Product Specs
- Approval Marks:
- CSA certificate
- Automatic Restart:
- Yes
- Ballast Factor Nom :
- 1
- Ballast Type:
- Electronic Fluorescent
- Base Model:
- HCN2S5490CWL
- Color Input Terminals:
- Black/Orange and Black/White
- Color Output Terminals:
- RED, YEL & BLU
- Connector Type:
- Poke-In
- Crestfactor Nom :
- 1.7
- Ean Upc Product:
- 7.81087E+11
- Emc Immunity Standard:
- FCC Non-Consumer
- Housing Dimensions:
- 16.7" x 1.18" x 1.0"
- Housing Material:
- Metal
- Housing Type:
- L
- Hum And Noise Level:
- A
- Ignition Method:
- Programmed Start
- Ignition Time Nom :
- 1.5 s
- Input Current Max :
- 0.35 A
- Input Current Min :
- 0.25 A
- Input Frequency:
- 50 to 60 Hz
- Input Power Nom :
- 120-119 W
- Input Voltage:
- 347-480 V
- Lamp Connection:
- Series
- Lamp Type:
- F54T5/HO
- Material Nr 12nc :
- 9.13711E+11
- Max Ballast Lamp Distance Remote Wiring:
- 20'
- Max Ballast Lamp Distance Tandem Wiring:
- Blue = 20'
- Max Ballast Lamp Distance Through Wiring:
- Blue = 20'
- Net Weight Piece :
- 0.586 kg
- Number Of Lamps:
- 1/2 piece/unit
- Numerator Packs Per Outer Box:
- 6
- Numerator Quantity Per Pack:
- 1
- Order Code:
- 9.13711E+11
- Order Product Name:
- CENTIUM HCN2S5490CWL35I
- Power Factor Nom :
- 0.98
- Rated Lamp Power:
- 54 W
- Remote Wiring Configuration Allowed:
- Yes
- Suitable For Outdoor Use:
- Yes
- T Case Maximum Nom :
- 90 °C
- Tandem Wiring Configuration Allowed:
- Yes
- Through Wiring Configuration Allowed:
- Yes
- Total Harmonic Distortion Usa:
- 10%
- Ul Recognized:
- No
- Wire Gauge Nom :
- 18AWG mm
- Wire Length By Color:
- No wires
- Wire Striplength:
- 0.375 mm
- Wire Type:
- Solid
