.

Key Features

  • Trade Size: 1/2" NPT threads sized for standard service entrance conduit connections.
  • Durable Aluminum Construction: Lightweight, corrosion-resistant aluminum body supports long-term outdoor performance.
  • Raintight Design: LB fitting configuration is built to help shield the service entrance point from rain and moisture intrusion.
  • NPT Threaded Connection: Threaded hub delivers a secure, mechanically sound connection to conduit and service entrance equipment.
  • LB Body Configuration: Provides a 90° change of direction at the service entrance while offering access for pulling and routing conductors.
  • Compact 1/2" Size: Sized to fit standard 1/2" conduit runs common to residential and light commercial service entrances.

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Typical Applications

  • Residential and Commercial Service Entrance Installations
  • Outdoor and Weatherproof Conduit Routing
  • Rigid and IMC Conduit Systems Requiring a Directional Change
  • New Construction and Electrical Service Upgrades
  • Conduit Runs Terminating at the Meter Base or Service Panel

Why Bridgeport Fittings?

Bridgeport Fittings builds this LB service entrance fitting from aluminum to deliver a lightweight yet durable raintight body, and its 1/2" NPT-threaded connection is designed to provide a secure, dependable termination point for service entrance conductors. The LB configuration gives installers the flexibility to change direction at the service entrance while the raintight design helps keep the connection protected outdoors. Electrical professionals count on Bridgeport Fittings for consistent, code-focused quality in raintight conduit fittings used across residential and commercial service entrance installations.

Manufacturer Resources

Product Specs

list_batch:
BPF-20260918
Product Type:
Type LB Conduit Body
Connection Type:
Threaded (NPT)
Configuration:
LB
Department:
Electrical
Product Subgroup:
Conduit Bodies & Covers
Product Material:
Aluminum
Product Size:
1/2"
Product Group:
Conduit & Raceway

Bridgeport Fittings BPF1025 – Frequently Asked Questions

1) Will the Bridgeport 1025 LB fitting thread onto 1/2 inch rigid or IMC conduit?
Yes. The Bridgeport 1025 is a 1/2 inch trade size LB body with NPT threaded hubs, so it threads directly onto 1/2 inch rigid metal conduit or IMC, both of which are cut and threaded to NPT. It will not accept EMT unless you adapt to threads first with a set-screw or compression male adapter.
2) What is the difference between a Type LB conduit body and a Type C conduit body?
They differ in the direction the conductors take. The Bridgeport Fittings 1025 is an LB configuration, meaning conductors make a 90 degree change of direction with a removable cover for pulling - the classic arrangement where a conduit run turns through a wall into a meter base or panel. A Type C body, such as the Crouse-Hinds C15MTC-6 Condulet, is a straight-through pull body: it keeps the run in line and simply adds an access opening for pulling conductors. If your run needs to turn at the service entrance, the LB is the body that does it; if the run is straight and you only need a pull point, the Type C is the shape to specify.
3) Can I use the Bridgeport 1025 on an EMT run, or do I need a different conduit body?
The Bridgeport Fittings 1025 has threaded NPT hubs, so it lands on threaded conduit - rigid or IMC - and is not the fitting for a bare EMT termination. For EMT, look to a combination-EMT body such as the Crouse-Hinds C15MTC-6 Condulet, which is built for EMT connections rather than an NPT thread. Confirm the trade size you need either way; the 1025 is a 1/2 inch body.
4) What does an LB conduit body actually do at a service entrance?
An LB body makes a 90 degree change of direction where the conduit leaves the wall and turns toward the meter base or panel, and the removable cover gives you an opening to pull conductors through instead of fighting them around an elbow. On the 1025 the body is raintight, so it is meant for the outdoor side of the service where water would otherwise track down the conduit into the connection.
5) Is an aluminum LB fitting OK outdoors, or should I use something else?
Aluminum is corrosion resistant and the 1025 is built as a raintight body for outdoor exposure, which is why it is the common choice on residential and light commercial service entrances. Where aluminum is a poor choice is direct contact with concrete, masonry with lime, or heavily alkaline or coastal salt conditions, and in those spots electricians generally step to a coated or non-aluminum body instead.
6) Can I use this LB for underground conduit coming up a wall to the panel?
Yes, that is a normal use. The 1025 sits at the top of the riser and turns the 1/2 inch conduit 90 degrees through the wall toward the panel or meter base, and the raintight body keeps rain out at that transition. Thread it to rigid or IMC, since the hubs are NPT.
7) Is an aluminum conduit body a suitable substitute for a Condulet on an outdoor service entrance?
For an outdoor turn at the point of service entry, the Bridgeport Fittings 1025 is the type of body specified for the job: an aluminum, corrosion-resistant raintight LB sized for 1/2 inch conduit with NPT threads, intended for residential and commercial service entrance work terminating at a meter base or panel. A Crouse-Hinds Condulet Series 5 body such as the C15MTC-6 is a Type C outlet body for combination EMT, so it serves a straight pull point on an EMT run rather than a threaded directional turn. Match the body to the raceway type and the direction the run has to take.
8) What is the Bridgeport part number and how do I order the right size LB?
Order Bridgeport Fittings part number 1025 for the 1/2 inch aluminum raintight LB. Size the fitting to the trade size of the conduit it lands on, not to the wire, so a 1/2 inch conduit run terminating at the meter base or panel takes the 1025.
9) Does the Bridgeport 1025 come with a cover and gasket, or do I buy those separately?
The 1025 is sold as a raintight LB service entrance fitting, and the raintight function depends on its cover and gasket being in place. Bridgeport catalogs it as a complete fitting rather than a bare body, so plan on it arriving assembled. If a cover is ever damaged on site, replace it with the matching Bridgeport raintight cover for the 1/2 inch body so the weather seal is maintained.
