Bussmann AGA-15 Eaton Series 15A Fast-Acting Fuse, 100-Pack
The Bussmann AGA-15 Eaton Series fast-acting fuse delivers reliable overcurrent protection for electronic circuits, rated 15A at 125Vac, 32Vdc with ferrule end X ferrule end termination for secure seating in compatible fuseholders. Built for a fast-acting response, this small-dimension electronic fuse opens quickly under fault conditions to help safeguard sensitive components and equipment. Each unit carries a 1 kAIC interrupt rating at 32Vac with a non-indicating design, and this listing is packaged as a convenient 100-pack for stocking electronic circuit protection on hand.
Key Features
- Amperage Rating: 15A fast-acting fuse sized for electronic circuit protection.
- Voltage Rating: Rated 125Vac, 32Vdc for reliable overcurrent protection in electronic applications.
- Connection: Ferrule end X ferrule end termination for secure fit in compatible fuseholders.
- Fast-Acting Response: Opens in 4 hr minimum at 100%, 60 min maximum at 135%, and 120 s maximum at 200% of rated current.
- Interrupt Rating: 1 kAIC at 32Vac for dependable fault current interruption.
- Fuse Indicator: Non-indicating design for standard electronic circuit installations.
- Packaging: Standard packaging supplied as a 100-pack for convenient inventory stocking.
Technical Specifications
- Amperage Rating: 15A
- Application: Electronic circuits
- Connection: Ferrule end X ferrule end
- Fuse Indicator: Non Indicating
- Interrupt Rating: 1 kAIC at 32 Vac
- Packaging Type: Standard
- Response Time: 4 hr minimum at 100%, 60 min maximum at 135%, 120 s maximum at 200%
- Voltage Rating: 125 Vac, 32 Vdc
- Product Type: Electronic- small dimension
- Product Length: .252 IN
- Product Height: .626 IN
- Product Weight: .006 LB
- Product Width: .252 IN
Typical Applications
- Electronic Circuit Protection
- Control Panels and Instrumentation
- OEM Electronic Assemblies
- Low-Voltage Electronic Equipment
- Panelboard and Component-Level Circuit Protection
Why Bussmann?
Bussmann by Eaton is a trusted name in circuit protection, and the AGA-15 fast-acting fuse reflects that reliability with defined 15A response characteristics and a stated interrupt rating for consistent performance. Backed by specified response times at 100%, 135%, and 200% of load, this fuse is built to deliver dependable protection for electronic circuits. Choose Bussmann for consistent, professional-grade overcurrent protection in your electronic equipment.
Manufacturer Resources
Product Specs
- Amperage Rating:
- 15A
- Application:
- Electronic circuits
- Connection:
- Ferrule end X ferrule end
- Fuse Indicator:
- Non Indicating
- Interrupt Rating:
- 1 kAIC at 32 Vac
- Packaging Type:
- Standard
- Voltage Rating:
- 125 Vac, 32 Vdc
- Product Group:
- Circuit Protection
- Department:
- Electrical
- Product Subgroup:
- Fuses
- Product Type:
- Fast-Acting Fuse
- Product Length:
- .252 IN
- Product Details:
- Electronic- small dimension
- Product Height:
- .626 IN
- Product Weight:
- .006 LB
- Product Width:
- .252 IN
Bussmann AGA-15 – Frequently Asked Questions
1) Can I use a 15A AGA-15 fuse on a 120V AC control circuit?
Yes, within rating. The AGA-15 is rated 125 Vac and 32 Vdc, so a 120 V AC control circuit is inside its AC rating. On DC it is limited to 32 Vdc, so do not put it on a 48 V or 125 V DC circuit.
2) Is the AGA-15 fast-acting or time-delay, and will it survive motor inrush?
Fast-acting. The AGA-15 opens in 120 seconds maximum at 200 percent of rated current and 60 minutes maximum at 135 percent, with no deliberate time delay built in. That is fine for electronic circuits, instrumentation and control boards, but a load with a heavy inrush surge wants a time-delay (slow-blow) fuse instead or you will be replacing fuses on every start.
3) Is a 1 kAIC interrupting rating enough for my panel?
The AGA-15 carries 1 kAIC at 32 Vac, which suits low-energy electronic and component-level circuits downstream of a transformer or power supply. It is not a branch-circuit fuse for a service or panel where available fault current runs into the thousands of amps; that needs a fuse with a 10 kAIC or higher interrupting rating.
4) Can I tell by looking whether an AGA-15 has blown?
Not from an indicator. The AGA-15 is a non-indicating fuse, so there is no pop-out pin or flag. You check it visually through the body or, more reliably, pull it and test continuity with a meter. If your maintenance crew needs blown fuses spotted at a glance, you want an indicating type.
5) Is the AGA-15 the right fuse for an OEM electronic assembly or instrumentation board?
That is its stated application. The AGA-15 is classed as an electronic small-dimension fuse for electronic circuits, and it is used in control panels and instrumentation, OEM electronic assemblies, low-voltage electronic equipment, and component-level circuit protection. It protects the board side of a power supply, not the feeder to it.
6) How many fuses come in a Bussmann AGA-15 order?
Supplied as a 100-pack in standard packaging, part number AGA-15 from Bussmann by Eaton. That quantity is aimed at shops and MRO cribs stocking spares for control panels and electronic assemblies rather than a one-off replacement.
