Eaton Circuit Breaker GFCI 20A 2-Pole 10kAIC Class-A CH Series Pigtail

Eaton CH 2-Pole GFCI Circuit Breaker

Professional Ground Fault Circuit Interrupter Protection

The Eaton CH 2-Pole GFCI Circuit Breaker delivers exceptional electrical protection and ground fault circuit interruption for residential and commercial applications. This 20A two-pole GFCI breaker with 10kAIC interrupt rating provides reliable electrical protection and personnel safety designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced ground fault protection technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Ground Fault Protection Performance

• Class-A GFCI Protection - Provides 5 mA personnel protection for enhanced electrical safety in wet locations and areas requiring ground fault protection
• 20 Ampere Rating - Handles standard residential and light commercial electrical loads with reliable overcurrent protection
• Two-Pole Configuration - Protects both hot conductors simultaneously for 240V circuits and enhanced electrical safety
• 10kAIC Interrupt Rating - Safely interrupts fault currents up to 10,000 amperes for reliable electrical system protection

Installation & Connection Features

• Pigtail Connection Design - Provides flexible wiring connection for easy installation and reliable electrical connections
• Wire Size Compatibility - Accommodates #14-3 AWG wire sizes for versatile electrical installation applications
• UL 943 Certified - Meets stringent safety standards for ground fault circuit interrupter performance and reliability

Technical Specifications

Amperage Rating: 20A, Number of Poles: 2-Pole, Interrupt Rating: 10kAIC, GFCI Type: Class-A, Personnel Protection: 5 mA, Wire Size: #14-3 AWG, Connection: Pigtail, Series: CH, Certification: UL 943, Dimensions: 6.1" L x 3.5" H x 2.25" W, Weight: 1 lb

Installation & Usage

1. Verify electrical panel compatibility with CH series circuit breakers and ensure proper electrical shutdown
2. Install breaker in appropriate panel position following manufacturer specifications and electrical codes
3. Connect pigtail leads to appropriate circuit wiring using proper wire nuts and electrical connections
4. Connect #14-3 AWG circuit wiring to pigtail connections ensuring proper hot, neutral, and ground connections
5. Test GFCI function using test and reset buttons to verify proper ground fault protection operation
6. Label circuit appropriately and document GFCI protection for electrical system records

Professional Applications

Ideal for:

• Bathroom Electrical Circuits - GFCI protection for bathroom outlets, lighting, and ventilation systems requiring ground fault protection
• Kitchen Electrical Systems - Ground fault protection for kitchen countertop outlets and appliance circuits near water sources
• Outdoor Electrical Installations - Weather-resistant electrical protection for outdoor outlets, lighting, and equipment circuits
• Garage and Workshop Circuits - GFCI protection for garage outlets, workshop equipment, and automotive electrical systems
• Basement Electrical Systems - Ground fault protection for basement outlets, utility rooms, and moisture-prone electrical installations
• Pool and Spa Electrical - Required GFCI protection for swimming pool, hot tub, and spa electrical circuits and equipment
• Laundry Room Circuits - Ground fault protection for washing machine outlets and laundry room electrical systems
• Commercial Wet Locations - GFCI protection for commercial kitchens, restrooms, and other wet location electrical installations

Class-A GFCI Technology Advantage

The Class-A GFCI technology provides 5 mA trip sensitivity for maximum personnel protection against electrical shock hazards. This advanced ground fault detection system continuously monitors electrical current flow and instantly interrupts power when ground fault conditions are detected, providing life-saving protection in wet locations and areas where electrical shock hazards exist.

Why Choose Eaton Quality?

Eaton's century-plus experience in electrical power management innovation delivers the CH series GFCI circuit breakers that electrical professionals trust. With rigorous UL 943 certification, proven ground fault protection technology, and reliable performance in demanding electrical applications, Eaton GFCI breakers provide the electrical safety and dependable operation that electricians, electrical contractors, and facility professionals require for code-compliant electrical installations worldwide.
