Burndy YS30L HYLINK Compression Splice, 300 kcmil Cu, Standard Barrel, Tin-Plated

Burndy YS30L HYLINK Compression Splice, 300 kcmil Cu, Standard Barrel, Tin-Plated

(No reviews yet) Write a Review

Model: YS30L

In Stock (leaves warehouse same day if ordered before 3pm ET)

$10.97
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Burndy YS30L HYLINK Compression Splice, 300 kcmil Cu, Standard Barrel, Tin-Plated

The Burndy YS30L HYLINK Compression Splice is built for 300 kcmil copper compact stranded conductors, with a chamfered standard barrel for smooth insertion in limited-space applications. Copper construction, tin-plated, UL/CSA listed, rated 90°C and up to 35kV with a 600V minimum. WHITE color code and 17/298 die index simplify tool selection.

Key Features

  • Conductor Size: Sized for 300 kcmil copper compact stranded conductors.
  • Durable Construction: Copper body, tin-plated for conductivity and corrosion resistance.
  • Standard Barrel Design: Chamfered barrel; HYLINK design for limited-space applications.
  • Electrical Rating: 600V minimum up to 35kV, 90°C operating temperature.
  • Color Code: WHITE for quick size identification.
  • Die Index: Compatible with 17 or 298 die index compression tooling.
  • Compact Dimensions: Length 2.47 in (63 mm), B length 1.06 in, strip 1-1/8 in.

Certifications & Compliance

  • UL Listed
  • CSA Approved
  • Meets UL486A-486B Industry Standards

Technical Specifications

  • Product Material: Copper
  • Minimum Pack Quantity: 1
  • Voltage - Maximum: 35000
  • Standards - Industry Standards Met: UL486A-486B
  • Die Index: 17;298
  • Plating Type: Tin - Electro Plated
  • Sub Brand: HYLINK
  • Conductor - Copper Str Compact Size: 300
  • Trade Name: HYLINK™
  • Application: For Limited Space Applications
  • Certification - CSA Approved: Yes
  • UPC 12 Digit: 7818105081522
  • Rating - KVA: 35 kV
  • Plated: Y
  • Feature - Barrel Style: Chamfered
  • Product Details: YS-L, Standard Barrel
  • Dimension - B Length fraction: 1-1/16 in
  • Industry Standard(s): UL486A-UL486B
  • Rating - Minimum Voltage: 600
  • Dimension - B Length inch: 1.06 in
  • Dimension - Strip Length inch: 1-1/8
  • Certification - cULus: No
  • UPC: 781810508152
  • Dimension - L Length Overall mm: 63 mm
  • Certification - UL Recognized: No
  • UL Listed: Yes
  • Standards - RoHS Compliance Status: CM
  • Dimension - Length Overall inch: 2.47 in
  • Certification - ETL: No
  • Product Family: COMPRESSION
  • Product Type: Splice

Typical Applications

  • Commercial and Industrial Electrical Installations
  • Limited-Space Splicing Applications
  • Medium-Voltage Cable Splicing up to 35kV
  • Copper Conductor Termination and Repair

Why Burndy?

Burndy's YS30L HYLINK splice pairs copper construction with a tin-plated, chamfered barrel for dependable connections. UL Listed and CSA Approved to UL486A-486B, it delivers reliable performance up to 35kV for limited-space splicing work.

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
BURNDY-20260915
Plating:
Tin Plated
Minimum Pack Quantity:
1
Voltage - Maximum:
35000
Standards - Industry Standards Met:
UL486A-486B
Feature - Barrel Type:
Standard
Die Index:
17;298
Color Code:
White
Plating Type:
Tin - Electro Plated
Sub Brand:
HYLINK
Conductor - Copper Str Compact Size:
300
Trade Name:
HYLINK™
Certification - CSA Approved:
Yes
UPC 12 Digit:
7818105081522
Rating - KVA:
35 kV
Plated:
Y
Feature - Barrel Style:
Chamfered
Product Details:
YS-L, Standard Barrel
Dimension - B Length fraction:
1-1/16 in
Industry Standard(s):
UL486A-UL486B
Rating - Minimum Voltage:
600
Dimension - B Length inch:
1.06 in
Connector Type:
STANDARD BARREL
Conductor - Copper Str Size:
300 kcmil
Dimension - Strip Length inch:
1-1/8
Certification - cULus:
No
UPC:
781810508152
Dimension - L Length Overall mm:
63 mm
Certification - UL Recognized:
No
UL Listed:
Yes
Standards - RoHS Compliance Status:
CM
Dimension - Length Overall inch:
2.47 in
Certification - ETL:
No
Product Type:
Compression Splice
Product Material:
Copper
Wire Size:
300 kcmil
Department:
Electrical
Product Group:
Wire Connectors & Terminals
Product Subgroup:
Splice Kits
Application:
For Limited Space Applications

