Bussmann FWX-300A High Speed Semiconductor Fuse, 250V

Bussmann FWX-300A High Speed Semiconductor Fuse, 250V

(No reviews yet) Write a Review

Model: FWX-300A

In Stock (leaves warehouse same day if ordered before 3pm ET)

$343.70
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann FWX-300A High Speed Semiconductor Fuse, 250V

The Bussmann FWX-300A is a high speed fuse from the Eaton Bussmann FWX series, purpose-built for semiconductor protection in power electronics and industrial control applications. Rated 300A at 250V, this fuse is engineered to safeguard sensitive semiconductor devices such as SCRs, diodes, and power transistors from damaging overcurrent conditions. Whether used in variable frequency drives, rectifier assemblies, or other power conversion equipment, the FWX-300A is engineered to provide dependable, code-compliant circuit protection. As part of the trusted Bussmann product line, the FWX-300A delivers the fast-clearing response semiconductor circuits require, helping protect costly power conversion equipment from fault-current damage and unplanned downtime.

Key Features

  • Amperage Rating: 300A, sized to provide precise overcurrent protection for semiconductor circuits and power conversion loads.
  • Voltage Rating: 250V, suited to power electronics and industrial control systems operating within this range.
  • High Speed Fuse Design: Engineered for fast clearing of fault currents, limiting let-through energy to protect sensitive semiconductor components.
  • Semiconductor Fuse Construction: Purpose-built as a semiconductor fuse for SCR, diode, and power rectifier protection.
  • Eaton Bussmann FWX Series: Part of the recognized Bussmann FWX series of high speed, semiconductor-rated fuses.
  • Reliable Overcurrent Protection: Designed to help prevent damage to sensitive power semiconductor devices under fault conditions.
  • Bussmann Reliability: Backed by the Eaton Bussmann name, a widely recognized source for circuit protection products across industrial and commercial markets.

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Typical Applications

  • Power Electronics and Semiconductor Protection Circuits
  • Variable Frequency Drives (VFDs) and Motor Control Systems
  • SCR, Diode, and Power Rectifier Protection
  • Industrial Power Conversion Equipment
  • Commercial and Industrial Electrical Systems Requiring Fast-Acting Overcurrent Protection

Why Bussmann?

Bussmann, an Eaton brand, is widely recognized for engineering high-performance circuit protection products built for demanding industrial and commercial electrical systems. The FWX series high speed semiconductor fuse reflects that engineering standard, delivering fast-acting overcurrent protection sized for 300A applications at 250V. Choose the Bussmann FWX-300A for dependable semiconductor circuit protection backed by the trusted Eaton Bussmann name.

Manufacturer Resources

Product Specs

list_batch:
BUSS-20260919
Product Type:
Semiconductor Fuse
Series:
FWX
Voltage Rating:
250V
Amperage Rating:
300A
Department:
Electrical
Product Subgroup:
Fuses
Product Group:
Circuit Protection
Product Width:
1.62 in
Product Height:
1.63 in
Product Weight:
0.46 lb
Product Length:
4.3 in

Bussmann FWX-300A – Frequently Asked Questions

1) Can I use a standard 300A time-delay fuse instead of the Bussmann FWX-300A in a drive?
No. The FWX-300A is a high speed semiconductor fuse, built to clear fault current fast enough to limit let-through energy to SCRs, diodes and power transistors. A conventional time-delay or dual-element fuse of the same 300A rating clears far too slowly and the semiconductor fails before the fuse does. If the equipment drawing calls for a semiconductor-rated fuse, use one.
2) What voltage circuit is the Bussmann FWX-300A rated for?
250V. It is a 250 volt, 300 amp semiconductor fuse, so it suits power electronics and industrial control circuits at or below 250V. On a 480V rectifier or drive bus it is the wrong part, a fuse must be rated at or above the circuit voltage, so look to a higher voltage member of the Bussmann FWH or FWP high speed families instead.
3) What does a semiconductor fuse actually protect in a VFD or rectifier assembly?
It protects the silicon, not the wire. The FWX-300A sits ahead of or in series with the power devices in a variable frequency drive, rectifier bridge or other power conversion assembly and clears a shorted SCR or diode fast enough to keep the fault from cascading through the stack. Branch circuit and cable protection is a separate fuse or breaker, a semiconductor fuse does not replace it.
4) I am standardizing MRO fuse stock for drive panels, is the FWX-300A the right line item?
For 250V class power conversion gear, yes. The FWX line is Bussmann's high speed semiconductor family and the amp rating is the only thing that changes across it, so a facility can stock a short ladder of FWX sizes against its drives and rectifiers. Pull the amp rating off each drive's fuse schedule rather than off the motor nameplate, semiconductor fuses are sized to the device, not the load.
