Bussmann CCP2-1-30CC UL98 Fusi...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$73.17
Bussmann CCP2-1-30CC UL98 Fusible Disconnect Switch, 30A Single-Pole, Class CC

Bussmann CCP2-1-30CC UL98 Fusible Disconnect Switch, 30A Single-Pole, Class CC

(No reviews yet) Write a Review

Model: CCP2-1-30CC

In Stock (leaves warehouse same day if ordered before 3pm ET)

$73.17
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks

Bussmann CCP2-1-30CC UL98 Fusible Disconnect Switch, 30A Single-Pole, Class CC

The Bussmann CCP2-1-30CC is a UL98 fusible disconnect switch from the Eaton Bussmann series CCP line, engineered for dependable overcurrent protection and safe circuit isolation in industrial, commercial, and OEM electrical systems. This single-pole disconnect is rated 30A and sized for Class CC fuses, giving panel builders and electricians a compact, code-compliant way to add local disconnect and fuse protection to a branch circuit. Built to UL98 performance standards and rated for 60 Hz systems, the CCP2-1-30CC combines the compact footprint of Class CC fusing with the switching convenience of a dedicated disconnect body. It is a practical fit anywhere a small-footprint, single-pole fused disconnect is needed for equipment or branch-circuit protection.

Key Features

  • Amperage Rating: 30A single-pole disconnect switch suitable for branch circuit and equipment overcurrent protection.
  • Fuse Class Compatibility: Sized for Class CC fuses, delivering compact, high-performance overcurrent protection in a small footprint.
  • Single-Pole Configuration: Single-pole switching allows quick, safe isolation of an individual circuit for service or maintenance.
  • Frequency Rating: Rated for 60 Hz electrical systems, matching standard North American power distribution.
  • Series: Part of the Eaton Bussmann series CCP fusible disconnect switch platform, model CCP2-1-30CC.
  • UL98 Fusible Disconnect: Engineered to UL98 standards governing fusible disconnect switch performance and construction.
  • Compact Disconnect Body: Combines fuse holder and disconnect switch functions in a single, space-saving assembly.

Certifications & Compliance

  • UL98 Fusible Disconnect Switch

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Typical Applications

  • Industrial and Commercial Electrical Panels
  • Motor Control Centers and Branch Circuit Protection
  • Class CC Fuse Holder and Disconnect Assemblies
  • Single-Pole Circuit Isolation and Maintenance Disconnects
  • OEM Equipment and Control Panel Wiring
  • 60 Hz Electrical Distribution Systems

Why Bussmann?

Bussmann, part of the Eaton Bussmann series, is a recognized name in circuit protection, and the CCP2-1-30CC fusible disconnect switch reflects that reputation with its UL98 listing and Class CC fuse compatibility. The single-pole, 30A CCP2-1-30CC is built to deliver dependable, code-compliant performance for professional electrical installations. Choosing Bussmann series CCP disconnect switches gives electricians and panel builders a consistent, well-documented product line for fused circuit protection.

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
BUSS-20260919
Product Type:
Fusible Disconnect Switch
Amperage Rating:
30A
Configuration:
1-Pole
Series:
CCP2
Standards:
UL98
Department:
Electrical
Product Subgroup:
Safety Switches & Disconnects
Product Group:
Power Distribution

Bussmann CCP2-1-30CC – Frequently Asked Questions

1) What fuse does the Bussmann CCP2-1-30CC disconnect take?
The CCP2-1-30CC is sized for Class CC fuses, up to 30A. Class CC is the compact ferrule fuse with the rejection feature, so a standard midget or Class G fuse will not seat in it. Order the fuse separately and match it to the load, not automatically to the 30A switch rating.
2) Is the Bussmann CCP2-1-30CC a single-pole or multi-pole disconnect?
One pole only. The CCP2-1-30CC switches and fuses a single conductor, which suits a 120V branch circuit or single-phase control feed. For a two-pole or three-phase load you need the multi-pole version of the CCP line, not this one.
3) Can I use the CCP2-1-30CC as a service or local disconnect that satisfies UL requirements?
It is built to UL98, the standard covering fusible disconnect switch performance and construction, so it functions as a true load-break disconnect rather than just a fuse holder. That is the distinction panel builders care about: a UL98 device can serve as the local isolating means for equipment, where a plain fuse block cannot.
4) Will the Bussmann CCP2-1-30CC work on a 50 Hz system?
It is rated for 60 Hz, which is standard North American distribution. For export machinery running on 50 Hz supply, confirm a 50/60 Hz rated device instead of assuming this one carries it.
5) What is the advantage of a CCP disconnect over a separate fuse block and switch in a control panel?
The CCP2 combines the fuse holder and the switching disconnect in one body, so you mount and wire a single device instead of a fuse block plus a separate disconnect. Paired with the small Class CC fuse footprint, it saves considerable DIN rail and backpan space in a tight OEM control enclosure.
6) What is the exact part number to order for the 30A single-pole Class CC CCP disconnect?
Eaton Bussmann part number CCP2-1-30CC, from the CCP2 series. The suffix reads directly: 1 pole, 30 amps, Class CC fuse.
7) Where can I get the full dimensional and electrical data for the CCP2-1-30CC?
Eaton publishes a spec sheet for the CCP2 series disconnect that carries the mounting dimensions, voltage ratings and interrupting data. It is linked from the product specs as a PDF, and it is the document to hand to an inspector or use for panel layout.