Burndy YS30L – Frequently Asked Questions

1) What conductor size does the Burndy YS30L splice take?
The YS30L is sized for 300 kcmil copper conductors, specifically compact stranded copper. It is a one-size splice, so both ends take 300 kcmil copper. Don't use it on aluminum conductors; it is a copper-bodied, tin-plated copper connector.
2) Which compression dies do I need for a Burndy YS30L?
Crimp it with tooling set to die index 17 or 298. The connector is also color coded WHITE, which is the quick visual cross-check against the die chart on the tool before you make the crimp.
3) How much insulation do I strip back for the YS30L splice?
Strip 1-1/8 inch of insulation off each conductor end. That matches the barrel depth on each side: overall length is 2.47 inches (63 mm) with a B length of 1.06 inches, so each conductor bottoms out around the center stop.
4) Can I use the Burndy YS30L on a 15kV or 25kV medium-voltage cable splice?
Yes. The YS30L HYLINK splice is rated from a 600V minimum up to 35kV, so 15kV and 25kV shielded cable work is within its rating. It is UL Listed and CSA Approved to UL486A-486B. Rebuilding the insulation and shield over the connector is a separate step with tape or a splice kit.
5) Is a 3M Scotchcast 82-A resin splice kit an alternative to the Burndy YS30L compression splice?
They do different jobs on the same conductor. The Burndy YS30L is a compression splice: a tin-plated copper standard barrel that is crimped onto 300 kcmil copper conductors with 17 or 298 die index tooling, giving the metallic joint itself. The 3M Scotchcast 82-A Series is an inline resin power cable splice kit rated 1-5 kV, which supplies the poured insulation and jacketing system around a joint. On a medium-voltage cable you typically need both a mechanical or compression connector and an insulating system, so the 82-A kit is a complement to a barrel splice rather than a replacement for it.
6) For a splice on a 25 kV feeder, which is rated for the voltage - the Burndy YS30L or the 3M Scotchcast 82-A kit?
The Burndy YS30L carries a 600 V minimum rating and is rated up to 35 kV, so it covers a 25 kV application as the compression connector. The 3M Scotchcast 82-A Series inline resin splice kit is a 1-5 kV product, so it does not cover 25 kV; for that class you would pair the YS30L barrel with an insulating system rated to the feeder voltage.
7) Will a 300 kcmil compression splice fit inside a crowded pull box or duct?
That is what the HYLINK standard barrel is built for. At 2.47 inches overall it is a short body, and Burndy lists it for limited-space applications. The barrel ends are chamfered so the conductor feeds in without birdcaging when you are working at an awkward angle.
8) What is the difference between a YS-L standard barrel splice and a long barrel version?
The YS30L is the YS-L standard barrel configuration: a single crimp zone per side with a B length of 1.06 inches and 2.47 inches overall. That keeps the connector short for tight boxes. Long barrel splices in the same family run longer to allow additional crimps per side, which is what you reach for when you want more crimps for pull-out strength and have the room to fit them.
9) Is a tin-plated copper splice OK in a damp or corrosive environment?
The YS30L body is copper with an electroplated tin finish, which is the standard choice for damp or industrial atmospheres because the tin slows oxidation on the copper. It is rated for 90 degrees C operation. In a submerged or direct-buried location you still need an appropriate splice kit or encapsulation over the connector.
10) Does the Burndy YS30L come in a bulk pack or can I buy one?
Minimum pack quantity on the YS30L is 1, so you can order a single splice for a repair rather than committing to a box. Each carries UPC 781810508152 under part number YS30L.
11) Is the Burndy YS30L RoHS compliant for a spec submittal?
RoHS status on the YS30L is recorded as CM (compliant with exemption). For the rest of a submittal package: UL Listed, CSA Approved, built to UL486A-486B, copper with electroplated tin. Burndy also publishes a spec sheet for the part at hubbellcdn.com.
