Burndy 1PLD44 UNITAP Aluminum Multi-Tap Connector

Burndy 1PLD44 UNITAP Aluminum Multi-Tap Connector, UV-Rated Black, 4-Port

The Burndy 1PLD44 is an aluminum multiple tap connector from the UNITAP™ line, built with a UV-rated black housing for long-term outdoor durability. This double-sided entry (2-sided) connector provides 4 ports for splicing and tapping runs, accepting copper conductors from #14 AWG to 4 AWG and aluminum conductors from 8 AWG to 4 AWG. An oxide inhibitor is pre-installed at the factory, saving installers a field application step and helping protect the connection against corrosion. As a mechanical connector, the 1PLD44 is intended for splicing and tapping applications where a bolted, multi-port aluminum body is preferred over a compression or insulation-piercing style connection.

Key Features

• 4-Port Design: Four ports allow multiple taps or runs to be terminated at a single aluminum connector body.
• Double-Sided Entry: 2-sided access simplifies routing and termination of conductors from either side of the connector.
• Durable Construction: Aluminum body with a UV-rated black finish resists degradation from sunlight exposure in outdoor installations.
• Multi-Tap Connector Type: Configured as a run/tap connector for joining a main conductor to one or more branch conductors.
• Wide Conductor Range: Accepts copper conductors from #14 AWG to 4 AWG and aluminum conductors from 8 AWG to 4 AWG.
• Pre-Installed Oxide Inhibitor: Oxide inhibitor is factory-applied to help maintain a low-resistance, corrosion-protected connection.
• UNITAP™ Trade Name: Part of Burndy's UNITAP™ family of mechanical multi-tap connectors.

Technical Specifications

• Ports: 4
• Connector Type: Multi Tap
• Product Type: Run/Tap
• Trade Name: UNITAP™
• Conductor - AL Str Size Range: 8 AWG-4 AWG
• Conductor - Copper Str Size Range: 14 AWG - 4 AWG

Typical Applications

• Electrical Distribution and Splicing
• Panelboard and Switchgear Wiring
• Grounding and Bonding Connections
• Outdoor and Wet-Location Electrical Installations
• Renovation and New Construction Electrical Work

Why Burndy?

Burndy's 1PLD44 combines an aluminum, UV-rated black connector body with a pre-installed oxide inhibitor, reducing field prep time while supporting a reliable, corrosion-resistant connection. As part of the UNITAP™ family, this multi-tap connector is built for the demands of professional electrical splicing and tap work across copper and aluminum conductors. The double-sided, 4-port body gives installers flexibility in laying out multiple taps at one location, while the UV-rated black housing supports use in exposed, outdoor-facing installations where sunlight exposure would otherwise degrade an unprotected connector body over time.
