Square D PowerPacT B-Frame 3-Pole Thermal Magnetic Circuit Breaker, 14kA

Square D PowerPacT B-Frame 3-Pole Thermal Magnetic Circuit Breaker, 14kA

(No reviews yet) Write a Review

Model: BDL26060

In Stock (leaves warehouse same day if ordered before 3pm ET)

$810.69
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Square D PowerPacT B-Frame 3-Pole Thermal Magnetic Circuit Breaker, 14kA

Square D's PowerPacT B-Frame 3-Pole Thermal Magnetic Circuit Breaker delivers compact thermal-mechanical circuit protection with a wide range of accessories and connection options. Rated 0Y/347VAC with a 14kA interrupt rating at 500...525V AC, it uses Everlink lug line and load connections and is UL 489 listed with an 800V insulation voltage (Ui) rating per IEC 60947-2, suited to industrial and commercial distribution panels.

Key Features

  • Configuration: 3-pole thermal magnetic circuit breaker for overcurrent and short-circuit protection.
  • Rated Voltage: 0Y/347VAC, with a Ue rated operational voltage of 525V AC, 50/60 Hz per UL 489.
  • Interrupt Rating: Ics rated service breaking capacity of 14kA at 500...525V AC and 25kA at 220...240V AC per IEC 60947-2.
  • Insulation & Impulse Withstand: Ui rated insulation voltage of 800V and Uimp rated impulse withstand voltage of 8kV per IEC 60947-2.
  • Electrical Connection: Everlink lugs on line and load sides, accepting AWG 14 through AWG 3/0 rigid or stranded aluminum/copper conductors.
  • Mounting: By screws to a plate or clip-on 35 x 15mm symmetrical DIN rail.
  • Durability: 20,000 mechanical cycles and 10,000 electrical cycles per IEC 947-1 Annex K ed 5.2.
  • Enclosure Protection: IP40 on the front cover per IEC 60529.

Certifications & Compliance

  • UL 489 Listed
  • CSA C22.2 No 5
  • NEMA AB1
  • IEC 60947-2 / IEC 60947-5-1
  • GB 14048.2 / NMX J-266
  • Product Certifications: IEC, EAC, NOM, CSA, UL, CCC
  • Suitable for Isolation per IEC 60947-2

Technical Specifications

  • Sustainable Packaging: Yes
  • Recycled Metal Content At Cr Level: 0 %
  • Serviceability: No
  • With Recycled Cardboard: Yes
  • China ROHS In Scope: No
  • Return Indicator: Y
  • Tier: 1
  • Legacy WEEE Scope: In
  • Packaging Made With Recycled Cardboard: Yes
  • Without Single Use Plastic: Yes
  • ROHS Exemption Information: Yes
  • Quality Labels: CE
  • WEEE Product Category: 4
  • Mercury Free: Yes
  • ROHS Eur Full Compliance Status Id: COMPLIANT_WITH_EXEMPTIONS
  • Packaging Without Single Use Plastic: Yes
  • Tier Id: 1
  • ROHS Eur In Scope: Yes
  • Environmental Disclosure: ENVPEP2311047_V2
  • ROHS Eur Status: Compliant with Exemptions
  • Average Life Duration: 15 year(s)

Typical Applications

  • Industrial and Commercial Electrical Distribution Systems
  • Panelboard and Switchboard Circuit Protection
  • Motor and Feeder Circuit Protection
  • I-Line and Unit Mount Panel Installations
  • OEM Control Panel Building

Why Square D?

Square D's PowerPacT B-Frame breakers combine compact thermal-mechanical protection with Everlink lug connections and a wide accessory range, backed by UL 489, CSA, and IEC 60947-2 listings for dependable, code-compliant performance in demanding distribution applications.

Manufacturer Resources

Product Specs

Product Type:
Circuit Breaker
Configuration:
3 Pole
Voltage Rating:
0Y/347VAC
Listing:
UL Listed
Standards:
UL 489
Series:
PowerPacT B
Product Color:
Gray
Department:
Electrical
Product Group:
Wiring Devices
