Bussmann TPL-BA Eaton Series Telecommunication Fuse, 70A 170Vdc
The Bussmann TPL-BA is an Eaton series TPL telecommunication fuse engineered for 170 Vdc, 70A DC power circuits requiring 100 kAIC interrupting capacity. This current-limiting, non-indicating fuse features a bolted blade end x bolted blade end configuration with silver-plated terminals for low-resistance, high-integrity electrical connections. Because the TPL-BA is current-limiting, it restricts peak let-through current and energy during a fault, helping protect conductors, bus structures, and sensitive downstream equipment. Built for telecommunication and DC power protection applications, the TPL-BA delivers dependable overcurrent protection in demanding power environments where high fault currents must be safely and quickly interrupted.
Key Features
- Amperage Rating: 70A continuous current rating suited for telecommunication DC power circuit protection.
- Voltage Rating: 170 Vdc rating engineered for demanding DC telecommunication power systems.
- Interrupting Rating: 100 kAIC interrupting capacity supports safe operation in high fault-current environments.
- Current-Limiting Design: Current-limiting operation restricts let-through energy to help protect downstream equipment, conductors, and bus structures.
- Non-Indicating Construction: Non-indicating fuse body consistent with standard Eaton Bussmann TPL-series telecommunication fuses.
- Terminal Configuration: Bolted blade end x bolted blade end termination provides a secure mechanical and electrical connection at both ends of the fuse.
- Silver-Plated Terminals: Silver-plated terminal finish enhances conductivity, reduces contact resistance, and helps resist corrosion at the connection points.
- Series: Part of the Eaton Bussmann TPL series of telecommunication fuses.
Technical Specifications
- Refer to manufacturer documentation for complete technical specifications.
Typical Applications
- Telecommunication Power Protection Circuits
- DC Power Distribution Systems
- Central Office and Data Center Power Equipment
- Battery Backup and Rectifier Protection
- Commercial and Industrial DC Power Circuits
- High Fault-Current DC Power Environments
Why Bussmann?
Bussmann by Eaton is a recognized name in circuit protection, and the TPL series is engineered specifically for the demands of telecommunication DC power systems. With a current-limiting design, a 100 kAIC interrupting rating, a 170 Vdc / 70A rating, and silver-plated bolted blade terminals, the TPL-BA is built to deliver reliable, code-compliant overcurrent protection for critical telecommunication and DC power infrastructure where dependable performance under fault conditions is essential.
Manufacturer Resources
Product Specs
- Department:
- Electrical
- Product Type:
- Fuse
- Product Group:
- Circuit Protection
- Product Subgroup:
- Fuses
- Voltage Rating:
- 170V DC
- Product Width:
- 1 in
- Connection:
- Bolted blade end x bolted blade end
- Product Weight:
- 0.19 lb
- Amperage Rating:
- 70A
- Product Length:
- 1 in
- Product Height:
- 2.66 in
- Compliances:
- RoHS Compliant
