Camden CX-DE1200 Series Single Door Exit Watch Delayed Egress Magnetic Locks

Camden CX-DE1200 Series Single Door Exit Watch Delayed Egress Magnetic Locks

(No reviews yet) Write a Review

Model: CX-DE1200-N1

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,375.00
$906.47
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Camden CX-DE1200 Series Exit Watch Delayed Egress Magnetic Locks

CX-DE1200 Series delayed egress magnetic locks feature heavy-duty construction, 1,200 lbs. holding force and a range of models and field selectable operation for varied applications, including retail, institutional or healthcare buildings.

Delayed egress magnetic locks are UL and ULC listed with a selection of models factory configured to meet North American code requirements. The innovative human voice and LED count down timer offers immediate comprehension of status for building occupants.

  • Holding Force up to 1,200 Lbs.
  • Field Selectable Exit Delay Tme 15 / 30 Seconds
  • Nuisance Delay Period Either 1, 2 or 3 Seconds
  • 75dB Voice Alerts With LED Segment Bar Displaying Countdown Time & Field Selectable Languages
  • Automatic / Manual Start-up On Power Restore
  • Single gang 90db sounder provided for Alarm alerts
  • Auto Sensing Voltage Power Input 12/24 VDC
  • Power Polarity Protection
  • Optional Connection for Auxiliary Lock (Double Leaf Door)
  • Hall Effect Sensor Monitoring Output
  • Anti-tamper status
  • Tailgating Prevention - Door Will Re-lock As Soon As It Closes
  • Anti-Pass Back / Auto Re-lock: If Door Doesn't Open After The Count Down, The Door Will Automatically Re-lock

SPECIFICATIONS

Voltage: 12/24 VDC +/- 10% (Auto-Sensing)
Current Draw: 600mA / 350mA
DPS Rating: 30 VDC, 0.1A (max.)
ATS Rating: 30 VAC / 42.4 VDC, 5A (max.)
Lock Status Relay Rating: 30 VDC, 2A (max.)
Alarm Output Rating: 30 VDC, 2A (max.)
Bond Sensor Rating: CX-DE1200: 30 VDC, 2A (max.)
Holding Force: Up to 1,200 lbs. (544 kg.)
Temperature Range: 32°F - 131°F (0°C to 55°C)
Dimensions - Armature Plate: 2-5/8"H x 11"W x 1"D (68mm x 280mm x 25mm)
Dimensions - Lock: 3"H x 11"W x 3"D (76mm x 280mm x 76mm)

Manufacturer Resources

Product Specs

Product Type:
Maglocks
Warranty:
Lifetime Limited
Commercial/Residential:
Commercial
Battery Operated:
No
Electronic:
Yes
Product Group:
Electronic Access Controls
Product Subgroup:
Electromagnetic Locks
Subcategory:
Electromagnetic Locks
Holding Force:
Up to 1,200 lbs.
Fail-safe / Fail-secure:
Field Selectable
Product Voltage:
12/24 VDC +/- 10% (Auto-Sensing)
Fire Rating:
No
Product Category:
Electronic Access Controls
Department:
Door Hardware

Camden Door Controls CX-DE1200-N1 – Frequently Asked Questions

1) How does a Camden CX-DE1200 delayed egress maglock behave when someone pushes on the door?
Push on the door and the CX-DE1200 starts a nuisance delay of 1, 2 or 3 seconds to weed out accidental bumps. If pressure continues, the exit delay runs 15 or 30 seconds (field selectable) while a human voice alert and an LED segment bar count down so occupants can see and hear what is happening. After the countdown the mag releases. If nobody actually goes through, the anti-pass back function re-locks the door automatically, and once the door does open and close again it re-locks immediately, which is what stops tailgating.
2) Is the Camden CX-DE1200 delayed egress maglock fire rated?
No. The CX-DE1200 carries no fire rating, so it is not a part for a fire rated opening assembly. It is UL and ULC listed as a delayed egress lock, with models factory configured to meet North American code requirements for delayed egress.
3) Can one Camden CX-DE1200 control a pair of doors?
The CX-DE1200 is a single door delayed egress lock, but it has an optional connection for an auxiliary lock so you can hold the second leaf of a double door off the same unit. The delay logic, voice countdown and alarm stay with the CX-DE1200 board.
4) Will the Camden CX-DE1200 delayed egress lock work in an unheated vestibule or exterior opening?
Only where temperatures stay between 32F and 131F (0C to 55C). That rules out unheated exterior openings in a cold climate. The CX-DE1200 is a commercial, hardwired device with no battery backup in the lock itself, so standby power has to come from the supply feeding it.
5) Does the Camden CX-DE1200 unlock or stay locked when power drops?
Fail-safe versus fail-secure behavior is field selectable on the CX-DE1200, along with how it comes back after a power restore: you can set it for automatic start-up or require a manual restart. Note that any electromagnetic lock releases with no power applied to the mag itself, so the selection governs the unit's re-lock logic on restore rather than creating a mechanically secure state.
6) Which model do I order in the Camden CX-DE1200 Exit Watch series?
The single door Exit Watch delayed egress unit is ordered as CX-DE1200-N1. Models in the series are factory configured to meet North American code requirements, so the model suffix matters, and the delay time, nuisance delay and language are set in the field after install.
7) Is the ROFU 21037 U-bracket a mounting option for the Camden CX-DE1200 delayed egress maglock?
No. The ROFU 21037 is a pair of U-brackets sold for use with the 21036 on ROFU model 8035/-002 in the Mini Shear Lock Series, so it belongs to a shear lock installation rather than a surface-mounted electromagnetic lock. The Camden CX-DE1200 is a single door delayed egress magnetic lock rated up to 1,200 lbs. holding force, with a 3 inch H x 11 inch W x 3 inch D lock body and a 2-5/8 inch H x 11 inch W x 1 inch D armature plate that mounts to the door leaf. Order CX-DE1200 mounting hardware suited to that armature, not shear lock brackets.
8) How loud is the alarm on the Camden Exit Watch delayed egress lock, and can I get alerts in another language?
Voice alerts from the lock run at 75dB, and the spoken language is field selectable. A separate single gang 90dB sounder ships with the unit for the alarm condition, so you can mount the louder annunciator where staff will hear it rather than at the door head. The LED segment bar at the lock shows remaining countdown time.
